End user settings
Loudspeakers Volume
Button feedback tone
Call feedback tone
Camera LEDs
Model 1060/71
RTSP In-Call stream settings
RTSP In-Call stream
IP Address (#)
Network mask (#)
Port
Stream
User Name (#)
Password (#)
URI for Streaming
In the RTSP streaming settings to set the IP address it is recommended to follow what is reported in
APPENDIX F1: How to use customized network settings in IperCom
It is possible to configure any Urmet NVR device to record calls made via Entry Panel 1060/71-74-
75-78 and related auto-on activated by video door phone. In
IPerCom calling stations to NVR Urmet
device is shown. For the configurations of the other Urmet NVR devices contact the Urmet Service
Centre.
590
Loudspeaker volume setting.
Audio feedback volume at button pressure.
Feedback volume of forwarded call.
Enabling of the camera LEDs.
This box must be ticked if you use a calling station with one
button.
Table 47: end user settings
If selected, the Switchboard application can display the RTSP
video stream of the calling station during the call to an
apartment station or during the auto-on from an apartment
station. Fields marked with the hash mark (#) must be filled
correctly.
IP address of calling station camera
Subnet mask of RTSP cameras (including calling station camera).
RTSP video stream port. Value not editable.
Name of the RTSP video stream. Value not editable
Username to access the calling station RTSP video stream
from the Switchboard application.
Password to access the calling station RTSP video stream
from the Switchboard application.
Full URI of the RTSP video stream. Value not editable.
It is built automatically by filling in the fields above respecting
the following syntax:
rtsp://[<username>:<password>@] <IP
address>:<port>/<stream>
Table 48: RTSP streaming settings
the configuration procedure of the 1098/328P Urmet NVR
system.
APPENDIX M1: Streaming video from
MT124-032N
