GENERAL ........................................................................................2
SPECIFICATIONS ............................................................................3
Electrical properties ......................................................................3
DESCRIPTION OF COMPONENTS ................................................ 3
TYPES OF SERVICE .......................................................................4
Switchboard station off ................................................................. 4
Switchboard station on ................................................................. 4
Night service .................................................................................4
Day service ...................................................................................5
OPERATING INSTRUCTIONS ........................................................ 5
Activation and deactivation ........................................................... 5
Day/night service changeover ...................................................... 6
Night/day service changeover ...................................................... 6
Viewing zone assignments ........................................................... 6
Calls to/from apartment stations ................................................... 7
Call storage in memory ................................................................. 7
Queued calls .................................................................................7
Panic alarm calls...........................................................................8
Concierge service .........................................................................8
Voice channel switchover keys ..................................................... 9
Door lock release functions ........................................................ 10
Voice line status display ............................................................. 10
Dialog between two switchboard stations ................................... 10
Self-activation function................................................................ 11
Special service codes ................................................................. 11
Sensor monitoring.......................................................................11
SPECIAL FUNCTIONS ..................................................................11
Date/time adjustment .................................................................. 11
Keypad lock activation/deactivation ............................................ 11
Call rerouting ..............................................................................12
Other display messages ............................................................. 12
Using a printer ............................................................................12
Management from PC using 'pcvoice' software.......................... 13
INSTALLATION-TERMINAL DESIGNATIONS .............................. 14
DIGIVOICE - Technical Manual
APARTMENT
DOOR PHONE
STATIONS
Download from: www.urmetdomus.com Technical Manuals area.
SECTION CONTENTS
SECTION 5A
(REv.F)
2
CONFIGURATION .........................................................................15
GENERAL ......................................................................................19
SPECIFICATIONS ..........................................................................20
INSTALLATION - TERMINAL DESIGNATIONS ............................ 20
Tabletop mounting ......................................................................20
Wall mounting .............................................................................20
CONFIGURATION .........................................................................20
OPERATION ..................................................................................21
FEATURES ....................................................................................23
SPECIFICATIONS ..........................................................................23
OPERATION ..................................................................................23
PROGRAMMING ............................................................................24
INSTALLATION ..............................................................................25
DESCRIPTION OF TERMINALS ................................................... 26
INSTALLATION ..............................................................................26
DESCRIPTION OF TERMINALS ................................................... 27
INSTALLATION ..............................................................................27
HANDS-FREE DOORPHONE Ref. 1138/6 .................................... 28
9
23
26
27
29
29

sec.5a −−−−

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1138/18 and is the answer not in the manual?

Questions and answers

Related Manuals for urmet domus 1138/18

Summary of Contents for urmet domus 1138/18

  • Page 1: Table Of Contents

    SECTION 5A (REv.F) APARTMENT DOOR PHONE STATIONS Download from: www.urmetdomus.com Technical Manuals area. SECTION CONTENTS GUARD DOOR SWITCHBOARD STATION Ref. 038/40 CONFIGURATION .................15 GENERAL ..................2 SPECIAL DOORPHONE Ref. 38/8 SPECIFICATIONS ................3 GENERAL ..................19 Electrical properties ..............3 SPECIFICATIONS ................20 DESCRIPTION OF COMPONENTS ..........3 INSTALLATION - TERMINAL DESIGNATIONS ......

  • Page 2: Guard Door Switchboard Station Ref. 038/40

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 GENERAL GUARD DOOR SWITCHBOARD STATION Ref. 038/40 260 mm SHIFT GENERAL Guard door switchboard station Ref. 1038/40 is designed specifically for the DIGIVOICE system, where it is used for: • Making and receiving calls to and from apartment stations, with provision for storing any unanswered calls in memory.

  • Page 3: Specifications

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 SPECIFICATIONS - DESCRIPTION OF COMPONENTS DESCRIPTION OF COMPONENTS GRAPHIC DISPLAY The guard door switchboard station is provided with a backlit graphic display featuring five lines with 10/20 characters each. During active service, characters shown on the display are divided into zones as follows: eeefiiii eeefiiii...

  • Page 4: Types Of Service

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 TYPES OF SERvICE dddd Zone (4 characters) 29 Clock key. This is the zone used for codes entered by the switchboard attendant: 30 Main entrance door lock release key. call codes, special codes, entrance module codes used for door lock 31 Secondary entrance door lock release key.

  • Page 5: Day Service

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 OPERATING INSTRUCTIONS DAY SERvICE After 3 seconds or when the call button is pressed, the switchboard station will be activated in the operating mode it was in the last time it was turned off. In this operating condition, the switchboard station can be programmed If the switchboard station is in DAY service, LED will be on.

