7

System technical manual

for the installer

Advertisement

Need help?

Need help?

Do you have a question about the IPerCom 3.1.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for urmet domus IPerCom 3.1.0

Page 1 System technical manual for the installer...
Page 2 Contents MT124-032N Version 3.1.0 Introduction ..........................12 IPerCloud mode ........................14 Configuration of an IPerCom system ..................18 IT security of the IPerCom system ................... 20 IPerCom devices and features offered by the system ..............22 Server 1060/1 ........................26 Call Module 1060/12-13-17-18 ....................
Page 3 2.26 Switchboard 1060/41 ......................35 2.27 IPerCom Clock Module 1060/85 ..................... 35 2.28 Lift Interface 1060/37 ......................35 2.29 Gateway IPerCom-2Voice 1083/59 ..................36 2.30 IPassan controller ........................36 2.31 IPerTAlk Server ........................36 2.32 RTSP Cameras ........................37 2.32.1 RTSP Cameras (NVR) ......................
Page 4 Automatic update to the latest available version ..............57 Starting the Launcher ......................59 Automatic detection of the IPerCom version ................59 6.5.1 System upgraded to the last version ................61 6.5.2 System not upgraded to the last released version ............63 6.5.3 Mixed system .........................
Page 5 6.10 How to use IPerCom Installer Tools to edit the configuration with system already installed and configured..........................111 6.11 System modified locally by MAX, VOG or Basic video door phone ........115 6.12 Importing configuration files with different IDs ..............119 6.13 Systems with two configurations ..................
Page 6 Creating or editing the configuration file from IPerCom Installer Tools ........193 7.1.1 Selecting the system topology (model) and the configurator structure ......194 7.1.1.1 Villa Kit (one-household) systems ................201 7.1.1.2 Single Stair systems ....................202 7.1.1.3 Multiple Stairs systems ..................... 203 7.1.1.4 Multi Block systems ....................
Page 7 7.1.5.5 Activation for events on Call Module ................. 273 7.1.5.6 Activation for events on Entry Panel with 1060/48 ............ 276 7.1.5.7 Key Reader activations ..................... 277 7.1.5.8 Activations for topological events ................279 7.1.5.8.1 Topological events for Relay Actuator ..............281 7.1.5.8.1.1 Addition of a user activation on video door phones / door phones / CallMe application .....................
Page 8 7.1.10.2 Door/Gate Settings ....................383 7.1.10.3 Call Forwarding Settings ..................385 7.1.10.4 Call divert settings ....................388 7.1.10.5 Network settings ....................389 7.1.10.6 ..................391 USTOM NETWORK SETTINGS 7.1.10.7 Maintenance Settings ................... 392 7.1.10.8 Sunrise/Sunset Settings..................394 7.1.11 Call addressing mode ....................395 7.1.12 Setting of call forwarding function in IPerCom system not in IPerCloud mode ....
Page 9 8.3.2.5 Mode 3.1: The installer creates the configuration in the laboratory on the MAX video door phone/PC/Android tablet and adds at the same time the previously installed devices .. 508 8.3.2.6 Mode 4: One MAX video door phone with configurator in "Acquisition" mode ... 509 Configuration distribution....................
Page 10 10.10 Factory reset of the Entry panel 1060/33-34 ................. 557 10.11 Factory reset of Entry Panel 1060/21 ................... 558 10.12 Factory reset of Floor Entry Panel 1060/22 ................559 APPENDIX A: Configuration parameters of IPerCom devices ..............560 Server 1060/1 ..........................560 Call Module 1060/12-13-17-18 ......................
Page 11 APPENDIX D: IPerCom priority calls ..................... 643 APPENDIX E: Type of proximity keys that can be read by IPerCom devices with access control function 644 APPENDIX F1: How to use customized network settings in IperCom system .......... 645 APPENDIX F2: Custom network settings and editable static IP addresses for IPerCom devices ....656 APPENDIX G: Changing the network settings of IPerCom Installer Tools.
Page 12 1 Introduction IPerCom 3.1.0 is an IP video door phone system with the following features: 1. it supports small and medium-sized systems with a maximum number of 1000 IP devices and a maximum number of 1000 users without having to use any system server 2.
Page 13 14. in systems with at least one system server, the configuration file can also be backed up periodically (automatic mode) to a USB stick (connected to the server) using IPerCom Installer Tools; 15. in systems with at least one system server, the firmware update of all devices can take place automatically via the server itself (appropriately configured).
Page 14 1.1 IPerCloud mode The IPerCloud mode, integrated into the IPerCom system starting from version 3.0.0, allows to receive calls on the “Urmet CallMe 2023 ed.” app (for smartphones/tablets) without the need for a door phone or video door phone in apartment: in this mode, the apartments are defined as IPerCloud apartments. The “Urmet CallMe 2023 ed.”...
Page 15 The configuration of the IPerCloud mode requires the mandatory use of the following applications to be used in the following order: • IPerCom Installer Tools (Windows application) for the installer (registration on Urmet Cloud is required), • CallMe Manager (Windows application) for the installer and building manager (registration on Urmet Cloud is required), •...
Page 16 BUILDING MANAGER The building manager must first accept the invitation sent by the installer, then use the CallMe Manager application to: • create an Urmet Cloud account and authenticate on CallMe Manager with this account, • acquire the site created by the installer, •...
Page 17 END-USER The end-user uses the CallMe application to: • create an Urmet Cloud account and authenticate on CallMe with this account, • scan the QR code sent by the building manager to associate the account (created in the previous point) with the apartment. Once this is done, you can receive the call to an IPerCloud apartment on your smartphone/tablet.
Page 18 1.2 Configuration of an IPerCom system It is advisable to use the IPerCom Installer Tools application as configuration tool for an IPerCom system. The tool allows to: • automatically update to the latest version available (if there is an Internet connection); •...
Page 19 The system technical manual for the installer is intended as a manual for setting up an IPerCom system, so for the use and the detailed installation of the single devices and software applications please refer to the relevant user and installation manuals, available on the website www.urmet.com. In this manual, calling station means a generic call module or entry panel of the system, while an apartment station means a video door phone or door phone in an apartment.
Page 20 1.3 IT security of the IPerCom system To increase IT security, starting from version 3.1.0 the following has been introduced regarding the passwords used by the applications and devices of the IPerCom system. 1. The complexity of new passwords must meet the requirements below: - minimum length: 8 characters, - maximum length: 19 characters, - presence of at least one uppercase character,...
Page 21 3. Protection against "brute force" attacks aimed at discovering passwords in use. To protect applications and software from possible "brute force" attacks, it is necessary to wait 5 seconds to enter a new password (if the previous one was wrong). This delay, combined with the new password security requirements, makes this type of attack practically impractical for an attacker.
Page 22 2 IPerCom devices and features offered by the system IPerCom system 3.1.0 supports the devices indicated below • Server: o IPerCom Server 1060/1 • Switchboards: o Switcboard (software application) 1060/41 • Calling stations: o Call module soft touch 1060/12-13 and vandal-proof 1060/17-18 o Vandal-proof call module 1060/23 o Modular entry panel with 1060/48 o Entry panel 1060/71-74-75-78...
Page 23 • Other Devices: o IPerCom Clock Module 1060/85 o Lift Interface 1060/37 o RTSP Camera o RTSP Camera (NVR) It is recommended to have a maximum of 200 devices in an IPerCom system including Key Reader 1060/45, Key Reader 1060/86, Relay Actuators 1060/84, and Lift Interface 1060/37. APPENDIX V: Device compatibility table the set of supported devices is reported for each version of IPerCom officially released.
Page 24 IPerCom system 3.1.0 supports the following services: o Audio/video communication on calls from calling station to an apartment station and on intercom calls, o Opening of the main door and gate from apartment stations during call and conversation with calling stations, o Auto-on on all calling stations and RTSP Cameras from all video door phones of the system (for VOG and VOG...
Page 25 o Call forwarding on smartphone/tablet Android and iOS via CallMe app with these additional features: ▪ Auto on on IPerCom calling stations, ▪ Intercom calls to apartment staions, ▪ Display of missed calls with snapshot from calling stations, ▪ Opening of main doors and gates during and outside calls, ▪...
Page 26 2.1 Server 1060/1 The Server 1060/1 is a device required to manage large installations (with more than 1000 IP devices and/or 1000 users) and to have the System Logs available on IPerCom Installer Tools. It is possible to configure up to 4000 IP devices and 10000 users with at least one Server 1060/1 in the system. The Server 1060/1, properly configured, can also update independently the various devices of the system: this means that through IPerUpgrade it is sufficient to upgrade only the Server 1060/1, which will upgrade the rest of the system.
Page 27 The version 1060/12-13 features a soft-touch alphanumeric keypad and glass panel, while the version 1060/17-18 features a vandal resistant steel front panel. It can be used in both 50Hz (1060/13-18) and 60Hz (1060/12-17) systems. 2.3 Call Module 1060/23 The Call Module 1060/23 is a call station with 3.5'' colour display, alphanumeric keyboard, and steel vandal resistant front panel.
Page 28 2.4.1 Call module The IP audio and video outdoor station 1060/48 together with the Display Module 1168/1 and the Numeric Keypad 1168/46 make up the standard configuration of a call module. The Display Module 1168/1 allows access to various functions (such as the residents' address book, direct call to the relevant switchboard, door opening via numeric code) and the display of a welcome message.
Page 29 2.6 Entry Panel 1060/21 The Entry Panel 1060/21 is a vandal-proof calling station with a single push button with weather-proof zama front. It can independently control two different outputs. The first is used to open a pedestrian door, the second to control the gate opening control unit of a possible driveway.
Page 30 2.9 Private Call Module 1060/22 The Private Call Module 1060/22 is a one-push button call station to be installed directly outside the main door of the apartment. It can only call the apartment station of the apartment to which the call station is associated. Apartment station can make auto-on on the Private Call Module.
Page 31 2.12 Video door phone 5’’ VOG 1761/15-16-18-19 The video door phone VOG 1761/15-16-18-19 is a hands-free video door phone indoor station with a 5'' display and soft-touch keys. The video door phone allows call forwarding to smartphones/tablets via the CallMe app (for Android and iOS), as well as enabling normal video door phone functions (also via gesture or voice commands).
Page 32 2.15 Video door phone 7’’ MAX 1717/31-32-33-34-41 The video door phone MAX 1717/31-32-33-34-41 is a hands-free video door phone apartment station with a 7’’ touch-screen display. The video door phone allows call forwarding to smartphones / tablets through the CallMe app (for Android and iOS), as well as allowing normal video door phone functions (also via gesture or voice commands for 1717/3x versions).
Page 33 2.18 Video door phone 7'' Basic 1741/1-2-3 The video door phone Basic 1741/1-2-3 is a hands-free video door phone apartment station with a 7'' touch-screen display. The video door phone allows call forwarding to smartphones / tablets through the CallMe app (for Android and iOS), as well as allowing normal video door phone functions (also via voice commands).
Page 34 2.22 Relay actuator 1060/84 v. 3.04 The activation of the relays in monostable or bistable mode occurs through events generated by call stations, key readers, and apartment stations or locally through the inputs of the Relay Actuator. The same inputs (properly programmed) can activate one or more outputs of several Relay Actuators and generate an alarm towards the Switchboard application.
Page 35 2.26 Switchboard 1060/41 The IPerCom system implements the concierge function using a PC and the specific Switchboard application software. It is possible to connect the door phone 1060/41 (via a USB port of the PC and the mini-jack audio connectors). Switchboard and IPerCom Client applications must be used on 2 different PCs.
Page 36 2.29 Gateway IPerCom-2Voice 1083/59 The Gateway IPerCom-2Voice 1083/59 allows integrating the 2Voice system with the IPerCom system: in detail, it allows the addition of a riser column (stair) of 2Voice audio / video apartment stations to an IPerCom system. In this way, it is possible to create systems with an IPerCom common backbone on street side and 2Voice riser columns with only 2 non-polarized wires.
Page 37 2.32 RTSP Cameras RTSP Cameras are cameras that use the network protocol Real Time Streaming Protocol for the video streaming. The auto-on function on RTSP Cameras is available from all video door phones of the IPerCom system and from the Switchboard and IPerCom Client applications for video surveillance functions (in addition to auto-on on calling stations).
Page 38 3 Basic concepts IPerCom is based on the following basic concepts: topology, topological group and topological path. 3.1 Topology The topology of a building (or site) is a simplified map that considers the various elements that make it up and their relative positioning. Typically, the types of elements that make up a building are: blocks, stairs, floors, apartments.
Page 39 Since each node can be associated with two digits, to identify in the entire topology an apartment that is below a floor, a stair, a block and a site, a numeric code of 10 digits is needed. In the example of Figure by assigning to the base site a code equal to “01”, to the block the code “01”, to the second stair “02”, to the third floor of the stair “03”...
Page 40 • the path highlighted in red from the ‘’Stair 2’’ node to the ‘’Site’’ node is the topological path of the ‘’Stair 2’’ node: visually speaking the topological path goes from the node considered upwards (‘’ Stair 2 -> Block 1 -> Site’’); •...
Page 41 3.3.3 Propagation of activation rules An activation rule created on a node is propagated on all apartament station contained in the topological group of the node in question. For example, an activation rule created on a stair node will be automatically propagated on all apartament station placed within the topological group in question.
Page 42 The CallMe app linked to the Switchboard application placed on the “Stair 1” node has in its address book the apartments of the topological group relating to the “Stair 1” node. 3.3.6 Resident access (with key code and door code) to doors/gates of the system Residents have automatic access by means of door codes and proximity key codes to all those entrances (pedestrian doors or driveways of Call Modules, Entry Panel and Key readers) that are placed on their topological path, that is on the topological path of their respective apartment nodes.
Page 43 3.3.9 Practical example of application of the topological path concept The figure below shows an example of application of the three concepts above: Figure 5: Example of topological path concept application As for resident access, everyone has access to the entrances of Call Modules A and B (placed on the node ''Site'' and ''Block 1'').
Page 44 3.3.10 Summary table Below is a summary table of what has been written above regarding the main services offered by the IPerCom system and which concepts they are connected to (whether topological group or topological path): Topological Group Topological Path Contacts in address book of calling station with Access to resident entrances display.
Page 45 3.5 Security level of an IPerCom system To guarantee a high level of safety for an IPerCom system it is necessary to comply with what is reported below depending on the type of system model chosen during the configuration phase. The available system models are shown below: - “Villa kit (one-household)”, for single-family installations, - “Single Stair”, for small installations with a single stair,...
Page 46 CallMe Manager application booklet in the download area relating to IPercom 3.1.0. The building manager is not required to enter any administrator password by IperCom Installer Tools if the CallMe Manager application is used: even in the case of an unlocked system, in fact, no installer, other than the one authorized by the building manager, can make changes to the system.
Page 47 Managing an IPerCom system with the IPerCom Installer Tools and CallMe Manager applications therefore guarantees a high safety standard for the "Single Stair", "Multiple Stairs" and "Multiple Blocks" system types. “V )” ILLA KIT HOUSEHOLD SYSTEM In this case the configuration does not require the use of specific applications and the role of an administrator is not required.
Page 48 4 System installation The installation of the system can be carried out independently of the system configuration. All IPerCom devices are uniquely identified by their MAC address (physical address of the network interface connected to IPerCom, e.g. 00:1E:E0:01:02:03). The video door phone MAX, VOG , Basic and Ipercom Client 1060/43 are equipped with QR codes which are useful for acquiring devices in one of the configuration modes (see “Adding devices to the system using the...
Page 49 4.2 IP network structure Although no knowledge of IP networks and their configuration is required for the installation of the system, it is recommended to refer to the wiring diagram shown in the following figure: Figure 7: Recommended network topology The shown network structure is of the “tree type”, in which the switches are arranged on different levels of the network: if you use switches with 24 POE ports, just 3 levels are sufficient to reach the maximum number of 1000 devices.
Page 50 Only one IPerCom system can be installed on the same network infrastructure. The correct operation and IT security of the TCP-IP networks on which Urmet products are installed are the full responsibility of those who manage the network infrastructure (consisting of switches, routers, firewalls, etc.) and cannot be charged either to the products or to Urmet.
Page 51 4.4 Device/application firmware upgrade After the installation of the system, it is necessary to upgrade the firmware of all devices and the software of any applications. The upgrade files (available at www.urmet.com) allow having one of the officially released IPerCom versions on the system.
Page 52 In both above cases, the Switchboard and IPerCom Client applications, assuming they are each running on different PCs, are automatically upgraded (by IPerUpgrade or by Server 1060/1). From version 3.1 the update of the IPerCom Client application is performed correctly even if you do not have administrator rights on the PC.
Page 53 5 System commissioning The commissioning of a system essentially involves: • setting the date and time • the creation of the project, which also includes configuration • the application (distribution) of the configuration to the system; • securing the system To commission a system, the installer can use: •...
Page 54 The configurator is also available on Android tablets through the IPerCom Configurator app, to provide the installer with all the flexibility possible in the creation/change of system projects only. The securing of a system on IPerCom Installer Tools and MAX, VOG or Basic video door phone is done in different ways.
Page 55 6 Commissioning a system through IPerCom Installer Tools 6.1 Introduction to IPercom Installer Tools The IPerCom Installer Tools application can be downloaded from www.urmet.com in the download area (Software -> Technical software -> Communication -> IPerCom system). To access the software, download area, registration to the website is required.
Page 56 On IPerCom Installer Tools in the "Site" tab, it is possible to check the alignment status between the configuration relating to a project and the configuration present on the site (plant), highlighting the following possible situations: • site configuration aligned with that present in the project (same date and time); •...
Page 57 • connect to Urmet Cloud (after registering) to: o save projects on Urmet Cloud so as not to lose them (for example if the data on your PC is no longer available); o transfer the configuration of a project with IPerCloud apartments to a system; o use the CallMe Manager application to configure call forwarding;...
Page 58 Press the “Yes” button to start downloading the new version Figure 10: upgrade download in progress As soon as the upgrade is finished, the installation starts Upgrades can be optional or mandatory: in this case if the upgrade is not performed, it is impossible to start the application.
