urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 574

RTSP In-Call stream settings
RTSP In-Call stream
IP Address (#)
Network mask (#)
Port
Stream
User Name (#)
Password (#)
URI for Streaming
In the RTSP streaming settings to set the IP address it is recommended to follow what is reported in
APPENDIX F1: How to use customized network settings in IperCom
It is possible to configure any Urmet NVR device to record calls made via Call Module 1060/23 and
related auto-on activated by video door phone. In
calling stations to NVR Urmet
shown. For the configurations of the other Urmet NVR devices contact the Urmet Service Centre.
The "Add" button in the "Activations" section has already been described in paragraph Activations.
The "Select" button in the "Images" section allows loading a welcome image on the calling station display.
Supported file formats include also the most common ones like jpg, bmp and png. We recommend
uploading images with an aspect ratio of 200x58 pixels: this way the image will not be cropped. Once an
image is uploaded, you can delete it using the "Delete" button.
The welcome image disappears if an apartment is called for which (in the configurator) a help
image on how to reach it has been uploaded (see section
replaced by the welcome image during the call phase (forwarding and answering). At the end of the
call, the welcome image is displayed again.
The address book of the Call Module is automatically created by importing the residents (set as
visible) of all apartments in the topology group of the Call Module itself.
574
If selected, the Switchboard application can display the RTSP
video stream of the calling station during the call to an
apartment station or during the auto-on from an apartment
station. Fields marked with the hash mark (#) must be filled
correctly.
IP address of calling station camera.
Subnet mask of RTSP cameras (including calling station
camera).
RTSP video stream port. Value not editable.
Name of the RTSP video stream. Value not editable.
Username to access the calling station RTSP video stream
from the Switchboard application.
Password to access the calling station RTSP video stream
from the Switchboard application.
Full URI of the RTSP video stream. Value not editable.
It is built automatically by filling in the fields above respecting
the following syntax:
rtsp://[<username>:<password>@] <IP address>:<port>/<stream>
Table 36: RTSP streaming settings
APPENDIX M1: Streaming video from IPerCom
the configuration procedure of the 1098/328P Urmet NVR device is
system.
Call addressing mode). This image is only
MT124-032N