  • Page 6: Day/Night Service Changeover

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 OPERATING INSTRUCTIONS DAY/NIGHT SERvICE CHANGEOvER desired switchboard station. For instance, if key is pressed twice, the display will show: To change from DAY to NIGHT service, press the key together SHIFT with the service button. How changeover takes place will depend on the type of installation.

  • Page 7: Calls To/From Apartment Stations

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 OPERATING INSTRUCTIONS CALLS TO/FROM APARTMENT STATIONS This indicates that the switchboard station is connected to apartment station 1634 on voice line 1. The display will be cleared when the call ends. The switchboard station can make and receive calls to and from apartment stations.

  • Page 8: Panic Alarm Calls

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 OPERATING INSTRUCTIONS Calling a queued apartment station 1634 To call a queued apartment station, press the Call from Queue key Note: calls to queued apartment stations can be made only with the handset off-hook, and no other apartment stations are connected.

  • Page 9: Voice Channel Switchover Keys

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 OPERATING INSTRUCTIONS If the called apartment station answers, the attendant can put the main Example: Handling calls with two voice channels entrance panel in direct communication with the apartment station by pressing key . The display will show: In systems with two voice channels, the switchboard station automatically selects the channel to be used for a call.

  • Page 10: Door Lock Release Functions

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 OPERATING INSTRUCTIONS 3) The attendant can establish direct communication between and secondary entrance panels, there is no way of knowing whether the entrance panel 1 and the apartment station as described above, lines between secondary entrance panels and decoders are engaged. and then switch the line to main entrance panel 2 by pressing key Voice channels 1 and 2 can assume the following states: .

  • Page 11: Self-Activation Function

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 SPECIAL FUNCTIONS 0001-0002 23/05/2000 08:10:00 23/05/2000 08:10:00 0001 0001 Note: dialog can take place between two switchboard stations only Where, ‘ON’ means that the lights are on, while ‘OFF’ indicates that they are off. In order to attract the attendant’s attention, the display is if neither is engaged in another voice call, and neither has accompanied by a one-second audible signal.

  • Page 12: Call Rerouting

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 SPECIAL FUNCTIONS will show “XXXX” in the user code field. To deactivate the keypad lock, • The message will remain on the display for as long as the problem repeat the operation described above. persists.

  • Page 13: Management From Pc Using 'Pcvoice' Software

    DIGIVOICE switchboard station. In addition, the screen features the Cancel button to exit from the procedure without making changes. Urmet Domus logo and a configuration button (38). The main screen is used to manage a directory consisting of: Note: the directory can contain a maximum of 1000 names.

  • Page 14: Installation-Terminal Designations

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 INSTALLATION-TERMINAL DESIGNATIONS INSTALLATION-TERMINAL DESIGNATIONS 5) Reassemble switchboard station and supply it with power. The switchboard station can now be controlled only by the PC, using the PCVOICE program. The switchboard station is designed for either tabletop or wall mounting.

  • Page 15: Configuration

    GUARD DOOR SWITCHBOARD STATION Ref. 038/40 CONFIGURATION PROGRAMMING TERMINAL 038/56 CONNECTION STEP  - SWITCHBOARD STATION CODE The display will show: The switchboard station is provided with a connector (17) for programming terminal 1038/56. The terminal can be used for centralized STEP 1 programming of all entrance modules installed in the system.
  • Page 16 GUARD DOOR SWITCHBOARD STATION Ref. 038/40 CONFIGURATION To change the number of voice lines, simply select the desired number If 1 is selected, the switchboard station will answer calls from main using the appropriate number key (1 or 2) and press the call button entrance panels addressed to its own code (i.e., the code set in step If the switchboard station is to be configured to handle two ‘simultaneous’...
  • Page 17 GUARD DOOR SWITCHBOARD STATION Ref. 038/40 CONFIGURATION STEP  – SERIAL LINE ENABLING STEP 2 – FUNCTION KEY F PROGRAMMING The display will show: The display will show: STEP 11 STEP 12 ---------- ---------- SERiAL LiNE FUNCTiON KEY [F1] (0=OFF,1=ON) (0,1,2,3,4) To change serial line configuration, simply select the desired number To change the function associated with key F1, simply select the...
  • Page 18 GUARD DOOR SWITCHBOARD STATION Ref. 038/40 CONFIGURATION STEP 6 - PROGRAMMING FUNCTION KEY F5 Proceed as for step 12. Note: for key F5, press and F2 simultaneously. SHIFT STEP 6A - ASSIGNING A SPECIAL CODE TO THE FUNCTION KEY Proceed as for step 12A. STEP 7 - PROGRAMMING FUNCTION KEY F6 Proceed as for step 12.

  • Page 19: Special Doorphone Ref. 38/8

    NOTE: only one conversation can take place in a riser column at any one time regardless of the number of 1138/18 special door phones fitted. NOTICE: Any entrance panels 1038/10, 1038/15 or 1038/16 installed in systems using special doorphones 1138/18 must be version 2.0 or higher. 1) Doorphone top casing. FEATURES 2) 10 alphanumeric keys.