Page 59 6.4 Starting the Launcher Once the search for a more up-to-date version and the possible upgrade step have been completed, the following ''launcher'' is displayed: Figure 13: launcher di IPerCom Installer Tools Depending on the selected item, the drop-down menu of the above screen allows you to •...
Page 60 Press "OK" to select the network interface through which the PC is connected to the IPerCom system, as shown in the following screen: Figure 15: selecting the network interface button allows updating the list of available network interfaces. To know the IP and MAC addresses of the network interface through which you are connected to the IPerCom system, it is necessary to press the "Open Network Connections and Sharing Centre"...
Page 61 Depending on the firmware version detected on the various devices, 2 different cases can occur: • the system is updated to one of the officially released versions; • the system is not updated to one of the officially released versions. 6.5.1 System upgraded to the last version If the version installed on the system coincides with the latest released version (that is 3.0.0 version), you will see a screen of this type, where in bold (red box) the IPerCom version detected is shown...
Page 62 If the firmware versions of the various devices all coincide with those of an officially released version (''3.0.0'' in this case), the system is aligned with an officially released IPerCom version. When the "OK" button is pressed, the following screen is displayed: Figure 17: auto-detected version 3.0.0 This means that a version 3.0.0 of IPerCom has been detected (referred to the above example) and therefore the version of IPerCom Installer Tools to use is 3.0.0 version;...
Page 63 6.5.2 System not upgraded to the last released version If the version installed on the system does not coincide with the latest released version, a screen of this type is displayed: Figure 19: system not aligned to the latest version 3.0.0 The red box shows that an IPerCom 3.0.0 version has been detected on the system, but it is not the latest released one.
Page 64 In the figure above, the "Copy to Clipboard" button allows copying the displayed table to a text or Excel file whereas the "OK" button simply returns to the initial screen (in case the system is not upgraded to the latest version): Figure 20: IPerCom Installer Tools launcher In reference to a generic released IPerCom version, If the detected version does not correspond to the latest one, it is always possible to update the system to the latest release.
Page 65 The information shown is always the same as in the previous screen: you can immediately see that the “Version” column indicates the presence of devices not upgraded to the latest version 2.2.0 ("2.2.0?") and devices not upgraded to the latest version 3.0.0 ("3.0.0?"). In this case, it is necessary to upgrade the system to the latest released version: the "Download the latest 3.0.0 release"...
Page 66 Otherwise, the other applications are downloaded from the Internet and subsequently installed. For example, if you choose to work with IPerCom version 2.0.0, after pressing the "OK" button, the following screen will appear: Figure 23: request to install version 2.0.0 of IPerCom Installer Tools By pressing the "Continue"...
Page 67 6.7 First run of IPerCom Installer Tools If the detected IPerCom version is 3.1.0 or you want to work with an IPerCom 3.1.0 version, the situation below occurs: Figure 25: auto-detected or directly selected 3.1.0 IPerCom version In both cases, press the "OK" button to display the following screen:...
Page 68 The icon indicates that authentication will take place on the European Urmet cloud; if you press the mouse once on the icon in question, it turns into , indicating that the authentication will take place on the Chinese Urmet cloud. At the first start IPerCom Installer Tools automatically shows one or the other icon based on the first response received following a ping to the European and Chinese Urmet cloud.
Page 69 6.7.1 Urmet Cloud authentication Creating an account is done by pressing the “Create Account” button. The following window opens where it is necessary to fill in the fields marked with an asterisk: Figure 27: new account registration window After filling in all the fields correctly, the “Next” button is enabled and, after pressing it, the following screen appears: Figure 28: terms of service and privacy MT124-032N...
Page 70 At this point, after accepting the general conditions of use and the privacy policy, you can press the “Register” button to complete the registration, as confirmed by the following dialog box: Figure 29: registration successful The last step to do is to go to your email inbox and click on the account activation link. You are then transferred to a web page which confirms that activation was successful: Figure 30: account activated successfully Once the account has been activated, access to Urmet Cloud occurs by entering the username and...
Page 71 The "User" field must be filled in with the e-mail address entered during registration, just as the password is the one entered during registration. At this point, simply press the “LOGIN” button to authenticate on Urmet Cloud. Correct access is indicated by the following pop-up window: Figure 32: correct access to Urmet Cloud Figure 31 if you select the “Remember me”...
Page 72 After logging in, the screen that appears is the following: Figure 34: IPerCom Installer Tools screen after cloud authentication MT124-032N...
Page 73 Pressing the ''Urmet Cloud'' tab displays the screen shown below: Figure 35: screen of the Urmet Cloud tab after cloud authentication The Urmet Cloud section (red box) presents the "Cloud logout" and "Edit profile information" buttons, which respectively allow you to exit Urmet Cloud and modify the data entered when creating the account. The IPerCloud Management section instead concerns more directly the configuration of the IPerCloud mode and is explained in detail in the next paragraph.
Page 74 Figure 37: serial number of license bundle After entering the serial number and pressing the "PRE-ACTIVATE NOW" button, the following window is shown, through which the installer can accept (or reject) the license agreement relating to the IPerCloud software (End User License Agreement): Figure 38: viewing of the IPerCloud user license agreement It is required to select the "Accept"...
Page 75 If a license bundle has already been pre-activated, this is indicated by the following message: Figure 40: license bundle already pre-activated The "License bundle pre-activation history" button allows you to view all the license bundles already pre- activated with pre-activation date and time and serial number, as shown below: Figure 41: License bundle pre-activation history The “Show EULA text”...
Page 76 6.7.2 Urmet Cloud authentication not performed If you do not want to authenticate to Urmet Cloud, simply close the log in window that appears when IPerCom Installer Tools is started, as shown below: Figure 42: Cloud authentication rejected The following dialog box is shown, which summarizes the main benefits of connecting to the cloud: Figure 43: message following cloud authentication refusal MT124-032N...
Page 77 By pressing the “Yes” button the following screen appears, like the one when connecting to the cloud: Figure 44: IPerCom Installer Tools screen after not authenticating to the cloud The difference lies in the "Urmet Cloud" tab, which appears as shown in the following screen: Figure 45 ''Urmet Cloud”...
Page 78 6.7.3 Project and site IPerCom Installer Tools is based on the project and site concepts, highlighted in tab “Site”. The site represents the system you want to configure (meaning for system the entire network, devices and IPerCom software applications). The configuration of a site occurs by creating a project with the related configuration, for example definition of the system topology, addition of devices on the topological nodes, addition of apartments (IPerCloud or non-IPerCloud), definition of any address books and activation rules, creation of residents and not residents, configuration of system and call forwarding parameters.
Page 79 Having defined the concepts of project and site, it is now possible to explain in more detail the items in the screen below and how they work: Figure 46: IPerCom Installer Tools startup screen After starting the IPerCom Installer Tools application, all the tabs in the red box at the top are disabled apart from the “Site”...
Page 80 The “Storage location” option allows you to choose whether to save the project on your PC (icon ) or on the Urmet cloud (icon if selected). Saving to PC is the default option. If you are not logged in to Urmet Cloud, the icon for this saving mode is as follows: .
Page 81 6.7.5 Opening a project To open a project, you need to press the “Open” button. The following window opens where the projects associated with a specific site are displayed: Figure 48: opening already saved projects MT124-032N...
Page 82 The names of the sites are highlighted in blue and immediately below is the date and time of the last modification of the project (as shown in the red box). If you select with the mouse the date and time of the last modification of the project, the following screen appears: Figure 49: project associated to the site “Turin via Bologna 188/C”...
Page 83 The “Storage location” option allows you to choose whether to open the project from your PC (icon ) or from the Urmet cloud (icon if selected). Opening the project from PC is the default option. If you are not logged in to Urmet Cloud, the icon for this opening mode is as follows: .
Page 84 The .gz files are files previously generated on another PC by IPerCom Installer Tools with the “Export” button, after having opened the project to be exported. The .gz file thus generated must be copied to the PC where it is to be imported, so that the related project is available in IPerCom Installer Tools. The import operation (both for .gz and .sbz files) does not open the project directly but makes it available through the "Open"...
Page 85 6.7.6.2 Import a project on a version of IPerCom 2.1.1 or higher To import a project (already created) on an IPerCom version, you need to press the "Import" button. The following screen opens: Figure 51: “Import project” window Then press the button .
Page 86 The correct outcome of the operation is indicated by the following dialog box: Figure 53: import successful Through the "Open" button it will be possible to open the project just imported. 6.7.7 Deleting one or more projects To delete one or more projects, you need to press the “Delete projects” button. The following window opens: Figure 54: deleting one or more projects To select a project, simply press the left mouse button on the relevant date and time or on the name of the...
Page 87 To select all the projects of a site (see paragraph “Save backup”: how to create one or more backups of a project), simply press the left mouse button on the name of the site in question. To delete the selected projects, press the “OK” button. To cancel the operation, press the “Cancel”...
Page 88 Before doing this, a table with the information available in the ''Local status'' section (related to the project) with their meaning is shown: Fields Meaning System ID Unique identifier calculated from the date of creation of the configuration file of the relevant project. Configuration available Selected if the project has a configuration file, otherwise it is not selected.
Page 89 A table with the information available in the ''System status'' section with their meaning is shown: Fields Meaning System ID Unique identifier calculated from the date of creation of the configuration file of the relevant project. Global site ID Unique identifier to identify the site in the CallMe Manager application, if related support is enabled.
Page 90 6.9 How to use IPerCom Installer Tools for the configuration of a system Below is the description of the various steps to follow to configure a site (system) with IPerCom Installer Tools and how the application parameters listed in the previous paragraph vary. The most common ways to configure an IPerCom system are shown below (assuming the system has already been installed and wired).
Page 91 6.9.3 Mode 3: system installed but not configured, creation of configuration associated to the project by importing it from external file The various devices that make up the system have been installed and wired but have not been configured, that is the system has no configuration file. The steps to configure the system are described below: •...
Page 92 The “Open” button is active if projects have already been saved. The starting point is to create a new project: to do this it is necessary to press the “New” button. The following screen opens, where it is necessary to enter the name of the project (to be associated with a site): Figure 57: name assigned to the project Pressing the "OK"...
Page 93 The “Close site” and “Exit” buttons are used respectively to: • close the site (to which you want to associate a project) without exiting the IPerCom Installer Tools application; • exit the IPerCom Installer Tools application. After creating a new project but not yet the related configuration file, the “System ID” field is forced to zero (red arrow).
Page 94 To create a new configuration, it is necessary to press the “Create” button, which opens the configurator. The screen displayed is as follows: Figure 60: configurator start screen The steps to follow to create a new project associated to a configuration file are described in paragraph configurator.
Page 95 Then, after creating and saving a local configuration, the following screen is displayed: Figure 61: “Configuration" tab after creating the local configuration The newly created configuration file is named userconfig.ccf and the date of last modification and the date of creation (red box) are displayed on this file. The data in the blue boxes are not assigned a value because you are not connected to any system yet: their meaning will be explained below.
Page 96 The above is displayed in the following screen: Figure 62: "Site" tab with local configuration created At the bottom right (blue box) the last modification date of the configuration file is shown. If during the installation phase the configuration requirements change and at the same time you do not want to lose what was done before any requested changes, it is possible to make a backup of the project (and therefore also of the configuration) and then make the changes.
Page 97 The following screen appears: Figure 63: backup of a project The date and time in which the project backup is being created is highlighted (red arrow) and, if necessary, an identifying note can be associated with the same backup: in this way the installer creates a restore point of his project which he can access at any time if the changes made are no longer necessary.
Page 98 After creating the backup, if you press the “Open” button, a screen like the one shown below appears for the “Turin via Bologna 188/C” site: Figure 65: site with 2 projects (one of which is backup) In detail, the project identified with the note “Latest version” indicates the most recent version of the project.
Page 99 By selecting the most recent project (red box) or the backup (blue box), the following data relating to the selected object is displayed in the Quick Info section (red and blue box): Figure 66: project and related backup associated with the site “Turin via Bologna 188/C” In details: •...
Page 100 If a backup is selected and the “OK” button is pressed, IPerCom Installer Tools shows the following screen: Figure 67: opening a backup In detail, the following information is shown in the blue box: • the [BACKUP] identifier to indicate that the open project is a backup; •...
Page 101 The following figure shows the above: Figure 68: restore of a backup It is important, therefore, to keep in mind that: • the “Save” button saves the current project as latest version (regardless of whether the current project is the latest version or a backup copy) •...
Page 102 6.9.6 Connecting to the system and transferring the configuration Once the configuration associated with the project has been created and defined (backup or the most recent one), the next step is to connect to the system site and apply the newly created configuration to it, to configure the system.
Page 103 After pressing the "Connect" button, the Windows operating system can notify the user of the need to unlock the communication ports on the IP network used for communication between the IPerCom system and the IPerCom Installer Tools application. This operation is required for proper application operation.
Page 104 In the system site box, the system status is now available (ONLINE) (red box), as indicated by the relevant icon . The system ID is zero, since the system does not have a configuration yet: therefore, also the “Created on” and “Modified” fields are not assigned a value since they are linked to the creation date and the last modification of the configuration file.
Page 105 Now it is necessary to press the "Set Date/Time" button. Press "Yes" on the relevant dialogue box, date and time of the devices will be aligned with those of your PC. An additional dialogue box indicates that the operation has been completed correctly: Figure 72: date and time aligned with those of the PC When setting the date and time of the system, it is recommended to check that the date and time of your PC are correct.
Page 106 The green section shows schematically the condition of all the devices connected to the system. The example in question shows that: • the number of devices connected to the system (“Involved devices”) is 6; • the number of devices not in configuration is 6. The configuration status is not aligned (red section), as explained above.
Page 107 After pressing the “OK” button, the configuration associated with the project is applied on the plant site. Correct transfer of the configuration is highlighted by a progress bar which turns green once the transfer has taken place correctly, as shown below: Figure 75: local configuration transferred to the system The red boxes indicate that the configuration transfer has taken place correctly, i.e.: •...
Page 108 The "Show" button displays a table with the list of devices with the same configuration, their MAC and IP address and the last modification date of the configuration file, as shown below: Figure 77: list of devices with the same configuration Press the “Site”...
Page 109 The most important things to observe are the following: • the identifier of project and site are the same, because the 2 identifiers are calculated starting from the creation date of the same configuration file; • the configuration is aligned as the last modification date of the configuration file of the project and system site are the same;...
Page 110 Figure 79: creating the local site configuration from an external file The configuration files that can be imported have the ccf extension and, for example, can come from configurations created on MAX, VOG or Basic video door phone, exported to SD card and then saved on PC (for further details see paragraph “Exporting the configuration to an SD card”).
Page 111 After entering the correct password, the configurator opens the relevant project: Figure 81: configuration of the imported file After saving the configuration and exiting the configurator (see paragraph “How to save the configuration”), the way the configuration is transferred to the system is like the previous case. If you import a configuration file onto another PC and this configuration has already been applied on a system, it is absolutely forbidden to transfer it to another system.
Page 112 In both cases, the essential point is that the project associated with the system with which the first configuration was made is available and to make sure that the system has not been modified by the MAX, or Basic video door phone which have the configurator on board. In this situation, after opening the right project with the "Open"...
Page 113 The “Configuration” tab instead shows that the system devices have an older configuration than the project (as shown in the red box): Figure 83: “Configuration" tab with local configuration not yet transferred to the system The "Apply changes" button allows you to align the configuration: in fact (after applying the changes) the “Modified”...
Page 114 Figure 85: system devices aligned to the local configuration Now it is possible to save the project and then close it: the modification to the system has been correctly made through the same project that was used to configure the system for the first time. The configuration distribution procedure ends correctly when the number of devices with an old configuration or without configuration and the number of devices with a newer distribution are zero.
Page 115 6.11 System modified locally by MAX, VOG or Basic video door phone In the example of use described above, it may happen that the configuration of the system site is more recent than that of the project: this may occur if changes have been made to the configuration file through the MAX, VOG or Basic video door phone and the configuration associated to the project has never been changed (assuming you are starting from a situation where the project and system site were aligned).
Page 116 The “Configuration” tab instead shows that the system devices have a newer configuration than the project. In fact, the “Devices with a newer configuration” field is equal to 6, that is all the system devices: Figure 87: “Configuration” tab with system site with more recent configuration than the local site The "Apply changes"...
Page 117 Press the "OK" button at the end of the configuration distribution: the “Site” tab, the “Modified” field on the project and the system site have the same date and then the “Configuration aligned” field is selected: Figure 89: aligned configuration between project and system site The “Modified”...
Page 118 In systems with at least one Server 1060/1, when importing the configuration from the system site to the project, the only device recognised is one of the system Servers. Now enable the "Import" button, and press it to import the keys (installer and administrator password) as shown below: Figure 92: importing passwords After pressing the "OK"...
Page 119 6.12 Importing configuration files with different IDs After locally creating a project with a configuration file and transferring the configuration to the system, the situation is as follows: Figure 93: “Site” tab with project and system site aligned The system is aligned, as shown in the red boxes, that is the modification date of the local configuration and that of the system are the same.
Page 120 If you create a configuration file with an identifier other than 1689259875 (which is the right system identifier), i.e. with a creation date other than ''16/06/2023 16:52:42'', and if you are not yet connected to the system (which has the same identifier as the local site “1637772037”), the following situation occurs: Figure 94: “Site”...
Page 121 The above error also occurs if the project configuration is taken from an external configuration file saved on a PC and you try to connect to a different identification system. If by mistake the project has been deleted and you want to restore it from the system site, you can create a new project with a zero identifier (that is without any configuration file): Figure 96: “Site”...
Page 122 The following screen is displayed: Figure 97: “Site” tab with connection to the system and project identifier equal to zero Connection to the system site may require the administrator password if the system is blocked. The system ID 1689259875 corresponds to that of the first configuration. Now move to the “Configuration” tab, the following screen is displayed: Figure 98: “Configuration”...
Page 123 In this case the "Create" button is frozen because any local configuration created would have a different identifier from the one already present on the system site and could not be transferred. The quickest way to restore a project configuration compatible with the system site configuration is to press the "From system"...
Page 124 6.13 Systems with two configurations Once the system configuration has been completed, it is good to lock the system (see section “System block”): in this way the installer can no longer have access to the system configuration except by means of the administrator password.
Page 125 6.14 System remote access All the operations described above can also be carried out with the system in remote mode, that is without being physically connected to the system with your PC. This operating mode is possible if the following conditions are met on the system to which you need to connect remotely: •...
Page 126 EMOTE ACCESS THROUGH ALREADY EXISTING PROJECT WITH IDENTIFIER SAME AS THE REMOTE SYSTEM SITE After starting IPerCom Installer Tools and opening the correct project with the "Open" button, the screen that appears is the following: Figure 102: project with the same identifier as that of the plant site (remote) At this point, in the red section of the above figure: •...
Page 127 To complete remote access, only the installer password must be entered. The "System id" field is already filled in and cannot be changed and is the same as the system id of the project previously opened. If the installer password entered is incorrect, the following error message appears: Figure 104: error message in case of incorrect installer password After pressing the "OK"...
Page 128 If remote access has not been enabled, after entering the password and / or system identification, the following error message appears: Figure 106: remote access not enabled by configurator From version 3.1.0 of IPerCom it is no longer possible to connect remotely to a system with a project whose identifier is equal to zero.
Page 129 6.15 Other functions of IperCom Installer Tools The other functions of IPerCom Installer Tools concern the “Security”, “Date/Time”, “Diagnostic”, “System Log”, “System backup”, “Maintenance” and “Urmet Cloud” tabs. The functions relating to these tabs are enabled based on the following events: •...
Page 130 6.15.1 “Urmet Cloud” tab The “Urmet Cloud” tab allows you to authenticate on the Urmet cloud. Authentication on Urmet Cloud allows you to: • save your projects on a virtual storage space, • transfer a configuration with IPerCloud apartments to a system, •...
Page 131 In the Urmet Cloud section the "Login/Register" button allows you to create an account for registering with Urmet Cloud or to use one already created previously. If you have never accessed Urmet Cloud, the screen that appears is the following: Figure 108: access to Urmet Cloud via account creation or login The “CREATE ACCOUNT”...
Page 132 6.15.1.2 Urmet cloud access performed The “Urmet Cloud” tab appears as shown below: Figure 110: access to the Urmet cloud completed The Urmet Cloud section (red box) shows the user with whom access was made and shows 2 buttons that allow you to: •...
Page 133 6.15.1.3 Urmet Cloud access and opening of a project After opening a project saved on your PC or on the cloud, the “Urmet Cloud” tab appears as shown below: Figure 111: access to the Urmet cloud performed with the opening of a project The Urmet Cloud section has not changed compared to before.
Page 134 6.15.1.4 Urmet Cloud access, opening of a project and connection to a site After connecting to the system (with the configuration aligned with that of the project), the "Urmet Cloud" tab appears as shown below: Figure 112: access to the Urmet cloud performed with the opening of a project and connection to the site The Urmet Cloud section has not changed compared to before.
Page 135 6.15.1.5 CallMe Manager support enabled with or without IPerCloud apartments In IPerCom systems without IPerCloud apartments, the use of the CallMe Manager application is optional and is recommended for those medium/large home topologies where the figure of the building manager is required.
Page 136 The Site authorization management section concerns the possibility of: • transfer the site from an installer to a condominium administrator for configuring the call forwarding function; • transfer the site from one installer to another installer. For further details on the 2 points above, see the Site authorization management paragraph.
Page 137 From version 3.1.0 it is possible to transfer ownership of the site from an installer to a building manager or to another installer even if CallMe Manager support is disabled. 6.15.1.6 Site authorization management If CallMe Manager support has been enabled from the configurator, the Site Authorization Management allows to: •...
Page 138 It is necessary to enter the e-mail address that the building manager previously communicated to the installer: Figure 117: building manager email entered Pressing the “Handover to Building Manager” button, an invitation e-mail is sent to the building manager and the correct outcome of the operation is confirmed by the following dialog box: Figure 118: correct outcome of the invitation to the building manager The content of the email sent to the administrator appears as follows: Figure 119: content of the email sent to the building manager...
Page 139 It is necessary that the e-mail address communicated by the building manager is associated with an Urmet Cloud account through registration on the CallMe Manager application. If this is not the case, from the content of the same e-mail it is possible to download the CallMe Manager application and the related manual, then install the application on your PC and create an Urmet Cloud account (using the e-mail address communicated to the installer).
Page 140 HE BUILDING MANAGER ACCEPTS THE INVITATION In the invitation email the building manager presses the link highlighted in blue at the bottom of the content of the same email to confirm the site transfer operation: Figure 121: link to accept the transfer of ownership of the site The installer receives a notification via email that the building manager has accepted the transfer of ownership of the site.
Page 141 When an installer creates a site, he is also the building manager and therefore, by authenticating on the CallMe Manager application with the same credentials with which he logged in to IPerCom Installer Tools, he can view the same site. After the transfer of ownership to the building manager, viewing on the CallMe Manager application will no longer be possible and the installer can only make changes to the configuration and distribute them to the system via IPerCom Installer Tools.
Page 142 HE INSTALLER CANCELS THE INVITATION If the installer presses the “Cancel site transfer” button (Figure 120), the following window appears: Figure 123: cancel of the transfer The “Cancel site transfer now” button allows you to cancel the transfer request (only if the building manager has not already clicked on the site acceptance link).
Page 143 Figure 126: message in the event of connection to a system by an unauthorized installer However, it could happen that another installer needs to make changes to the system configuration. To do this, the installer who created the site can transfer it to another installer via the “Hand over site to another installer”...
Page 144 ITE NOT YET TRANSFERRED TO A BUILDING MANAGER If the site has not yet been transferred to a building manager, the installer who created the project is also the site building manager: this means that the installer, by authenticating on the CallMe Manager application with the same credentials with which he logged in to IPerCom Installer Tools, is able to view the site.
Page 145 For example, if “installer_1_urmet” transfers the building manager and installer properties of the site to “installer_2_urmet” and “installer_2_urmet” accepts the invitation, when “installer_1_urmet” connects to the same system, the following appears in the “Urmet Cloud” tab (box in green): Figure 130: not authorized installer As you can see, “installer_1_urmet”...
Page 146 This means that “installer_2_urmet” can make changes both through the IPerCom Installer Tools application (to modify the system configuration) and through the CallMe Manager application (to configure the call forwarding function). However, if you press the “No” button in Figure 128, the procedure remains identical to what is reported above with the only difference that the new installer will not have building manager functions.
Page 147 ITE ALREADY TRANSFERRED TO A BUILDING MANAGER If the ownership of the site is transferred to the building manager, this means that the installer has completed the configuration part of the system using IPerCom Installer Tools and consequently the building manager can begin to configure the call forwarding function via the CallMe Manager application.
Page 148 6.15.1.7 IPerCloud Test Mode The IPerCloud test mode is useful to check that the call from any calling station arrives correctly at an IPerCloud test apartment (that is, the call arrives to CallMe app). In this way the installer avoids to purchase specifically a license bundle to carry out installation tests (thus also avoiding the procedure of pre- activating the license bundle, transferring the site to a building manager, activating the license bundle, assigning a license to an apartment, and printing the letter).
Page 149 The fundamental steps for carrying out the test mode with the CallMe app will be shown below. For all more detailed information relating to the use of the CallMe app see the related booklet on site www.urmet.com. To use the CallMe app, simply log in with the same account used on IPerCom Installer Tools. Once logged in, this screen appears: Figure 137: CallMe app home page Pressing the “Add a place”...
Page 150 Press the “Scanning the QR code” button to start the QR code reader application. Then press the “IPerCloud Test QR Code” button displayed on IPerCom Installer Tools. The following screen appears: Figure 139: scan of QR code in test mode MT124-032N...
Page 151 Then with app CallMe scan the QR code displayed on the PC where the IPerCom Installer Tools application is installed. After scanning the QR code, the following screen will appear on your smartphone/tablet to indicate that the place has been added correctly: Figure 140: place added The default name given to the place is “IPerCloud Test”...
Page 152 6.15.2 Security The “Security” tab allows you to: • modify the installer password, (for example if the administrator decides to change installer or if the installer can no longer remember his/her password); • block the system, that is enter an administrator password after the configuration step is finished. As described in paragraph “Security level of an IPerCom system”, there are two access password levels:...
Page 153 The installer password change does not require to enter the old password. For proper security management of a system, the installer password must not be known to the system administrator and similarly the administrator password must not be known to the installer. After locking the system, you can perform the reverse operation, that is unlock it.
Page 154 After entering the new password and pressing the "OK" button, it is possible to check in real time that the installer password change process is correctly performed. Once the procedure is complete, the following screen is displayed: Figure 144: installer password modification successfully performed The installer password update does not affect devices such as Lift Interface, Relay Actuator, Key Readers, RTSP Cameras, IPassan Controller and iPerTAlk Server.
Page 155 A screen is displayed where it is possible to enter the password: Figure 146: entering the administrator password After entering the new administrator password and pressing the "OK" button, it is possible to check in real time that the administrator password entering process is correctly performed. Once the procedure is complete, the following screen is displayed: Figure 147: system blocked The “Security Status”...
Page 156 6.15.2.3 Unlocking the system If the IPerCom system is blocked, it is necessary to press the “Unlock" button to unlock it: Figure 148: how to unlock the system It is possible to check in real time that the system unlocking process is carried out correctly. Once the procedure is complete, the following screen is displayed: Figure 149: unlocked system The “Security Status”...
Page 157 6.15.3 Date/Time The “Date/Time” tab allows you to: • set date and time of the PC on the IPerCom system; • obtain the IPerCom system date and time. 6.15.3.1 Configuring date and time from PC If you want to apply the date and time from PC to the IPerCom system, press the "Set date and time" button (red arrow): Figure 150: “Date/Time”...
Page 158 For proper system operation, the date and time of the IPerCom system must be correctly configured. On a system installed but not configured, before applying the configuration associated to the project to the system, it is necessary to set the date and time with the "Set Date/Time" button, as explained in paragraph “How to set date and time on the system”.
Page 159 Now it is possible to check the status of the procedure in progress in real time: Figure 154: date/time request in progress At the end of the procedure, a screen with the date and time detected and any difference with the date and time of the PC (in seconds) is displayed: Figure 155: date/time request completed If the date and time difference between PC and system is greater than 60s, IPerCom Installer Tools...
Page 160 If “Request Date/Time from the system” button is pressed on a system where date and time have not yet been configured, the procedure shows the following message: Figure 157: Error to obtain dates and times from the system The system must have configured date and time to request them correctly. To set the date and time correctly, press the "Set Date/Time"...
Page 161 6.15.4 Diagnostics The “Diagnostic” tab allows you to easily understand if all the devices in the system are working regularly or if there are problems of various types (connection, firmware alignment or other). The screen displayed is as follows: Figure 158: “Diagnostic” tab The following information is detailed for each device: Column Name Meaning...
Page 162 The icons in the red box are active depending on the selected device. The operation of each icon is explained below. Icon Name/Meaning Get UPS info: It allows you to obtain information on the UPS (uninterruptible power supply) status, including the percentage of battery charge and autonomy time. The button is enabled only if the selected device is a Server 1060/1.
Page 163 For a correct display of the csv file, it is necessary to open Excel, go to the “Data” tab, press the “From text” icon, select the exported file and press "Import". You must now select "65001" as the character encoding: Unicode (UTF-8)" and the character "comma" as text delimiter. Devices Lift Interface, Relay Actuator, Key Reader, IPassan Controller and iPerTAlk Server do not recognise the operating mode "with server"...
Page 164 6.15.5 System Logs The “System Logs” tab allows you to record in a log a set of events related to the operation of an IPerCom system. To display the complete log with all its functions, it is necessary that at least one Server 1060/1 is present on the system.
Page 165 The screen displayed (after a set of processing) is as follows: Figure 161: displaying the System Logs (static mode) The figure above shows the static operation mode of the System Logs, i.e. a static representation of the events is displayed over a time interval of one week from the current date. Press the button (red arrow), to update the System Logs to the current time instant and download it again from the selected source.
Page 166 When the System Logs is displayed for the first time in static mode, in the “Site” tab the item “System logs available offline” is selected (red arrow): Figure 162: "Site" tab with System Logs saved locally If this item is selected, the next time IPerCom Installer Tools is started it is possible to consult the system logs by simply opening the project, even if you are not connected to the system (and therefore even if the configurations of the project and site are not aligned).
Page 167 To display the System Logs saved locally (backup), the same System Logs must have been displayed at least once in online mode: the backup, in fact, is created as soon as the static System Logs operation mode is activated. Every time the "Open System Logs" button is pressed (except the first time) in static mode, the local System Logs is downloaded again.
Page 168 6.15.5.1 How to filter System Logs: basic and advanced filters The basic and advanced filters (Search in System Logs section in the red box) work in the same way regardless of whether the source of the System Logs is the server or a backup saved according to what was previously written.
Page 169 ALLS The"Calls" event category includes all types of calls between the various system devices (including auto- on): for each call the source device (from which the call starts), the destination device (to which the call arrives), the possible response and the end of the call are displayed in detail. The name of each device is preceded by the name of the topological node where the device has been placed.
Page 170 IAGNOSTICS The event category "Diagnostic" indicates for each device if it is no longer reachable and when it is reachable again. The name of each device is preceded by the name of the topological node where the device has been placed. An example is given below: Figure 170: System Logs filtered by diagnostics LARMS The "Alarms"...
Page 171 Each event category can be further filtered in the Advanced Filters section, which can be enabled by pressing the "Configure” item, as shown in the figure: Figure 173: advanced System Logs filters The next screen contains a drop-down menu with the various categories of events and, depending on the type of event selected, the relevant filter, as explained in more detail below.
Page 172 A screen opens where it is possible to navigate the topological structure of the system and generally choose a call station for the source, as shown below: Figure 175: navigation of the system topological structure The called device is selected in the same way. After pressing the "OK"...
Page 173 By selecting one or more of the access points listed and after pressing the "Apply filters" button for the Access point activities event category, only the events related to the opening of the selected access points are displayed. ILTER ON USER ACTIVITY EVENT If, in the Category drop-down menu, the event type "User activities"...
Page 174 LARM EVENT If, in the Category drop-down menu, the event type "Alarms" is selected, the following is displayed: Figure 179: advanced filter for alarm event By selecting one or more types of alarms among those listed and after pressing the "Apply filters" button for the “Alarms”...
Page 175 6.15.6 System backup The "System backup" tab allows you to periodically save the system configuration (backup) manually or automatically. The function is useful if: • after making changes to the configuration, it is necessary to restore the situation before the changes;...
Page 176 ANUAL BACKUP The "System backup" section (in red) allows you to manually save the system configuration on your PC ("Save all data" option by default). Press the "Apply" button to open a window through which you can choose the path where to save the configuration on your PC.
Page 177 The "Apply" button allows you to save the set changes. Whenever you need to remove the USB stick from the Server 1060/1, you must remove it using the "Eject" button. Even in the case of automatic backup, the generated file has an "sbz" extension and name with preset date and time.
Page 178 6.15.7 Maintenance The “Maintenance” tab is useful if it is necessary to: • switch from a system with server to a system without server; • import a new configuration to the system; • restart all system devices (useful function if one or more devices (not in configuration and not aligned with the IPerCom version of the system) are connected to the system;...
Page 179 If the number of devices, apartments, and users is less than or equal to 1000 and you want to switch to a system without Server 1060/1, the operations to do are as follows: • disconnect the various servers from the system; •...
Page 180 Press "OK", to restart the devices in the system so that they operate in "without server" mode. At the end of the operation (after entering the administrator password if the system is blocked), the following message is displayed: Figure 186: mode without server set correctly Now the last step is to enter the configurator, delete the various servers from the configuration and distribute it again (see paragraph “The...
Page 181 DDING A SERVER TO THE SYSTEM To add a 1060/1 Server (not configured and with default settings) to a system in ''without server'' mode, it is necessary in a first step to connect only the 1060/1 Server to the PC (not to the IPerCom system) and perform the following operations in the order shown.
Page 182 To do this it is necessary to press the "Erase configuration on all devices" button: Figure 188: “Maintenance” tab - deleting the configuration The following pop-up window is displayed: Figure 189: request to delete the configuration from the system devices Deleting the configuration will reboot the devices.
Page 183 Press the "OK" button to restart the application. Now it is possible to configure again the site creating a new project or opening another project and apply the configuration. If the project associated to the system whose devices have been brought back to the factory configuration is opened again, IPerCom Installer Tools shows a dialogue box that warns installer that configuration associated to this project (saved through backup) will be imported in automatic way.
Page 184 As written in the paragraph Device/application firmware upgrade, a warning message indicating the presence of misaligned devices appears on the video door phones, Switchboard, IPerCom Client and IPerCom Installer Tools applications. The message is like the one reported below: Figure 192: Presence of devices with UPTK versions not aligned The fastest way to bring the system back to normal operation involves: •...
Page 185 MAX, VOG7 NABLING DISABLING ACCESS TO OM CONFIGURATION FROM A ASIC VIDEO DOOR PHONE THAT HAS NOT BEEN CONFIGURED YET Access to the IperCom configuration by MAX, VOG7 or Basic video door phones not yet configured and connected to the system is enabled (default value). To disable access to the IperCom simply press the "Prevent access"...
Page 186 6.15.8 Devices not aligned to the same IPerCom or software development platform (UPTK) version The possible presence of a misalignment between the UPTK versions of the devices and/or software applications is reported by the IPerCom Installer Tools application, which compares it with its own local UPTK version.
Page 187 CASE 1 The misalignment is reported by IPerCom Installer Tools via the dialog box shown below: Figure 195: UPTK version misalignment reported on IPerCom Installer Tools By pressing the "Status" button, the devices (or device) whose UPTK version (for example 8.22) is not aligned with that of IPerCom Installer Tools (for example 8.31) are displayed: Figure 196: list of devices whose UPTK version is not aligned with the local version By pressing the “OK”...