  • Page 20: Specifications

    REFERENCE STANDARDS To activate the configuration cycle, hold down the SHIFT key (5) and Special doorphone 1138/18 complies with the following standards: press key (13) several times in succession until LED (11) turns red (not • CEI EN 5008- Electromagnetic Compatibility. Generic emission flashing).

  • Page 21: Operation

    SPECIAL DOORPHONE Ref. 38/8 OPERATION STEP 7 - CALLING MODE • 20 pre-programmed functions: Call code 1000. OPERATION Enter 3 to select ‘UNRESTRICTED’ calling mode, 2 to select ‘PROGRAMMED’ calling mode, or 1 to disable the doorphone from RECEIvING CALLS FROM ENTRANCE PANELS OR making outgoing calls.
  • Page 22 SPECIAL DOORPHONE Ref. 38/8 OPERATION ‘PROGRAMMED’ calling mode To deactivate the feature, press SHIFT-MUTE again. LED (11) will go off. In this mode, each key 1 through 0 and A through J (i.e., SHIFT-1 To activate the feature with MUTE, press MUTE; LED (11) will turn through SHIFT-0) is associated with an apartment station code or, green.

  • Page 23: Doorphone With Single-Port Decoder Ref. 38/3

    DOORPHONE WITH SINGLE-PORT DECODER Ref. 38/3 FEATURES - SPECIFICATIONS - OPERATION DOORPHONE WITH SINGLE-PORT DECODER 9) Ringer/courtesy tone speaker. 10) Top casing. Ref. 38/3 11) Programming connector. 12) Printed circuit. 90 mm 69 mm 13) Programming key. TERMINAL DESIGNATIONS RISER COLUMN TERMINAL BLOCK - (M) Voice terminal B (return voice conductor) Voice terminal A (outward voice conductor) Data bus terminal...

  • Page 24: Programming

    DOORPHONE WITH SINGLE-PORT DECODER Ref. 38/3 PROGRAMMING RINGING TONES CALLS FROM LANDING The doorphone is provided with an outward-facing call tone signaling speaker. The speaker produces four distinctive ringing tones to identify different types of call: • Call from main entrance modules. Continuous two-tone ringing for the duration programmed at the calling module.

  • Page 25: Installation

    DOORPHONE WITH SINGLE-PORT DECODER Ref. 38/3 INSTALLATION PROGRAMMABLE PARAMETERS LED status Condition Programming key pressed briefly The following parameters must be programmed for each doorphone Indicates that device is ready to (riser cable code and user code with single-port decoder: be programmed.

  • Page 26: Atlantico Door Phone With 2 Buttons Ref. 38/3

    ATLANTICO DOOR PHONE WITH 2 BUTTONS Ref. 38/3 DESCRIPTION OF TERMINALS - INSTALLATION ATLANTICO DOOR PHONE WITH 2 BUTTONS INSTALLATION Ref. 38/3 100 mm 64 mm Featuring Atlantico styling, this doorphone is designed specifically for the Digivoice system. The features of the door phone are: •...

  • Page 27: Installation

    UTOPIA DOOR PHONE WITH 2 BUTTONS Ref. 38/4 DESCRIPTION OF TERMINALS - INSTALLATION UTOPIA DOOR PHONE WITH 2 BUTTONS INSTALLATION Ref. 38/4 90 mm 48,5 Featuring Utopia styling, this doorphone is designed specifically for the Digivoice system. The features of the door phone are: •...

  • Page 28: Hands-Free Doorphone Ref. 1138/6

    HANDS-FREE DOORPHONE Ref. 38/6 HANDS-FREE DOORPHONE Ref. 38/6 Connection of two hands-free doorphone in parallel to a decoder Ref. 038/35. 1038/35 1138/6 1138/6 Connection of a hands-free doorphone in parallel with a basic doorphone to a decoder Ref. 038/35. Hands-free doorphone provides following...

  • Page 29: Hands-Free Doorphone For Special Applications Ref. 38/7

    HANDS-FREE DOORPHONE FOR SPECIAL APPLICATIONS Ref. 38/7 GUARD DOOR SWITCHBOARD STATION/ TELEPHONE INTERFACE OR PABX ADAPTER CIRCUIT Ref. 038/70 INSTALLATION HANDS-FREE DOORPHONE FOR SPECIAL GUARD DOOR SWITCHBOARD STATION/ APPLICATIONS Ref. 38/7 TELEPHONE INTERFACE OR PABX ADAPTER CIRCUIT Ref. 038/70 In order to use the call rerouting feature, the telephone interface or PABX adapter circuit must be installed in the switchboard station Ref.