Page 188 CASE 2 The misalignment is reported by IPerCom Installer Tools via the dialog box shown below: Figure 197: UPTK version misalignment reported on IPerCom Installer Tools By pressing the "Status" button, the devices (or device) whose UPTK version is not aligned with that of IPerCom Installer Tools are displayed, in the same way as written in the previous case.
Page 189 CASE 3 The misalignment is reported both by the software application and by IPerCom Installer Tools in the same ways described in the previous points. For example, if the Switchboard application has not been updated to the latest IPerCom version present on the system, after connecting to the system itself, the IPerCom Installer Tools application displays the following dialogue window: Figure 198: UPTK version misalignment reported on IPerCom Installer Tools By pressing the “OK”...
Page 190 According to what is written above, it is therefore of fundamental importance: • add new devices to a system only after having updated them to the correct IPerCom version using the IPerUpgrade application for Windows operating system, available with the relevant manual on the website www.urmet.com;...
Page 191 In this case after pressing the “Status” button, simply press the “Update device list” button, as shown below: Figure 200: “Update device list” button The following message is shown with the request to restart both IPerCom Installer Tools and the system: Figure 201: request to restart the system By pressing “Yes”, all the system devices are restarted and at the end of the operation the following message is displayed:...
Page 192 6.15.8.1 IPerCom Installer tools application not aligned to the same IPerCom or software development platform (UPTK) version If a PC with a version of IPerCom Installer Tools whose version is not updated to that of the rest of the system is connected to a regularly functioning system, as soon as you connect to the system IPerCom Installer Tools signals the misalignment via the dialog box below: Figure 203: UPTK version misalignment reported on IPerCom Installer Tools By pressing the "Status"...
Page 193 7 The configurator The configurator allows defining the system topology, associating the various devices to the system nodes, creating directories, activation rules, access control rules, residents, and non-residents, setting the operating mode of the system. The configurator is integrated in both IPerCom Installer Tools and the MAX, VOG or Basic video door phones and the operating mode is similar.
Page 194 The configuration creation (and thus the configurator) allows you to: • define the system topology, • add IPerCloud apartments (if present), • add the devices on the topological nodes of the system, • customize the system (assigning appropriate names to apartments, topological nodes, devices, etc.), •...
Page 195 The name of the site is the one that will then appear in the IPerCom Installer Tools application in the "Site" tab in the relevant "Site Name" field, after aligning the project configuration with that of the system. To enter the name of the project and the installer password use the alphanumeric keyboard present in the configurator.
Page 196 Once all the fields have been filled in and the desired model has been selected, by pressing “OK” a basic project will be created and the “Topology” tab will be displayed: Figure 207: “Topology” tab of a “Multiple Stairs” configuration The shown screen is related to the case in which the Multiple Stairs topology was chosen during the project creation phase.
Page 197 it is possible to identify three zones: • an upper part (in yellow), showing the current topological node; • a central part (in red), with a list of all the topological nodes that derive directly from it; • a lower button (in blue), to add new nodes to the topology. Two buttons are available for the topological nodes: •...
Page 198 If the presence of a 1060/1 Server is requested, the configurator signals its lack in the configuration via a message when saving the configuration itself (see paragraph How to save the configuration): Figure 209: message on configurator in the absence of Server 1060/1 If the 1060/1 Server is added to the configuration but is not physically installed on the system, during the saving phase the configurator allows you to save the configuration but when you try to apply it via IPerCom Installer Tools the following message is shown:...
Page 199 In the context module within “Topology” it is possible to access 4 configuration panels that allow you to make changes related to the current node: • “Settings”, that allows accessing the node properties; • “Devices”, that allows adding/modifying/removing devices; • “Address books”, that allows creating the address books used by above all by apartment station;...
Page 200 Export The tab allows you to: • export a file in html format that contains a summary of the topology and the devices that make up the system; • export a file in xml format useful for the integration of the IPerCom system with the IPassan access control system (for further details see “APPENDIX O: IPassan integration with IPerCom”).
Page 201 Transition from one system model to another is usually required in the following cases: • if the model was not chosen correctly during the creation phase of the project; • if the system layout greatly evolved after the project was created. For example, if you have a "Single Stair"...
Page 202 7.1.1.2 Single Stair systems The single stair systems are characterised by the fact that all the apartments are arranged on the floors belonging to a single stair. This mode is also suitable for two-family systems. On this system it is possible to have any number of apartments and floors on which IPerCom devices will be placed.
Page 203 7.1.1.3 Multiple Stairs systems If the system topology consists of several stairs within the same block, a Multiple Stairs configuration can be created. In this case a block is automatically created with one stair, one floor and a single apartment. Figure 217: “Topology"...
Page 204 7.1.1.4 Multi Block systems The last type of plant model supported by the configurator is the Multi Block one, that allows creating a project with any number of blocks/stairs/floors/apartments. The selection of Multi Block as plant model automatically leads to the creation of a site without blocks, as shown in the following figure: Figure 219: “Topology"...
Page 205 The configurations are created and edited using the IPerCom Configurator application, also known as the configurator. The configurator consists of three main components, shown in the following figure: Figure 221: Main components of the configurator It is possible to see: •...
Page 206 7.1.2 Adding devices Once the topology has been defined, it will be possible to add the devices in the system configuration. There are 3 different ways to configure the devices, depending on whether you are connected to the system via PC. In any case, regardless of the chosen installation mode and topology, it is necessary to associate each device to a topological node, bearing in mind that: •...
Page 207 “A ” DDING DEVICES TO THE CONFIGURATION THROUGH THE DD NEW DEVICE BUTTON O CONNECTION TO THE SYSTEM The "Topology" tab and the relative "Devices" tab appear as shown below: Figure 222: screen page through which to add devices without being connected to the system Non-configured devices cannot be considered (red box) because you are not yet connected to the system and consequently the "Show new devices"...
Page 208 Now simply press the "Add new device" button. A list of all devices that can be added to the apartment node is displayed: Figure 224: list of device categories that can be added on the apartment node To add a MAX video door phone, simply press on “Apartment stations” item. The following screen opens: Figure 225: list of apartment stations MT124-032N...
Page 209 To add a MAX video door phone, simply press on “Video door phone 7’’ MAX 1717/31-32-33-34-41”. The following screen opens: Figure 226: MAX video door phone configuration Fill in the fields in the red box to configure the device in question (in this case the MAC address and a name to associate with the video door phone).
Page 210 For the configuration of the other devices, it is therefore necessary to: • position on the node where you want to add the device (through the navigation module); • press the "Add Devices" button; • choose the device to be added from the list of categories; •...
Page 211 Non-configured devices can be considered as you are connected to the system and consequently these will be displayed when pressing the "Show new devices" button (red box): Figure 229: list of devices connected to the system and not yet configured When displaying the list of devices to be configured, the "Devices"...
Page 212 The same configuration page appears as in the first mode, with the only difference that the MAC address field is already filled in: Figure 230: MAX video door phone configuration with MAC address already filled in Once the MAX video door phone has been configured, press the "OK" button to return to the list of devices to be configured: Figure 231: devices still to be configured As you can see, the "Non-configured Devices"...
Page 213 The "Show configured devices" button instead shows the devices configured on the topological node in question: Figure 232: Adding a MAX video door phone to an apartment If there are devices that cannot be configured on the topological node where you have positioned, they appear in light grey and the relevant button is disabled.
Page 214 "A " DDING DEVICES TO THE CONFIGURATION USING THE DD NEW DEVICE BUTTON WITH CONNECTION TO THE SYSTEM This procedure is like the first one with the only difference that in the device configuration phase for entering the MAC address, it is useful to use the “..." button, as shown in the figure in the case of a MAXvideo door phone: Figure 233: MAC address entry when connected to the system By pressing the “...”...
Page 215 Simply select the device to add, identifying it through its MAC address, and it is filled in automatically. If you are connected to a system with one or more Servers 1060/1, they must be configured if you want to save the system configuration. Otherwise, it is impossible to save the configuration and the configurator shows the message below: Figure 235: message when Servers 1060/1 are not configured This is to avoid starting a system with Servers 1060/1 connected but not configured: the concerned...
Page 216 On the nodes below the stair node (floors and apartments), where a Gateway IPerCom-2Voice 1083/59 has been placed, it is not possible to add any device; the "Add new device" button on these nodes shows the following screen: Figure 237: Adding devices on nodes below a stair with Gateway IPerCom-2Voice On the stair node where the Gateway IPerCom-2Voice was added, it is possible to add new devices.
Page 217 The 2Voice apartments that are thus created under the stair, where the gateway is located, have a different setting page than the IPerCom apartments: in addition to the “Name“, “Topological Code”, “Numerical Code” or “Logical Code” fields (if the system is set in numerical or logical mode), the “2Voice Code” field also appears: Figure 239: apartment 2Voice code setting This field is used to set the physical code of the 2Voice user: the allowed values range from 0 to 126.
Page 218 By entering an allowed value and pressing ‘’OK’’, the last 7 dip-switches in the image below are automatically positioned on the right position, to represent the previously entered number in binary format. Having entered 100, the figure shown below appears: Figure 241: Binary code of the entered code It is also possible to act directly on the dip-switches (pressing on the related image) to set the desired 2Voice code.
Page 219 7.1.2.2 Adding a Lift Interface 1060/37 on a stair node Add a Lift Interface 1060/37 to control the lift control panels to enable the ascent only to the defined floors according to the apartment called. The interfacing to the lift control units is typically made by changing the status of one or more inputs of these control panels through control relays.
Page 220 Figure 243: Lift Interface setting - Mode selection 7.1.2.2.1.1 Creating the path The lift interface is equipped with 24 relays that can be configured through the IperCom Installer Tools configurator, so that they close in response to an event occurring in the system. A typical case is to enable the visitor who accesses the residential complex to use a lift to access only the floor, or the apartment according to the operating mode, where the person with the selected name lives.
Page 221 To create a path, it is necessary to select an access available in the system from the list. The types of devices that can be selected are: • Call Module 1060/12-13-17-18-23, • Modular Calling Station with 1060/48, • Entry panels 1060/21-33-34-71-74-75, •...
Page 222 7.1.2.2.1.3 Assignment in Floor mode Since the assignment operation is carried out through the settings of each Floor concerned, it is necessary to first select the desired floor, choose the lift interface to configure and finally enable the relays to be activated.
Page 223 In a very active system, where several paths have been configured, each with its own activation time, the relay opening times may overlap, for example: • Path 1 o From the main entry panel to the lift. o 1st floor o Activation time: 5 minutes.
Page 224 7.1.2.2.1.4 Assignment in Apartment mode In this case the assignment operation is carried out through the settings of each apartment, it is necessary to first select the desired floor, choose the lift interface to configure and finally enable the relays to be activated.
Page 225 7.1.2.2.2 Access for non-residents It is also possible to configure access paths for non-resident users. In the users section choose a "Not residents" user in case he/she is already present in the system, or press "Add" to create a new one (to add a non-resident user, see paragraph residents).
Page 226 Tick the "Customise" box to enable the relays to every single path created between the lift interface and the various devices. Figure 251: Lift Interface assignment - Enabling non-resident user relays (part 2) 7.1.2.2.3 Lift interface-RS485 mode The Lift Interface-RS485 type allows interfacing the device with a possible third-party controller. In this case the lift interface will only communicate the event occurred in the system to the third-party controller that will perform the actions programmed according to the above event.
Page 227 7.1.3 System IPerCom in IPerCloud mode The creation of the configuration of IPerCom systems in IPerCloud mode must be done exclusively starting from IPerCom Installer Tools (with authentication on Urmet Cloud and CallMe Manager support enabled) and not from the video door phones that integrate the configurator (VOG , MAX or Basic).
Page 228 ONFIGURATION • calling stations of type Entry Panel 1060/21; • a maximum of 20 IPerCloud apartments. If in the IPerCom system in IPerCloud mode it is instead required to have: • at least one calling station other than Modular Calling Station with 1060/48 or Entry Panel 1060/33- 34 or Entry Panel 1060/21, •...
Page 229 If the 1060/1 Server is added to the configuration but is not physically installed on the system, during the saving phase the configurator allows you to save the configuration but when you try to apply it via IPerCom Installer Tools the following message is shown (within 5 minutes): Figure 253: message on IPerCom Installer Tools in the presence of Server 1060/1 added on the configurator but not present on the system In addition, the VOG , VOG...
Page 230 7.1.3.2 How to set up an apartment in IPerCloud mode To set up an apartment in IPerCloud mode it is necessary to select the relevant node and the "Settings" tab, as shown below: Figure 256: apartment in IPerCom mode The section in red shows that the IPerCloud mode is disabled for the selected apartment. To enable it (and therefore create an IPerCloud apartment) simply press on the "DISABLED"...
Page 231 By choosing the "ENABLED" item, the selected apartment becomes an IPerCloud apartment. This is highlighted by the relevant icon in the left navigation module (red arrow): Figure 258: apartment in IPerCloud mode The “Call forwarding URI” item is no longer visible as the use of the CallMe Manager application is required to configure the IPerCloud apartment and the parameter in question can only be set if this application does not It's requested.
Page 232 By pressing the "Yes" button in the next dialog box, the apartments present in the topological group of the "Block 01" node are automatically set as IPerCloud apartments, as shown below: Figure 260: automatic acquisition of IPerCloud mode By pressing the "Reset" button and then "Yes" in the subsequent dialog box, the IPerCloud apartments present in the topological group of the "Block 01"...
Page 233 7.1.4 Contacts In the "Topology” tab, through the “Address Books” item, it is very easy to create: • the contact list for video door phones with address book (most common use), • the contact list for IPerTalk extensions; • the contacts associated with T1 and T2 buttons of the Miro door phone 1160/3 and T1, T2 and T3 buttons of the video door phone 1761/6 (most common use);...
Page 234 What has been written for the video door phone 1717/3x-4x also applies to all other video door phones with address book. To create contacts on the video door phone 1761/6, refer to what stated for the Miro door phone 1160/3, with the only difference that in addition to the T1 and T2 buttons there is also the T3 button.
Page 235 If you want to call only the MAX video door phone present in the dental practice from the apartment with topological code "0101010102", add a contact in its address book having that device as target. If, instead, you want to make both the MAX video door phone and the Miro door phone in the dental practice ring, the contact must be the set of devices in the dental practice, that is in the topological node in which they are placed.
Page 236 To create the new contact, press the “Add new contact" button. The following page is displayed: Figure 263: New contact creation screen The following shows the meanings of the four fields: Name Name of contact Scope Scope of the contact. This shows the node in which you are creating the contact;...
Page 237 The T1 and T2 buttons refer to both the Miro door phone 1160/3 and the video door phone 1761/6, while the T3 button refers only to the video door phone 1761/6. Below is an example on how to use these items. The CallMe option, if selected, allows you to view the contact on the CallMe app as well.
Page 238 Now, point to apartment "0101010101" with the navigation unit on the left and add the target, selecting it from one of the items suggested on the right: Figure 265: Target selection As previously mentioned, you can select only one device of the dental practice as target (i.e. only the MAX video door phone or the only Miro door phone) or both devices referred to the concerned apartment.
Page 239 As shown in the figure, the “Visibility Filter” field is populated with the list of devices that could use the contact: the type of device already automatically selected is “Video door phone with address book (VDP)”. Since you want to make the contact visible in the address book of the MAX video door phone of the apartment "0101010102", in this case simply press the “OK”...
Page 240 In this manner, the new contact “Dental Practice” will appear in the address book of the MAX video door phone of apartment "0101010102" and can call it or start a chat with it In the list of contacts, the buttons in the “Edit” and “Delete” columns can be used to edit or delete data for each contact, respectively (via confirmation pop-up).
Page 241 Figure 269: creation of the desired contact on the scale "010101 ####" (private scope) Similar considerations apply to extend the "Dental Practice" contact to all MAX video door phones of the system. Simply create the public type contact on the site. Figure 270: creation of the desired contact on the site node Since in each apartment in the example there are a MAX video door phone and a Miro door phone, you can allow the Miro door phone of the whole site to call the “Dental Practice”...
Page 242 Figure 271: contact that can also be called via the T1 button of the Miro doorphone of the entire site In the case shown in the figure, the created contact can be called by means of button T1 of each Miro door phone in the system.
Page 243 To make this contact also visible in the address books of Call Modules of the entire site, simply select the "Call Modules" option in the "Visibility Filter" field. Figure 272: Adding a contact to the address books of Call Modules of the whole site With this setting, the Call Module in the site and the one in block "0101######"...
Page 244 7.1.4.1.1 How to call an IPerCloud apartment If you want to call an IPerCloud apartment from a video door phone or a door phone, after selecting the IPerCloud apartment to define the recipient of the contact, the screen that appears is the following: Figure 273: recipient selection screen in case of IPerCloud apartment Selecting the item “All CallMe on apartment”...
Page 245 Selecting the “Video Door Phone with address book” item and pressing “OK”, the contact is created as shown below: Figure 275: contact with destination IPerCloud apartment created In this way the video door phone of the apartment "01010003" will see the contact relating to the IPerCloud apartment in the address book and by calling this contact it will receive the call on its own smartphone/tablet.
Page 246 7.1.4.2 How to call the Switchboards from MAX video door phones, Miro door phones and/or call modules In the example in Figure 180 there is a Switchboard on block "0102######". Automatically, all MAX video door phones the topological path of which intercept the switchboard, will have a button in the video door phone application that can be used to call the respective Switchboard.
Page 247 After assigned meaningful name to the contact as "Switchboard", you should choose the target by pointing to the topological node in which the Switchboard is located. Figure 277: Selecting the target of the "Switchboard" contact In the case of Switchboards, the following selections can be made (on each node): •...
Page 248 Let us assume you choose single Switchboard called "Switchboard B2". The following screen will appear: Figure 278: contact creation page updated with recipient data Select the "MAX" option in the field " Video door phone with address book" field and confirm the "PUBLIC" selection in the "Scope"...
Page 249 Press the "OK" button to finish creating the contact, as shown in the following figure: Figure 280: List of contacts with new created contact In this way, the MAX video door phones of the topological nodes which belong to block "0101######" will see the new "Switchboard"...
Page 250 In the case shown in the figure, the created contact can be called by means of button T1 of each Miro door phone in block “0101######”. To make this contact also visible also in the address books of the Call Modules referred to block “0101######”, simply select the "Call Modules"...
Page 251 7.1.4.3 Auto-on function on Door Speaker Units, Call Modules and RTSP cameras from MAX video door phones outside their competence. The MAX video door phones can automatically make autoinsertion on Entry Panels, Call Modules and RTSP cameras only if these calling stations are on the topological path of the video door phones themselves and if the item “Automatic assignment for CCTV cameras”...
Page 252 Assign a meaningful name to the contact, e.g. "Call Module Block 01", because the target must be able to select the desired Call Module. Figure 284: Selecting the target of the "Call Module Block 01" contact Pressing the "OK" button will update the contact creation screen, as shown in the following figure: Figure 285: contact creation page updated with recipient data MT124-032N...
Page 253 Select the " Video door phone with address book” option in the field "Visibility Filter" field (the only option available in this case) and confirm the "PUBLIC" selection in the "Scope" field, to make the contact appear in the CAMERAS list of all MAX video door phones of the topological nodes which belong to block "0102######".
Page 254 In this mode of use of the “Contact” tab, the “Video door phone with address book” option also includes video door phone 1761/6 If one or more gateways are present in an IPerCom system, the 2Voice apartment stations can carry out: •...
Page 255 As an example, the following figure is shown: Figure 288: plant topology where: • stairs “010102####” e “010202####” are with Gateway IPerCom-2Voice 1083/59 (highlighted in yellow); • stairs “010101####” e “010201####” are stairs with IPerCom apartment stations; • “0101010101" topologic code apartment is a dental practice (in red). If you want to add the dental surgery as a contact in the address book of a 2Voice audio/video apartment station, this is prevented by the configurator: in fact, by positioning on the nodes below the stair node with gateway, the Contacts tab is no longer available (up to 2Voice apartment nodes):...
Page 256 The Contacts tab instead remains available on each stair node with 2Voice Gateway, as on these nodes it is possible to add other IPerCom devices (for example one or more MAX video door phones on which it may be necessary to create a address book). On stair 1 of block 1, instead, the Contacts tab is normally present up to the apartment node: Figure 290: Tab “Address books”...
Page 257 7.1.5 Activations The "activation rules" (more briefly "activations") allow defining the behaviour of the relay outputs in relation to events that can occur within the IPerCom system. The devices that provide the control relays output are: Relay Actuators 1060/84: two fully independent relay outputs and two inputs, Lift Interface 1060/37: 24 relay outputs and one input, Entry Panel 1060/33-34-71-74-75-78: only the relay output that controls the gate, Entry Panel 1060/21: only the relay output that controls the gate,...
Page 258 The events that define the behaviour of the relay outputs can be divided into three groups listed below: 1. Events on device: outgoing call, auto-on, tamper alarm, coercion alarm, code activation; door opening, gate opening, user recognition (following proximity key passage or door opener code entry);...
Page 259 For the events on device, it is necessary to open the configuration page of the devices indicated in point 1: Figure 291: Devices present on site node Simply press the ''Edit'' button of the Call Module. At the bottom of the screen there is the “Add” button in the “Activations”...
Page 260 For topological events, press the "Activations" tab on the "Topology" page and navigate the topological structure of the system to the node where you want to create the activation rule: Figure 293: "Activations" tab to connect topological events to outputs For automation events, press "Automation"...
Page 261 The following summary table groups the possible events according to the source (device) or type of event itself: DEVICE/EVENT TYPE EVENTS Entry panel (1060/33-34-71- Outgoing call, auto-on, door opening, gate opening. 74-75-78) Entry panel (1060/21) Outgoing call, auto-on, user recognition, door opening, gate opening, Private Call...
Page 262 7.1.5.1 Activation for events on Entry panel 1060/33-34-71-74-75-78 The "Add" button, at the bottom of the configuration page of Entry Panel, allows creating one or more activation rules, as shown below. Figure 295: addition of an activation rule Press this button to open a screen containing the list of activation rules already set, if any. If the device has just been added to the configuration or no rule has been set yet, this list will be empty, as shown in the figure: Figure 296: list of activations...
Page 263 To create a new activation, press the "Add New” button. The following screen opens in which you can set all the parameters needed to build the activation rule: Figure 297: Screen for creating an activation with event on Entry Panel The "Trigger"...
Page 264 The "Description" field can be used to give a meaningful name to the activation you are creating. The "Time Profile" drop-down menu can be used to associate a previously created time profile with the activation rule. In this way, the rule will only be active within the selected time profile. For example, having selected the auto-on event and given a meaningful name to the activation, the screen that appears is as follows: Figure 299: Partial activation creation...
Page 265 The available commands depend on how the output has been configured, i.e. monostable or bistable. In case of monostable output, only the "ACTIVATE" and “DISACTIVATE’’ commands are available. In the other case, the available commands are "ON", "OFF" and "SWITCH". For more details, see APPENDIX A: Configuration parameters of IPerCom devices.
Page 266 The list of activation rules shown will contain the new created activation. Figure 302: Activation table with the newly created element The second output of the Relay Actuator is automatically activated in monostable mode every time an auto-on is performed in the entry panel. In any case it is possible to modify or delete the newly created activation using the "Edit"...
Page 267 7.1.5.2 Activation for events on Entry panel 1060/21 The "Add" button, at the bottom of the configuration page of Entry panel 1060/21, allows you to create one or more activation rules, as shown below: Figure 304: addition of an activation rule Press this button to open a screen containing the list of activation rules already set, if any.
Page 268 To create a new activation, press the "Add" button. The same screen as for the creation of activations with event on Entry panel 1060/71-74-75-78 opens, where it is possible to set all the parameters necessary to create the activation rule: Figure 306: screen for creating an event activation MT124-032N...
Page 269 The “'Event” drop-down menu allows selecting the event to be associated to one or more Relay Actuator outputs. The possible events on Entry panel 1060/21 are: • “Outgoing Call”, i.e. call from the Entry Panel; • "Auto-on", i.e. connection from the video door phone to the camera of the Entry Panel; •...
Page 270 7.1.5.3 User recognition event The user recognition event allows you to activate one or more Relay Actuator outputs after: • passing a valid proximity key of a resident or non-resident; • entering a valid door opener code of a resident or non-resident. This function is available on the following devices: •...
Page 271 7.1.5.4 Activation for events on Floor Entry panel 1060/22 The "Add" button, at the bottom of the configuration page of Floor Entry panel 1060/22, allows you to create one or more activation rules, as shown below: Figure 309: addition of an activation rule Press this button to open a screen containing the list of activation rules already set, if any.
Page 272 The same screen as for the creation of activations with event on Entry panel 1060/33-34-71-74-75-78 opens, where it is possible to set all the parameters necessary to create the activation rule: Figure 311: screen for creating an event activation The “'Event” drop-down menu allows selecting the event to be associated to one or more Relay Actuator outputs.
Page 273 7.1.5.5 Activation for events on Call Module The "Add" button, at the bottom of the configuration page of Call Module, allows you to create one or more activation rules, as shown below. Figure 313: addition of an activation rule Press this button to open a screen containing the list of activation rules already set, if any. If the device has just been added to the configuration or no rule has been set yet, this list will be empty, as shown in the figure: Figure 314: list of activations...
Page 274 The same screen as for the creation of activations with event on Entry panel 1060/71-74-75-78 opens, where it is possible to set all the parameters necessary to create the activation rule: Figure 315: screen for creating an event activation The “'Event” drop-down menu allows selecting the event to be associated to one or more Relay Actuator outputs.
Page 275 Figure 316: Event list on Call Module The activation rule is created in the same way as for the Entry Panels. In the "Code activation" event, the code is entered in the "Code" field in the relevant screen. MT124-032N...
Page 276 7.1.5.6 Activation for events on Entry Panel with 1060/48 The "Add" button, at the bottom of the configuration page of Modular Entry Panel with 1060/48, allows you to create one or more activation rules, as shown below: Figure 317: addition of an activation rule The creation of the activation rule takes place as already described for the Call Module with the only difference that the tamper alarm is not present in the list of possible events.
Page 277 7.1.5.7 Key Reader activations The "Add" button, at the bottom of the configuration page of Key Reader, allows you to create one or more activation rules, as shown below: Figure 318: "Activations" button for Key Readers Press this button to open a screen containing the list of activation rules already set, if any. If the device has just been added to the configuration or no rule has been set yet, this list will be empty, as shown in the figure: Figure 319: “Activations Tables”...
Page 278 The same screen as for the creation of activations with event on Entry panel 1060/71-74-75-78 opens, where it is possible to set all the parameters necessary to create the activation rule: Figure 320: Screen for creating an activation with event on Key Reader The “'Event”...
Page 279 7.1.5.8 Activations for topological events To associate a topological event to one or mode outputs of a Relay Actuator, Lift Interface, or gate of a calling station it is necessary to click on the “Topology” tab and then on the “Activations” tab. Figure 322: “Activations"...
Page 280 To create the activation rule, press the "Add New Activation" button on the "Activations" screen. The same view screen opens for creating of activations with event on Entry Panel that can be used to set all the parameters needed to build the activation rule. Figure 323: Screen for creating an activation with a topological event The “Event”...
Page 281 The possible topological events for the Lift Interface device are: • ‘’Lift Up and Lift Down’’ (lift function), events enabled only for stair, floor, and apartment nodes; as shown on the respective screens: Figure 324: List of events for MAX video door phones 7.1.5.8.1 Topological events for Relay Actuator Having selected the incoming call event and given a meaningful name to the activation, the following...
Page 282 To add outputs to the activation rule, proceed as described for creating activations for Entry Panels. For example, a screen of this type will appear: Figure 326: List of outputs associated with the activation rule Once all the outputs have been added to the activation rule and a possible time profile has been selected, press the "OK"...
Page 283 If instead "User Activation" is chosen as the event, the following screen will appear: Figure 328: user activation In the field “Button Name” it is advisable to enter a meaningful name of the activation (for example "Staircase lights"). The “Filter” field allows you to choose where to add the activation rule as shown below: •...
Page 284 In the case of IPerCloud apartments with call forwarding also on the GSM or landline telephone network, the selection of the "DTMF T7" or "DTMF T8" or "DTMF T9" items allows you to control the output of a Relay Actuator or a Lift Interface from a smartphone by pressing button 7 or button 8 or button 9 respectively only during a conversation with the calling station.
Page 285 By selecting an apartment in the navigation module, in correspondence of the "Activations” tab we will see the activation applied by the stair node, as shown in the following figure: Figure 330: Activation "inherited" from the apartment The activation is greyed out to show that it was created on the stair node, not on the apartment node. Therefore, it can only be modified by going to on the stair node and not to the current topological node.
Page 286 7.1.5.8.1.1 Addition of a user activation on video door phones / door phones / CallMe application When creating a user activation rule, it is possible to choose which type of apartment station/application to add via the "Filter" field. The possibilities are summarized below: •...
Page 287 ("VDP" DD USER ACTIVATION ON VIDEO DOOR PHONES WITH ADDRESS BOOK ITEM In the "Video door phone" screen of the MAX, VOG , VOG , Basic video door phones and IPerCom Client application of these apartments, a new "ACTIVATION LIST" button will appear with a yellow light bulb icon: Figure 332: “ACTIVATION LIST”...
Page 288 ("ADP T1" "ADP T2" DD USER ACTIVATION ON VIDEO DOOR PHONE IRO DOOR PHONE ITEMS Miro 1160/3 door phone and the VOG 1761/6 video door phones have two buttons associated with the items “ADP T1” and “ADP T2”. The buttons are shown in the following two figures: Figure 334: T1 and T2 buttons of Miro door phone Figure 335: T1 and T2 buttons of VOG5 1761/6 The button marked with a dot/gate corresponds to the “ADP T1”...
Page 289 DD USER ACTIVATION ON E APP The “Staircase Lights” button appears on the Home Page of the CallMe application (previously associated with the apartment): Figure 336: activation list By pressing the "Staircase Lights" icon, the output of the Relay Actuator chosen during the configuration phase will be piloted, which will turn on the staircase lights.
Page 290 7.1.5.8.2 Topological events Lift Up and Lift Down Regarding the selection of the “Lift Up” and “Lift Down” events, these options are only visible if you go in correspondence of stairs, floors, or apartments, as they are only associated with the use of the lifts. In a system where there is a Lift Interface or a Relay Actuator, it is possible to create activation rules (maximum 2) that, for example, allow each resident to enable, through the MAX, VOG , VOG...
Page 291 Figure 338: activation screen of Lift Interface relays Select the relay(s) to be enabled and set the relay activation time in the "Duration" field. Figure 339: enabling the Lift Interface relays MT124-032N...
Page 292 Select the Relay Actuator in the "Output" area to display the outputs to be configured. The outputs must be set in monostable mode and the relay activation duration must be enabled in the device configuration page (see APPENDIX A: Configuration parameters of IPerCom devices).
Page 293 Press the Lift Interface or Relay Actuator icon to activate the configured relays by sending the "Up" or "Down" command to the lift, for the set time. Figure 342: Lift “Up” and “Down” commands To obtain the same functions on the VOG5 video door phone and on the Miro door phone, the relative keys T1 and T2 must be set to the "Lift Down"...
Page 294 7.1.5.8.3 Events Open Door and Open Gate The "Open Door" and "Open Gate" events can refer to any door or gate in the system. If you choose one of these two events, the "any" (default) events will appear, as shown in the image below: Figure 343: Open door/gate activation In this case, about calling station access points, the activation of one or more relay outputs also takes place outside the call step itself, by simply pressing the door and gate opening keys of apartment stations...
Page 295 7.1.5.8.4 Switchboard Activations Switchboard activations are activation rules that appear only on the Switchboard application, if created on its topological path. For example, if placed on the unit node, the activations that will be shown on the Switchboard application are those created from the unit (where the Switchboard application is present), block or site node.
Page 296 Also in this case, give a meaningful name to the activation ("Button Name" field), select one or more outputs through the "Add a New Output" button and eventually a time profile, as seen in the previous paragraphs. When pressing the "OK" button, the activation is created and added to the list of activations of the topological node chosen before: Figure 345: activation from switchboard created on the configurator The newly created activation rule will appear on the Switchboard application as below:...
Page 297 7.1.5.8.5 Activations for topological events with 2Voice audio/video apartment stations Activations for topological events also apply to topological stair nodes with 2Voice Gateway with the following differences: 1. The User Activations - MAX, Lift Down and Lift Up events are not present on the nodes below a stair node with 2Voice Gateway: Figure 347: List of events for audio/video Door Phone 2Voice The events in question are instead present on each stair node with 2Voice Gateway, because on these...
Page 298 Figure 348: Activation "inherited" from 2Voice apartment If you want to replace the activation on the 2Voice apartment with a custom one, just press the replacement button and change the data. If set on scale or floor level, the activation rule will be propagated only to 2Voice apartments of the topological group of the respective node.
Page 299 7.1.5.9 Automation events: input/output association Each relay actuator is provided with two inputs (controlled by buttons or switches) to: • control the respective outputs locally; • control one or more outputs of different relay actuators by means of events (of the inputs). In the first case, staircase light control is a typical example in which it may be useful to have a local output control.
Page 300 7.1.5.9.1 Input-output activation on two different relay actuators In this example, we will assume there are two combinations of commands to be imparted on the system: • switch on light 1 for a predefined time; • switch on light 1 and light 2 for the predefined time. Two automation rules are required.
Page 301 Having followed the instructions in the note, the input/output association can be set on the Automation tab under "Activation Rules", as shown in the following figure: Figure 349: "Automation" page, "Activation Rules" tab Press "Add New’’ to open the following page: Figure 350: Creating a new activation On this page, you can: •...
Page 302 The input selection "Add" button opens the following screen: Figure 351: List of available inputs If the default names of the inputs were still used for each Relay Actuator (i.e. Input 1 and Input 2, instead of the previously assigned meaningful names), it would have been difficult to identify the input with which to associate the rule you want to build.
Page 303 For example, if you choose the "Short press" event, it will be highlighted with a different colour from the previous one: Figure 353: "Short Pressure" event selected If the input in question were set as bistable, the events displayed would be “ON” and “'OFF”. The input you are associating with the rule passes to the right of the screen, while those not yet associated remain on the left.
Page 304 At this point, as shown in the table, you must choose the output to be controlled. If with the "Short press" event you want to control only one "Garden Path light 1" output of the second relay actuator, you must select the "single output"...
Page 305 Go to the topological node of the Relay Actuator 2, select the concerned device, then choose the output and set the respective command: Figure 357: Topological structure navigation for relay actuator search, output selection and respective command Press the "OK" button to open the following screen with a summary of the choice made regarding the output: Figure 358: Selected output and respective command The buttons in the "Edit"...
Page 306 Press the OK button again to go back to the main screen where the name of the activation, the input and the relative event are shown: Figure 359: Activation created The buttons in the "Edit" and "Delete" columns can be used to modify or delete the newly created rule (via confirmation pop-ups), respectively.
Page 307 Using the same input of the first Relay Actuator, the one named as "Garden Path Light Switch Input", it is possible to switch on both the first and the second light (outputs linked to the second Relay Actuator). So it is possible taking advantage of the second event linked to the programming of the input, that is the "Long press"...
Page 308 After having given a meaningful name to the newly created rule and having pressed "OK", you have the situation shown in the figure, where the name of the activation, the input and the respective event will appear: Figure 362: Summary of created activations The buttons in the "Edit"...
Page 309 7.1.5.9.2 Creating a scenario In this example, we will suppose that the combination of commands to be imparted on the system consists in switching on four lights and switching off two lights using three different events: • Automation event (e.g., short press on input) •...
Page 310 To build the group of commands press the "Add New Output" button. The following page will appear: Figure 364: Creation of a group of commands First, you need to give a meaningful name to the group of commands, then add the outputs you want them to be part of the group.
Page 311 Press the "OK" button to add the first output to the group you are about to create: Figure 366: Adding the first output to the scenario The buttons in the "Edit" and "Delete" columns can be used to modify or delete the output and the respective command (via confirmation pop-up), respectively.
Page 312 At this point, if you want the input named as "Pool Lights On Input" to control the newly created group of outputs on a short press event (for example), go to the "Activation Rules" tab and follow the instructions in the previous paragraph with the only difference of selecting the "command set"...
Page 313 Then press "OK" to open this screen that summarises the choices made: Figure 370: Selecting a group of commands After giving a name to the activation, press the "OK" button to open the following screen: Figure 371: Activation with created group of commands It is advisable to give a meaningful name to the created rule so that you can quickly identify that the concerned rule controls a group of outputs.
Page 314 The same scenario can be added when creating a topological activation rule or on a device, more precisely when adding outputs as shown in the following figure: Figure 372: Activation with created group of commands "Select" item can be used to choose the scenario, while the "Add" button allows you to add it to the rule you are creating.
Page 315 Press "Add New’’ to open the following page: Figure 374: Adding a time profile After having given a name to the time profile you want to create, the buttons can be used to create a time interval for each day of the week within which the activation will be valid (through the following screen): Figure 375: Creating a time profile MT124-032N...
Page 316 The scrolling menus in the figure above allow you to define the start and end of validity of the time profile for each day of the week. For example, if you want to activate a validity for Monday from 8:00 to 12:00, the result is as follows (after pressing the "OK"...
Page 317 Press the "OK" button to complete creating the time profile: Figure 378: Saved time profile The buttons in the "Edit" and "Delete" columns can be used to edit or delete data for each time profile, respectively (via confirmation pop-up). At this point, in a previously created or new activation, the "Time Profile" drop-down menu allows you to add a time profile, as shown in the following image: Figure 379: Time profile associated with activation MT124-032N...
Page 318 Press the OK button, to see the newly created activation with the associated time profile in the activation list: Figure 380: Time profile with activation The buttons in the "Edit" and "Delete" columns can be used to edit or delete data for each activation, respectively (via confirmation pop-up).
Page 319 Press the "Add New" button to open the following screen with all the available inputs of the various relay actuators (identified by their physical MAC address and a significant name): Figure 382: Inputs available for alarm generation In this example, we will assume that the first input is reserved for alarm generation. Press the button to choose which event on this input generates the alarm.
Page 320 If the input has been configured in monostable mode, the possible events are: Figure 384: events available if the input is set to monostable mode The Short press and Long press events are used to generate non-instantaneous alarms. For example, if the input has been set to normally closed, a sensor connected to a door that is left open for a time longer than the time set at the input triggers a Long press event and then generates an alarm.
Page 321 It is possible to select the alarm type to be sent to the Switchboard from the drop-down menu with the red box. The available alarms are listed below: Figure 386: Available alarms For example, if you select the "Door Forced" alarm, press the "OK" button to see the list of inputs on the screen.
Page 322 7.1.5.9.5 Creation of relay actuator activations and alarms The activation and alarm generation rules seen in the previous paragraphs can also be created on the configuration page of the relay actuator in the section dedicated to inputs. Note that the input programming method described in the previous paragraphs is only possible on relay actuators with firmware version 3.04 or higher.
Page 323 Press the "Add’’ button to open the following page: Figure 390: Screen to create activation on a single input The “Trigger” drop-down menu allows you to select the event to be associated with the input, in this case "ON" or "OFF": Figure 391: Possible events on the input MT124-032N...
Page 324 After having selected an event (e.g. "ON") and given a meaningful name to the activation, associated it with a time profile if required and added one or more outputs, the following screen will appear: Figure 392: Event output settings The result is what we saw in the previous paragraphs, as well as for the creation of alarms. MT124-032N...
Page 325 7.1.5.9.6 Schedules Through the “Schedules" tab you can program on a weekly basis the behaviour of the outputs of the Relay Actuators (activation rules). A schedule may consist of one or more activation rules. Press the Schedules tab, to display the following page: Figure 393: ''Schedules”...
Page 326 The buttons allow you to add one or more activations for each day of the week and at a preset time. Activations are created by choosing: • one or more outputs of the Relay Actuators, setting the relative command; • one or more groups of commands (scenarios) previously created.
Page 327 To set the time to sunrise and sunset (corresponding to your geographical location), see the paragraph Sunrise/Sunset Settings of the chapter on system parameters. Press the "Select" button to open a screen page where you can choose the absolute time or the offset (in hours and minutes) to associate with the sunrise or sunset: Figure 396: choice of absolute time or offset to associate with sunrise or sunset Below are 3 examples of how the "Time"...
Page 328 The "Description" field allows you to give a meaningful name to the time activation you are creating. The “Add a New Output” button allows you to add one or more outputs with the relative command to the activation you are creating. Press this button and position on the topological node of theRelay Actuator, select the desired device (if there are more than one Relay Actuators), then choose the output and set the relative command: Figure 400: selection of a Relay Actuator output...
Page 329 Press the "OK" button to add the output selected with the relative command, as shown in the following (by way of example) figure: Figure 401: list of outputs associated with the schedule It is possible to associate different outputs to the same activation by pressing "Add a new output" and repeating the above steps.
Page 330 The buttons in the red box allow you to: • modify the activation just created (button • delete the activation just created (button • add another activation for the same day ( ("Copy") and ("Paste") buttons in the blue box allow you to copy the activations you have just created to the other days of the week: in fact, if you press the "Copy"...
Page 331 By pressing the “OK" button, the schedule is saved and added to the schedule list: Figure 404: saved schedule The buttons "Edit" and "Delete" allow you to modify the data or delete each schedule created, respectively (through confirmation pop-up). MT124-032N...
Page 332 7.1.6 Gate contact used as output of a Relay Actuator For activation rules it is possible to use the gate contact of any calling station as a relay output (in addition to the relay outputs of 1060/84 Relay Actuator and the 1060/37 Lift Interface devices). The calling stations that allow the gate contact to be used as the output of a relay actuator are: - Entry Panel 1060/71-74-75-78;...
Page 333 The page relating to the configuration parameters of the Call Module opens. In the section relating to the Gate, the "Enabled" field must be set to the value "Relay actuator", as shown below: Figure 406: gate contact used as output of a relay actuator The following fields are shown in automatic way: •...
Page 334 Pressing the "Add a New Output" button, both the outputs of any Relay Actuators and the relay output of the gate of the Call Module are displayed: Figure 408: gate contact used in the activation rule By pressing the “OK” button, the activation is correctly created. MT124-032N...
Page 335 7.1.7 Remote relay functions, remote entrance hall button and remote sensor The remote relay function, available on devices such as Call Module 1060/12-13-17-18-23, Entry panel 1060/33-34-71-74-75-78, Entry panel 1060/21, Modular Entry Panel with 1060/48, Key Reader 1060/45 and Key Reader 1060/86, allows you to remotely control the outputs that operate the pedestrian door and the driveway (if any) on those of a Relay Actuator 1060/84 with firmware version 4.05 or higher.
Page 336 If you want to implement this service on the pedestrian door of a Call Module (for example), it is necessary to go to the configuration page of the device in question, i.e. open the configurator on the "Topology" tab, then on the "Devices" tab. A screen with the list of devices present on the system on the selected node is displayed: Figure 409: Devices present on the site node By pressing the modification button on the Call Module, the remote relay function setting part is displayed...
Page 337 About the “Remote Relay” item, the “Select” button allows you to navigate the topological structure of the system, position on the topological node of the Relay Actuator 1060/84 v. 4.05 that you want to use to remotely control the pedestrian passage, select one of the 2 outputs, then press “OK” as shown in the figure below to confirm: Figure 411: Output selection Relay actuator for pedestrian door remote control After pressing the “OK”...
Page 338 In the same way, it is possible to remotely control the pedestrian door entrance hall button or the open- door sensor with the only difference that, instead of selecting the output of a Relay Actuator, it is necessary to select an input. The remote entrance hall button will activate (for a pre-set time) the same output used to remotely control the pedestrian passage.
Page 339 7.1.8 User management In the four possible plant models (Villa Kit, Single Stair, Multiple Stairs, Multi Block) the management of the users is implemented in the relevant "Users" tab, as shown in the following figure: Figure 413: “Users” tab The screen shows 4 different types of users, described in the dedicated paragraphs: “Residents”, “Not residents”, “Groups”, “Switchboards”.
Page 340 In the configuration, no topological node has yet been entered, so the "Users" tab will not allow the addition of residents, since it is only allowed in the apartments. Figure 415: “Residents" screen in a topological node different from the apartment If you want to add a block, with a stair, a floor and 3 apartments to the topology: go through the navigation module to one of the apartments, you will see the "Add"...
Page 341 Press the button to access the following screen, with the fields to be filled in for the creation of the new user. Figure 417: Creating a new resident – first part Figure 418: Creating a new resident – second part MT124-032N...
Page 342 The following table helps you to understand the meaning of the fields Surname or Surname of the resident or company name. Maximum length: 32 Company Name characters. Name/Other Resident name or other information. Maximum length: 32 characters. information Telephone Telephone number associated to the resident. Maximum length: 16 number numeric characters.
Page 343 The types of keys available are: • 125KHz, • Mifare, • Mifare Plus • dual technology (125KHz and Mifare). APPENDIX E: Type of proximity keys that can be read by IPerCom devices with access control function contains a table with a list of devices that integrate a key reader and the different types of proximity keys that can be read by these devices.
Page 344 The buttons in the columns "Edit" and "Delete" allow you to modify the data or delete each user created, respectively (through confirmation pop-up). The creation of the residents allows: • having a contact address book that can be viewed on the Call Modules and Modular entry panel with 1060/48;...
Page 345 By pressing the “Add New” button, a screen like the following one will open: Figure 421: creation of a non-resident - part one Figure 422: creation of a non-resident - part two MT124-032N...
Page 346 The following table helps you to understand the meaning of the fields: Surname or Surname of the resident or company name. Maximum length: 32 characters. Company Name Name/Other Resident name or other information. Maximum length: 32 characters. information Telephone Telephone number associated to the not resident. Maximum length: 16 number numeric characters.
Page 347 Generally, the validity period is not set, so access is always granted to the non-resident; to set a validity period, select the “Valid From” and “Valid To” items in the red rectangle (using the relevant tick boxes) and then set a validity start date and end date. An example is provided in the following figure. Figure 424: selection of date and time of the period of validity An important difference is noted on the operation of the Door Codes and Key Codes.
Page 348 A screen page opens displaying the various access profiles loaded into the system to be associated with non-residents, or a list of doors that can be opened, if necessary, during a certain time frame: Figure 426: selection of access profiles for non-residents Access profiles can be created in the "Access Control"...
Page 349 The buttons in the columns "Edit" and "Delete" allow you to modify the data or delete each user created, respectively (through confirmation pop-up). The "Lift Interface Settings" button in the red box of Figure 296 allows setting the activations of the lift interface (if present in the system) according to the defined paths (see paragraph Adding a Lift Interface 1060/37 on a stair node).
Page 350 Pressing the "Add" button, the following screen appears: Figure 429: adding a group The "Name" and "Description" fields allow you to give a meaningful name and description to the group you are creating. The "Add" button in the "Access Table" section allows you to associate a previously created access profile to the group (see chapter Access control).
Page 351 To add residents, simply press the corresponding button : they disappear from the list above. The "Filter" field allows you to search for people by name, apartment, and topology according to the string entered in this field. By pressing the “OK” button, this screen appears: Figure 431: New group Then simply give the group a meaningful name and description and confirm with the "OK”...
Page 352 7.1.8.4 Switchboards Through the "Switchboards” tab of the "Users” tab it is possible to manage the users of the switchboards in the system. Figure 433: “Switchboard" screen The '’Add'' button allows adding new users of the switchboards. Press it to open the following screen: Figure 434: Creation of a new user MT124-032N...
Page 353 Once all fields have been edited appropriately and the "OK” button has been pressed, another user is added to the user list. Figure 435: List of the switchboard users The buttons in the columns "Edit" and "Delete" allow you to modify the data or delete each user created, respectively (through confirmation pop-up).
Page 354 7.1.9 Access control The IPerCom system integrates an access control service, which allows the opening of gates (doors, gates, barriers, etc.) by recognising proximity keys or entering door codes. Call Modules, Entry Panels 1060/21 and Key Readers can be used to open the access. Call Modules with 1060/48 and Entry Panels 1060/21 integrate a Proximity Key reader.
Page 355 All residents of Stair "02" are automatically enabled to open the accesses associated with the main Call Module and the Key Reader with a key code and a door code (both the Call Module and the Key Reader are on the topological path of these residents). Figure 438: User setting screen If you want to give the residents of Stair "02"...
Page 356 7.1.9.1 Access profiles The "Access Profiles” screen is the same as the one that appears when you open the "Access Control" tab. Figure 439: “Access profiles” screen Access profiles allow to group a set of accesses that a group of users’ needs to open in a single rule even if these accesses are not on the topological path of the apartments of these users.
Page 357 It is necessary to give a name to the access profile that is being created in the "Name" field at the top left, and then select the access points that are part of it by simply pressing on the relevant record (the relevant tick box is selected automatically).
Page 358 In the “Access profiles” screen page, the buttons in the columns "Edit" and "Delete" allow you to modify the data or delete each access profile created, respectively (through confirmation pop-up). Each resident/non-resident can be assigned an access profile during the user creation/editing phase: Figure 443: Resident editing screen di un residente By pressing the “Add”...
Page 359 By selecting an item on the left, it will be moved automatically to the right list. Assuming you want to select the previously created access profile, you get the following: Figure 445: Selection of an access profile Press the "OK” button to automatically associate the access profile with the created user: Figure 446: association of access profile to resident An access profile must be associated with a resident or non-resident or user group to be effective.
Page 360 7.1.9.2 Time Profiles A time profile is a set of time intervals for the validity of accesses. To manage time profiles, go to the "Access Control” tab, then click on the "Time Profiles” tab. The following screen will open: Figure 447: “Time profiles” screen By pressing the “Add New"...
Page 361 Up to three access time intervals can be created for each day. To create a new time interval, press button to open the following screen: Figure 449: Creation of a time interval After setting the time interval and pressing the "OK" button, the interval will be added to the selected day, as shown in the following figure: Figure 450: time interval added to the selected day MT124-032N...
Page 362 The buttons ‘’ ’’ and ‘’ ’’ allow you to quickly copy the time interval you have just created for all the other days of the week: in fact, if you press the button ‘’ ’’ on Monday, you enable the buttons ‘’ ’’...
Page 363 After naming the time profile and pressing the "OK” button, the new time profile will be added to the time profile list. Figure 452: List of the created time profiles The buttons in the columns "Edit" and "Delete" allow you to modify the data or delete each time profile created, respectively (through confirmation pop-up).
Page 364 For example, if you want to associate a time profile to a Key Reader access point, you will see the following screen, where no time profile is set. Figure 454: Time profile not set To associate a previously created one, click on the respective drop-down menu to open a screen with all the created time profiles.
Page 365 If a time profile is associated with a generic access, it appears with an asterisk when creating an access profile: Figure 456: Door with associated time profile 7.1.9.3 Holidays Holidays allow you to define one or more particular dates of the year (e.g. Christmas) on which to alter a previously created time profile.
Page 366 Pressing the "Add New" button you can create a holiday by defining the following fields: • "Name": significant name to give to the festivity; • "Year": field not mandatory. If not set, the exception (i.e. the holiday) that is being created is valid for each year;...
Page 367 At this point, the following screen will appear when opening a previously created time profile, for example, where you can set a new time profile for the 25th of December of each year, as seen in the previous paragraph: Figure 460: time profile with the possibility of adding a holiday Press "Add Holiday’’...
Page 368 By pressing button it is possible to create up to three time intervals within the holiday period. Assuming you want to create a single interval from 8 to 10, the following page will appear: Figure 462: Additional holidays with timetables The "OK"...
Page 369 7.1.9.4 Door groups The door group is a set of doors that must obey the same rules, have the same temporal validity and the same temporal profile. The Doors Group function is useful if a group of people needs to access a group of doors in the same way.
Page 370 To create a group of doors, it is necessary to assign a name and select the desired doors: these are moved to a list on the right to form the desired list of doors. Figure 465: Selection of desired doors To delete a door from the list, simply select it: it will be moved back to the list on the left.
Page 371 If you want to use the "Swimming pool doors" door group in the previously saved access profile, simply open it again and select as door group the group “Swimming pool doors” instead of the previously selected Key Readers. Figure 467: Selection of the new door group in the saved access profile MT124-032N...
Page 372 7.1.9.5 Door profiles A Door Profile is a set of parameters that define the behaviour of a generic door. This functionality is useful if there are several doors in the system which must comply with the same rules. Instead of applying the set of rules several times to different doors, it is sufficient to create the set of rules once and then apply it to the individual doors.
Page 373 For the meaning of the various parameters, see "APPENDIX A: Configuration parameters of IPerCom devices". An example of configuration is shown below: Figure 470: Setting parameters for an access Press "OK" to create the access profile: Figure 471: Creating an access profile Once the access profile has been created, it can be applied to several doors.
Page 374 To do this you need to go to the "Topology" page, then to the "Devices" tab: Figure 472: Devices on which to load the access profile Press the "Edit" button of the first Key Reader to open the following screen where "Custom" appears next to the concerned access (i.e.
Page 375 Click on "custom" to choose the previously created access: Figure 474: Selecting a door profile Press the "OK" button to load the door profile on the concerned door: Figure 475: Loading the access profile The loaded parameters are greyed out to highlight the fact that they come from a previously created access profile.
Page 376 7.1.9.6 Trade The trade function allows opening the pedestrian door and/or the driveway (if enabled) directly from the Call Modules and Modular Entry Panel with 1060/48 keypad during a time set during the creation of the trade itself. The application can be useful if external personnel needs to access the residential complex in pre-set time intervals.
Page 377 In the screen above you need to select the access profile created as a trade. After assigning a name to the trade, pressing the “OK” button the trade is created and added to the list of available trades. Figure 478: List of created trades The buttons in the columns "Edit"...
Page 378 7.1.10 System parameters The "System" tab allows setting several parameters related to the system operation and its performance. For simplicity, the parameters have been divided into the following sections: • "Global Settings", • "Door/Gate Settings", • “Call Forwarding Settings”, • “Call Divert settings”...
Page 379 7.1.10.1 Global Settings The parameters are shown in the following figures: Figure 480: "System" tab - “Global Settings” (first part) Figure 481: "System" tab – “Global Settings” (second part) MT124-032N...
Page 380 The meaning of the single items is shown in the following table: System Language Language used by IPerCom devices with display or IPerCom applications with graphical interface (Switchboard and IPerCom Client). Time Zone Time zone selected for time management. Default value: “Europe/Rome”.
Page 381 Default Apartment Type If the IPerCom value is set, all the apartments added in the configuration are of the IPerCom type, that is with at least one apartment station; if the IPerCloud value is set, all the apartments added in the configuration are of the IPerCloud type, that is they can have no apartment station.
Page 382 Regarding the item “Automatic Assignment for CCTV Cameras”, the CallMe app linked to the apartment behaves as shown below. Item “Automatic Assignment for CCTV Cameras” enabled The list of cameras in the CallMe app on which making auto on is the same as the apartment video door phone or video door phones, excluding any RTSP cameras.
Page 383 7.1.10.2 Door/Gate Settings The parameters are shown in the red rectangle in the following figure: Figure 482: “System" tab – “Door/Gate Settings” The meaning of the single items is shown in the following table: Automatic Door Opening If enabled, it allows the automatic opening of the doors during the call phase.
Page 384 If the door is opened during the unhook time and the call is also answered within 10s, the call itself is no longer closed automatically. With automatic call closing after door opening function enabled, if the door is opened during the unhook time, any call divert enabled on the called apartment is ignored.
Page 385 7.1.10.3 Call Forwarding Settings The parameters are shown in the following figure: Figure 483: "System" tab – “Call Forwarding Settings” MT124-032N...
Page 386 The meaning of the single items is shown in the following table: Call forwarding If enabled, it allows call forwarding on smartphone/tablet. Default value: enabled. Call forwarding Cloud URI SIP server where to register the user for call forwarding on smartphone/tablet.
Page 387 If CallMe Manager support is disabled and IPerCloud apartments are present in the configuration, these are automatically set to IPerCom mode. MT124-032N...
Page 388 7.1.10.4 Call divert settings The parameters are shown in the following figure: Figure 484: "System" tab – “Call Divert Settings” The parameter meaning is as follows: Call Divert If enabled, it allows diverting the direct call to an apartment station (including IPerCom Client application) towards relevant switchboards or towards the contacts in the address book.
Page 389 7.1.10.5 Network settings The parameters are shown in the following figure: Figure 485: “System" tab – “Network Settings” The parameter meaning is as follows: ETWORK SETTINGS Network Addressing Mode The “Dynamic” item means that the devices automatically acquire an IP address consistent with the network in which they are installed (networks with DHCP server);...
Page 390 After a change in network settings, any devices in the system with a static IP address (e.g. RTSP cameras) must be made compatible with the new address assigned to the system. If a system contains MAX 1717/3x, MAX 1717/2x and/or VOG7 1761/3x video door phones to also be connected to domestic networks via the second LAN connector, it is recommended to configure the network for the IPerCom system with addresses of the type “10.x.y.z”...
Page 391 7.1.10.6 C USTOM NETWORK SETTINGS The parameters are shown in the following figure: Figure 486: “System" tab - “Custom Network Settings” The parameter meaning is as follows: IP Range Minimum Lower limit of the IP address range for the custom subnet you are creating IP Range Maximum Upper limit of the IP address range for the custom subnet you...
Page 392 If you enable RTSP streaming of the calling stations in the configurator, the related “User Name” and “Password” fields are automatically filled in with the values set in the “RTSP - Default User Name” and “RTSP - Default Password” fields. It is possible to leave the “RTSP - Default Username”...
Page 393 Remote Access If enabled, it is possible through IPerCom Installer Tools to connect to a remote system. Default value: disabled. Table 22: meaning of the parameters in the “Maintenance Settings” section For manually scheduled restarts, it is necessary to respect the constraint of at least 2 restarts every 4 days.
Page 394 7.1.10.8 Sunrise/Sunset Settings The parameters are shown in the following figure: Figure 488: "System" tab - “Sunrise/Sunset Settings” The parameter meaning is as follows: City The value chosen in this drop-down menu allows you to set automatically the "Latitude" and "Longitude” values used to calculate the sunrise and sunset time to program the activation of the outputs of one or more Relay Actuators or one or more scenarios on a weekly basis.
Page 395 7.1.11 Call addressing mode The call addressing mode in the “Global Settings” section of the system parameters affects how an apartment can be called by the alphanumeric keypad of the calling stations with display (Call Module 1060/12-13-17-18-23 and Modular calling station with 1060/48) and Switchboard. The call addressing mode to an apartment with the remaining calling stations with call buttons is not affected by the type of addressing mode chosen, that is: •...
Page 396 OPOLOGIC ADDRESSING TYPE In topologic addressing type to call an apartment from Call Module or Modular Calling Station with 1060/48 or Switchboard, the topologic code of the apartment in question must be entered by the keypad (starting from the block node). The topologic code of an apartment is a fixed parameter defined by the configurator during the creation of the system topology and is visible on the red box reported in the picture below: Figure 489: “Settings”...
Page 397 UMERIC ADDRESSING TYPE In numeric addressing to call an apartment from Call Module or Modular Calling Station with 1060/48 or a Switchboard, a numeric code must be entered by the keypad. You can set this code in automatic or manual mode (see paragraph Global Settings for further details).
Page 398 OGIC ADDRESSING TYPE In logic addressing to call an apartment from Call Module or Modular Calling Station with 1060/48 or a Switchboard, an alphanumeric code must be entered by the keypad. You can set this code in automatic or manual mode (see Global Settings paragraph for further details).
Page 399 LOCK MODE ADDRESSING TYPE In block mode addressing to call an apartment from the Call Module or Modular Calling Station with 1060/48 it is necessary to distinguish whether these are positioned on the “Site” node or not. 1060/48 ODULE OR ODULAR ALLING TATION WITH...
Page 400 If the numeric codes of the apartments are set manually, a numeric code must also be set for the blocks present in the topological structure of the system, as shown below: Figure 492: block “Settings" screen in case of block mode If some blocks do not have a valid numeric code, it is impossible to save the configuration.
Page 401 7.1.12 Setting of call forwarding function in IPerCom system not in IPerCloud mode The call forwarding function allows receiving a call from • Entry panel 1060/71-74-75-78, • Entry panel 1060/21-33-34, • Call module 1060/12-13-17-18-23, • Modular Entry Panel with 1060/48, •...
Page 402 If an IPerCom system with the call forwarding function already configured is updated to version 2.1.0 or higher, in order to take advantage of the new features of the function it is necessary: • scan the QR code on the letter sent by the administrator if CallMe Manager is used; •...
Page 403 7.1.12.1 Configuring call forwarding function with CallMe Manager application support Below are the various actions to perform to correctly configure the function. 1. INSTALLER • Connect a router to the IPerCom system network that can provide Internet access; • Installation of the IPerCom Installer Tools PC application; •...
Page 404 Configuration of the system and parameters of the call forwarding function (installer) Using the IPerCom Installer Tools application, the installer creates the project and the related configuration, that is defines the system topology, adds the devices on the topological nodes, assigns appropriate names to the devices, apartments, and topological nodes, creates the address books, the users, and activations, configure the parameters of the call forwarding function in the "System"...
Page 405 After carrying out the configuration, it is necessary to apply it to the system. To do this, you must first save the configuration and exit the configurator. Then select the “Configuration” tab and press the “Apply changes” button to transfer the configuration to the system: Figure 494: Configuration transfer After this, it is necessary to go to the “Urmet Cloud”...
Page 406 It is necessary to press the "Transfer site to Building Manager" button to transfer ownership of the site to the building manager, who with the CallMe Manager application will be able to configure the call forwarding service by printing the relevant letters. The following dialog box is shown in which it is necessary to enter the email with which the building manager registered with Urmet Cloud: Figure 496: transfer of the site to building manager By pressing the “Transfer ownership”...
Page 407 Import of the topological structure of the system and printing of letters (Building Manager) Below are illustrated the fundamental steps that the building manager must follow to allow residents to use the call forwarding function. For all information on managing users, refer to the user manual of the CallMe Manager application.
Page 408 By pressing the "OK" button, the homepage of the CallMe Manager application appears with the new site loaded: Figure 500: CallMe Manager app homepage By expanding the topological structure, it is possible to view all the topological nodes present in the system, that is blocks, stairs, floors, and apartments: Figure 501: topological structure of the system MT124-032N...
Page 409 Once the topology has been imported, it is necessary to generate the letters (pdf file) which must be sent via email or post to the users, to allow the association of the accounts with the apartments (via the CallMe app) and the use of the function call forwarding: to do this, press the “Print letters” button. Depending on the selected node, the letters of the users (and/or switchboard operator, if present) who are in the topological group of the node in question (including the node itself) are generated.
Page 410 Activating and enabling the call forwarding feature (end-user) Below the basic steps that the end-user must perform with the CallMe app, after receiving the letter from the building manager, to activate the call forwarding function are reported. For all information on configuring the app, refer to the relevant booklet on the website www.urmet.com.
Page 411 Once logged in with a newly created or existing account, the application homepage is displayed: Figure 504: application homepage Pressing the “Add a place” button the following screen appears: Figure 505: add of a place MT124-032N...
Page 412 Press the "Scanning the QR code" button to start the QR Code Reader application, then scan the QR code displayed in the letter sent by the building manager relating, for example, to the first apartment. The app shows the following screen: Figure 506: association of a place/apartment with the CallMe account If you want, you can change the name “Smith Family”.
Page 413 At this point on the video door phone, it is necessary to: • press the “Activate and Verify” button to activate the call forwarding function and verify its correct activation; • check that the apartment's master video door phone automatically shows (if the function is activated for the first time) the Remote mode icon;...
Page 414 7’’ VOG 1761/31-32-33, 7’’ MAX 1717/31-32-33-34-41, 10’’ MAX 1717/21-22-23, IDEO DOOR PHONE 7’’ B 1741/1-2-3 ASIC • Switch on the master video door phone display by pressing anywhere on the screen or by pressing the Home button. • If you are not already viewing the Video Door Phone page, press the icon to access the “Top Page”...
Page 415 • Press on the “Device Mode Settings” item: Figure 510: device mode settings • Press on the item “Call Forwarding Settings” and then on the item “Activate/Verify Call Forwarding service”: Figure 511: activation and verification of the call forwarding function MT124-032N...
Page 416 • Press the “ACTIVATE AND VERIFY” button and check that the following screen is shown for correct activation of the service: Figure 512: correct activation of the call forwarding function As a last step it is necessary to check that the icon appears at the bottom and top right of the master video door phone display as shown below: Figure 513: operating icon in “Remote”...
Page 417 1761/15-16-18-19 IDEO DOOR PHONE • Press the button twice to access the homepage, the following screen appears on the video door phone display: Figure 514: homepage • Press the buttons to select the following icon , then press the button to access the video door phone configuration menu: Figure 515: setting menu MT124-032N...
Page 418 • Press the button and select the “Call forwarding” item, press the button to confirm the selection. • The following screen appears on the display: Figure 516: activation and verification button • Press the “Activate and verify” item using the button and check that the following screen is shown for correct activation of the service: Figure 517: correct activation of the call forwarding function...
Page 419 As a last step it is necessary to check that the icon as shown below appears on the homepage of the master video door phone: Figure 518: operating icon in “Remote” mode On any slave video door phones, it is possible to view the “Remote” mode operating icon at the top right by pressing the button once with the screen off.
Page 420 1761/6 IDEO DOOR PHONE • Access the configuration menu by pressing and holding down the button for at least 5 seconds with the display off: Figure 519: configuration menu (first window) • Press the button to display the second window of parameter configuration: Figure 520: configuration menu (second window) MT124-032N...
Page 421 • Press the button in the second screen of the configuration menu, the display will show the following window: Figure 521: verify the correct activation of the call forwarding function • Press the “VERIFY ACTIVATION” item using the button and check that the following screen is shown for correct activation of the service: Figure 522: correct activation of the call forwarding function MT124-032N...
Page 422 As a final step, press the button and then the button and check that the icon appears on the homepage of the master video door phone at the top right, as shown below: Figure 523: operating icon in “Remote” mode On any slave video door phones, it is possible to display the operating icon in “Remote”...
Page 423 The QR code on PDF document sent by the building manager can only be used once. It cannot be used again after it has been scanned. The entire service activation procedure must be performed after scanning. If procedure is interrupted, the administrator will have to generate a new document with a new QR code to allow service activation.
Page 424 7.1.12.2 Configuring call forwarding function without CallMe Manager application support The configuration of the call forwarding function without the support of the CallMe Manager app is foreseen for all those types of systems in which there is no building manager. Below are the various actions to perform to correctly configure the function.
Page 425 Configuration of the system and parameters of the call forwarding function (installer) Using the IPerCom Installer Tools application, the installer creates the project and the related configuration, that is defines the system topology, adds the devices on the topological nodes, assigns appropriate names to the devices, apartments, and topological nodes, creates the address books, the users, and activations, configure the parameters of the call forwarding function in the "System"...
Page 426 After carrying out the configuration, it is necessary to apply it to the system. To do this, you must first save the configuration and exit the configurator. Then select the “Configuration” tab and press the “Apply changes” button to transfer the configuration to the system: Figure 525: configuration transfer MT124-032N...
Page 427 Activating and enabling the call forwarding feature (end-user) Below the basic steps that the end-user must perform with the CallMe app to activate the call forwarding function are reported. For all information on configuring the app, refer to the relevant booklet on the website www.urmet.com.
Page 428 Once logged in with a newly created or existing account, the application homepage is displayed: Figure 527: Create an account or log in Pressing the “Add a place” button the following screen appears: Figure 528: add of a place Press the "Scanning the QR code" button to start the QR Code Reader application, then scan the QR code displayed on the apartment video door phone.
Page 429 7’’ VOG 1761/31-32-33, 7’’ MAX 1717/31-32-33-34-41, 10’’ MAX 1717/21-22-23, IDEO DOOR PHONE 7’’ B 1741/1 ASIC • Switch on the master video door phone display by pressing anywhere on the screen or by pressing the Home button. • If you are not already viewing the Video Door Phone page, press the icon to access the “Top Page”...
Page 430 • Press on “Device Mode Settings” item: Figure 531: device mode settings • Press on the item “Call Forwarding Settings” and then on the item “Activate/Verify Call Forwarding service”: Figure 532: QR code for call forwarding function activation MT124-032N...
Page 431 1761/15-16-18-19 IDEO DOOR PHONE • Press the button twice to access the homepage, the following screen appears on the video door phone display: Figure 533: homepage • Press the buttons to select the following icon , then press the button to access the video door phone configuration menu: Figure 534: configuration menu MT124-032N...
Page 432 • Press the button and select the “Call forwarding” item, press the button to confirm the selection. • The following screen appears on the display: Figure 535: QR-code to associate the account with the apartment MT124-032N...
Page 433 1761/6 IDEO DOOR PHONE • Access the configuration menu by pressing and holding down the button for at least 5 seconds with the display off: Figure 536: configuration menu (first window) • Press the button to display the second window of parameter configuration: Figure 537: configuration menu (second window) MT124-032N...
Page 434 • Press the button in the second screen of the configuration menu, the display will show the following window: Figure 538: QR-code to associate the account with the apartment MT124-032N...
Page 435 After scanning the QR-code (in one of the three cases above), the app shows the following screen: Figure 539: association of a place/apartment with the CallMe account MT124-032N...
Page 436 If you want, you can change the name “Smith Family”. By pressing the “Save name and proceed” button, the CallMe application home page appears as shown below: Figure 540: the account has been associated with the apartment At this point on the video door phone, it is necessary to: •...
Page 437 The "Activate and Verify" button is located on the same screen where there is the QR-code associating the CallMe account with the apartment. Once pressed, the correct outcome of the operation is indicated by the following dialogue box depending on the different models of video door phone: Figure 541: correct activation of the call forwarding function on video door phones 1717/xx - 1761/3x - 1741/x Figure 542: correct activation of the call forwarding function on video door phones 1761/1x MT124-032N...
Page 438 Figure 543: correct activation of the call forwarding function on video door phones 1761/6 As a final step, it is necessary to check that the “Remote” mode operating icon appears on the master video door phone as shown below depending on the different types of video door phone models: Figure 544: "Remote"...
Page 439 Figure 545: "Remote" mode operation icon on video video door phones 1761/15-16-17-18 On any slave video door phones, it is possible to view the “Remote” mode operating icon at the top right by pressing the button once with the screen off. If operation in “Remote”...
Page 440 Figure 546: "Remote" mode operation icon on video video door phones 1761/6 On any slave video door phones, it is possible to display the operating icon in “Remote” mode in the same way as seen for the master video door phone. If operation in “Remote”...
Page 441 7.1.13 Configuring the call forwarding function in IPerCom systems in IPerCloud mode The configuration of the call forwarding function in IPerCom system in IPerCloud mode requires the mandatory use of the following applications to be used in the following order: •...
Page 442 2. BUILDING MANAGER • Install the CallMe Manager application on the PC; • Create an Urmet Cloud account via CallMe Manager and authenticate on CallMe Manager with this account; • Acquire the site created by the installer via the CallMe Manager app; •...
Page 443 What the installer must do Using the IPerCom Installer Tools application, the installer creates the configuration associated with the project, that is defines the system topology, adds the devices on the topological nodes, assigns appropriate names to the devices, IPerCloud apartments and topological nodes, creates the address books, the residents, not residents, and activations, configure the parameters of the call forwarding function in the "System"...
Page 444 After carrying out the configuration, it is necessary to apply it to the system. To do this, you must first save the configuration and exit the configurator. Then select the “Configuration” tab and press the “Apply changes” button to transfer the configuration to the system: Figure 548: configuration transfer After applying the configuration to the system, the installer must carry out the test mode: this mode is useful for verifying that the call from any calling station to a test IPerCloud apartment arrives correctly at...
Page 445 Once logged in, this screen appears: Figure 549: log in to app CallMe Pressing button “Add a place”, the following window appears: Figure 550: add a place MT124-032N...
Page 446 Press button “Scanning the QR code” to run app QR code reader. Then press the “IPerCloud Test QR Code” button displayed on IPerCom Installer Tools. The following window appears: Figure 551: scan the test mode QR Code Then scan the QR code displayed on the PC where the IPerCom Installer Tools application is installed. After scanning the QR code, the following screen appears on smartphone/tablet of the installer to indicate that the place has been added correctly: Figure 552: place added...
Page 447 The default name given to the place is “IPerCloud Test” but it is possible to rename it (even later): at this point the CallMe app has been associated with a (not real) IPerCloud test apartment. The installer can therefore make a call from any calling station to the IPerCloud test apartment: in fact, on all calling stations with displays the relevant address book displays only the name "IPerCloud Test"...
Page 448 After that, go to tab “Urmet Cloud” in the section IPerCloud Management: Figure 553: IPerCloud management In this section the installer pre-activates a license bundle for the system by pressing the "Pre-Activate license bundle" button. The following window opens: Figure 554: license bundle pre-activation In the ''License Bundle Serial Number'' field it is necessary to enter the serial number of the license bundle for pre-activation by the installer.
Page 449 After entering the serial number, pressing the "PRE-ACTIVATE NOW" button, and accepting the license agreement relating to the IPerCloud software (End User License Agreement), the positive outcome of the pre-activation is confirmed by the following message: Figure 555: bundle license pre-activation with serial number Once the pre-activation of the licenses has been completed, the installer must install the CallMe Manager application: the application and the related user manual are available on the website www.urmet.com...
Page 450 By pressing the "OK" button, the home page of the CallMe Manager application appears with the new site loaded: Figure 558: CallMe Manager home page (installer login) By expanding the topological structure, it is possible to view all the topological nodes present in the system, that is blocks, stairs, floors, and apartments: Figure 559: plant topological structure MT124-032N...
Page 451 The topological node icons are displayed in red to indicate that the topological structure contains Ipercloud apartments to which a license has not yet been associated. More precisely, the icons of the nodes located on the topological path of the IPerCloud apartments are colored red. Hybrid apartments (i.e.
Page 452 The following window is shown: Figure 561: license wallet window To activate one or more license bundles, it is necessary to know the activation code (A/C) shown on the license card as shown below: Figure 562: license bundle activation code To view the activation code, you need to scratch the silver band next to the red arrow with a coin.
Page 453 At this point, simply enter the activation code in the relevant field and press the "Activate" button: Figure 563: license bundle activation request The correct outcome of the procedure is confirmed by the following dialog box: Figure 564: license bundle activated successfully MT124-032N...
Page 454 By pressing the “OK” button, the license is added to the installer's wallet: Figure 565: license added to installer wallet All the information relating to the newly activated license bundle is displayed in the red box, that is: • Bundle: identifies the serial number of the Ipercloud license bundle (entered during the pre-activation phase);...
Page 455 After activating a license bundle, it is necessary to associate the single licenses with the apartments. To do this, simply select the topological node where the IPerCloud apartments are present (in this case "Floor 010100") and press the "Licenses" button: Figure 566: license association The following window is shown: Figure 567: list of apartments to which to assign a license...
Page 456 In the Target Selection section, you can choose whether: • assign licenses to all the apartments present on the topological node “Floor 010100” (item “Process all apartments”), • assign licenses to only the selected apartments (item “Process only selected apartments”). In the License Operation section, select the item "Assign licenses to apartments".
Page 457 By pressing the “OK” button, the following screen appears: Figure 569: topological structure after assigning licenses to the apartments After assigning licenses to apartments, the topological node icons are displayed in black to indicate that licenses have been assigned to Ipercloud apartments. By selecting a single apartment, you can view the single license in use: Figure 570: single license associated with an apartment MT124-032N...
Page 458 The “Info” button allows you to view all the information on the license in use by the apartment: Figure 571: information about the assigned license The "Activation date" and "License expiry date" fields will be filled in as soon as the end user associates the account (created to authenticate on the CallMe app) with the apartment via the letter with QR code sent by the building manager.
Page 459 The "Transfer site ownership" button allows you to transfer the site to the building manager, who with the CallMe Manager application will be able to print the letters to send to the residents in the apartments. By pressing this button, the following dialog box is displayed in which it is necessary to enter the email with which the building manager has already registered with Urmet Cloud: Figure 573: transfer of the site to building manager By pressing the “Transfer ownership”...
Page 460 What the building manager must do Below are illustrated the fundamental steps that the building manager must follow to allow residents in IPerCloud apartments to use the call forwarding function. For all information on managing users, refer to the user manual of the CallMe Manager application. The building manager must download the CallMe Manager application and the related user manual from the website www.urmet.com.
Page 461 By pressing the "OK" button, the homepage of the CallMe Manager application appears with the new site loaded: Figure 577: CallMe Manager app homepage By expanding the topological structure, it is possible to view all the topological nodes present in the system, that is blocks, stairs, floors, and apartments: Figure 578: topological structure of the system MT124-032N...
Page 462 Once the topology has been imported, it is necessary to generate the letters (pdf file) which must be sent via email or post to the users, to allow the association of the accounts with the apartments (via the CallMe app) and the use of the function call forwarding: to do this, press the “Print letters” button. Depending on the selected node, the letters of the users (and/or switchboard operator, if present) who are in the topological group of the node in question (including the node itself) are generated.
Page 463 What the building manager can still do (optional) If in the topological structure shown on the left side of the CallMe Manager application, the building manager selects the node that shows the name of the system (red arrow), the following screen appears: Figure 580: new features for building manager The red box shows two new features for the building manager which are explained below.
Page 464 In this way the installer can make changes to the configuration via IPerCom Installer Tools but cannot apply them to the system. If the installer authenticates on Urmet Cloud via IPerCom Installer Tools, the "Urmet Cloud" tab shows the information that he has been suspended from making changes to the system, as shown below: Figure 582: temporary installer suspension displayed in IPerCom Installer Tools Once suspended, the building manager can re-enable the same installer via the "Restore installer access"...
Page 465 What the end-user must do Below the basic steps that the end-user must perform with the CallMe app, after receiving the letter from the building manager, to activate the call forwarding function are reported. For all information on configuring the app, refer to the relevant booklet on the website www.urmet.com.
Page 466 Once logged in with a newly created or existing account, the application homepage is displayed: Figure 585: application homepage Pressing the “Add a place” button the following screen appears: Figure 586: add of a place MT124-032N...
Page 467 Press the "Scanning the QR code" button to start the QR Code Reader application, then scan the QR code displayed in the letter sent by the building manager relating, for example, to the first apartment. The app shows the following screen: Figure 587: association of a place/apartment with the CallMe account It is possible to change the name “Smith Family”.
Page 468 The main features of the CallMe app are listed below: • call forwarding to the apartment on smartphone/tablet; • auto-insertion on calling stations; • intercom call to apartment stations; • sending activation commands; • door and gate opening even outside of the call. Auto-insertion on RTSP cameras is not supported by CallMe app.
Page 469 7.1.14 Search function The function allows a quick search of the items in the system. Press on the main screen of the configurator to open the following screen (relating to a generic system): Figure 589: Search Function Screen You can search for the following items or only one of them: •...
Page 470 Furthermore, only for the devices, it is possible to further filter by MAC address or part of it or by device code (that is 1060/12 for the Call Module). The “Entries Matching” field shows the number of elements found depending on the selected entries (red box).
Page 471 The device search shows the various devices present in the system with the corresponding topological code (block, stair, floor, and apartment), device code (column "D") and device type: Figure 592: search for device If the device is located on the site node, the table above only shows the device code and not its topological path.
Page 472 7.1.15 How to save the configuration After creating the configuration, it is possible to save it through the "Project" tab of the configurator. The screen displayed is as follows: Figure 593: project sheet Press the "Save" button to save the configuration. The "Exit"...
Page 473 8 Commissioning a system through MAX, VOG or Basic video door phones: the configuration menu MAX, VOG or Basic video door phones configuration menu allows commissioning an IPerCom system. From version 3.1.0 this is only possible if the two conditions below are met: •...
Page 474 Mode 1: Access to the configuration menu from the start screen page of non- configured MAX, VOG or Basic video door phones Non-configured MAX 1717/2x, MAX 1717/3x and VOG video door phones upon starting show a screen like the one below: Figure 594: start screen of an unconfigured VOG and MAX 1717/3x video door phone In addition to the “IPerCom”...
Page 475 The “LANGUAGE” button allows you to change the video door phone language, choosing one from those shown in the relevant list: Figure 595: selection of the device language The language thus chosen is immediately applied to the video door phone. The “IPerCom”...
Page 476 MAX 1717/4x and Basic video door phones that are not configured at startup show a screen like the one below: Figure 597: start screen of an unconfigured Basic and MAX 1717/4x video door phone For these video door phones there is no “CallMe” button and they start directly in IPerCom mode. In both cases, from this screen it is possible to access the configuration menu via the “CONFIGURATION”...
Page 477 8.1.1 Date and time setting The first step of the system commissioning is to set the correct date and time. Date and time are used to identify configuration files and determine which one is the most up-to-date during the automatic distribution between devices; therefore, as already mentioned, it is essential to set them correctly before proceeding with the following steps.
Page 478 First set the time zone. Select the desired item from the convenient drop-down menu in the section highlighted with red edge, as shown in figure: Figure 600: Choose of time zone Press the "CONFIRM" button to confirm the selection of the time zone and enable the section highlighted with the blue border to set the date and time is enabled.
Page 479 The time zone setting will be applied only to the current device. The time zone of the whole system is selected during configuration, as shown in paragraph System parameters. Therefore, in addition to setting the time zone using the MAX, VOG or Basic video door phone as shown, it is also recommended to confirm your selection of the time zone using the configurator, so that the entire system is set to the desired date and time.
Page 480 The sub-menu “System configuration” is structured as follows: Figure 603: “System configuration” sub-menu (part 1) Figure 604: “System configuration” sub-menu (part 2) This menu allows you to: 1. change the system date and time; 2. import the configuration from another already configured device in the network; 3.
Page 481 The “SD card projects management” sub-menu is as follows: Figure 605: “SD card projects management” sub-menu This sub-menu allows you to: 1. modify IPerCom configuration projects on SD card 2. create a project to be saved directly on SD card. These operations allow you to use the MAX, VOG or Basic video door phone as a configuration editor regardless of which system is installed.
Page 482 8.2 Access to the configurator from the MAX, VOG or Basic video door phone Access to the configurator from MAX, VOG or Basic video door phone is carried out with the "Create configuration" item if the system is not configured or with the "Change current configuration" item if the system has already been configured.
Page 483 If the system has already been configured and the MAX, VOG or Basic video door phone is part of it, by changing the current configuration the configurator will open with the configuration on the system (after entering the installer password): Figure 607: Opening a Multi Block configuration using the configurator As mentioned in the paragraph "Configuration...
Page 484 By selecting the desired file name, the configurator will open and show the contents of the chosen configuration. If you open a file with ccf extension created through the IPerCom Installer Tools version 3.0.0 configurator and with CallMe Manager support enabled, it is not possible to make any changes to the configuration except through the same configurator started by IPerCom Installer Tools, as shown in the following message: Figure 609: configuration not editable...
Page 485 If instead the configurator is open as configuration editor (that is from the "SD card projects management '' submenu), the ''Project'' tab appears as follow: Figure 611: “Project" screen of the configurator in editor mode In case a configuration has been suspended while using a MAX, VOG or Basic video door phone, as soon as you launch the application again you will be asked whether to recover the last interrupted configuration project.
Page 486 8.2.1 The configurator on Android tablets The configuration of an IPerCom system can also be made through Android tablet (minimum version required 5.0) with the IPerCom Configurator app downloadable from Play Store. For each officially released version of IPerCom the app, through a "launcher", allows you to: •...
Page 487 Press the "Settings" button to install the configurator versions related to the IPerCom version you want to work with. The screen displayed, in fact, is as follows: Figure 614: list of the various configurators that can be installed For example, if you want to install the configurator version related to IPerCom versions 1.4 and 2.0, simply press the relevant "Install"...
Page 488 To finish the installation correctly, it is necessary to press the "END" button, which brings back to the initial screen of the IPerCom Configurator app. The "Open" button does not allow you to launch the newly installed configurator version as this can be done only from the IPerCom Configurator app (by opening a configuration file or creating a new one).
Page 489 The "New" button allows you to select the IPerCom version for which you want to create the new configuration (depending on the previously installed configurator versions). Then, in relation to the above, by pressing the "New" button, the following screen is displayed: Figure 618: choice of the configurator version to start After selecting one of the proposed versions, the previously installed configurator for the selected IPerCom version is launched.
Page 490 After entering all the data correctly, it is possible to press the "OK" button to start creating the new configuration as described in paragraph configurator. Once the configuration is finished, the Project tab of the configurator allows you to: • save the project (Save and Save As buttons);...
Page 491 The "Open" button allows you to open, convert and edit previously created configuration files. Once identified and selected the file to open (with ccf extension) through the file manager of the tablet, the following screen opens: Figure 621: open a configuration file already saved To open the configuration file without converting it to a later version of IPerCom, it is necessary to enter the installer password for the project and press the "OK"...
Page 492 If you also want to convert the file to a later IPerCom version (whose configurator version has been installed through the "Settings" button), it is also necessary to select the "Convert the file to another IPerCom version". Then by pressing the “OK” button, the following screen opens: Figure 623: conversion of the configuration file to a higher version Only the IPerCom versions higher than the one related to the file you are opening and whose configurator version has been installed as described above are automatically shown.
Page 493 When the modifications have been completed, in the Project tab it is always possible to: • save the project (Save and Save As buttons); • close the project (Close button) to open another one; • directly quit the configurator (Quit button) to return to the “launcher”. It is not possible to open configuration files related to IPerCom versions whose configurator has not been installed through the "Settings"...
Page 494 8.3 System first configuration This section describes the steps to be followed when configuring an IPerCom system for the first time referring both to the MAX, VOG or Basic video door phone and to the IPerCom Configurator app. When doing this, all devices must have the factory settings; otherwise, it is necessary to reset to the factory settings (see chapter Restoring the factory settings).
Page 495 8.3.1 Creation of a new configuration: definition of the system topology To create the first configuration on a MAX, VOG or Basic video door phone it is necessary to access the configuration menu, then to “System configuration” and choose “Create configuration”, as shown in the figure: Figure 625: Creation of the first system project on MAX video door phone Confirming the request will open the screen for creating a new project.
Page 496 You get to the same screen if you want to use an Android tablet and then the IPerCom Configurator app to create a new project. Once the app starts, it is necessary to press the New button and then select the IPerCom version for which you want to create the new configuration.
Page 497 To add the various devices of the system from MAX, VOG or Basic video door phone in the configuration, it is advisable to follow one of the 4 methods described in the following paragraph, being understood that also from MAX, VOG or Basic video door phone the same rules described for IPerCom Installer Tools are valid, i.e.: •...
Page 498 8.3.2 Adding devices to the system using the MAX video door phone and/or the Android tablet app To add all the devices of the system to the configuration, it is advisable to follow one of the 4 procedures below. In this way, you can speed up the configuration operations by exploiting some features of the MAX, or Basic video door phones and the Android tablet app.
Page 499 The following selection screen will be displayed, allowing to choose the type of device to add. Figure 630: Selecting the type of device to add To add a MAX video door phone, select “Video door phone 7’’ MAX 1717/31-32-33-34-41”. The following screen page will then open: Figure 631: Entering device parameters The "Name”, "MAC Address”, "Device Code", and "Location"...
Page 500 In this case, simply fill in the fields "Name” and "MAC Address" to add the device: the field "Name” is arbitrary and chosen by the installer, the field "MAC Address" instead is well defined and associated with the device in use. To enter the latter parameter, in this case you do not need to know the single digits, as there is a quick selection button "...”...
Page 501 By pressing "OK", the device is added to the device list of the configuration. Figure 634: List of devices for the selected apartment 2. Adding other device types to the configuration When the first MAX video door phone has been added, a similar procedure is to be followed to add all other devices installed in the system.
Page 502 This time you need to know the MAC address of the device to be added to fill in the relevant field; there are therefore two possible modes to fill it in: • manually entering the MAC address digits, or • pressing the "..."...
Page 503 So, to proceed with a second MAX video door phone, you will need to access the configuration menu, then go to "System configuration” and "Import configuration from remote device”: a screen like the following one will appear. Figure 637: Importing the configuration from a remote device A list of devices from which to import the configuration is displayed: by pressing on the configured MAX video door phone and confirming the request, the configuration will be imported into the system.
Page 504 8.3.2.2 Mode 1.1: The installer creates the configuration in the laboratory on the MAX video door phone/PC/Android tablet and adds the devices to the configuration via the MAX video door phone Application case: The devices are already installed on the plant, but not yet configured. There is a basic configuration on SD Card in which the topology has been defined but the devices have not been added yet Pro: It is not necessary to know the physical MAC addresses of the MAX video door...
Page 505 8.3.2.3 Mode 2: The installer creates the configuration in the laboratory on the MAX video door phone/PC/Android tablet but adds the devices via Android tablet Application case: The devices are already installed on the plant, but not yet configured. There is a basic configuration on SD Card in which the topology has been defined but the devices have not been added yet.
Page 506 Figure 638: Adding a new device on Android tablet By pressing this button, the "Barcode Scanner" app will start (if it is not in the system, the system will automatically prompt to install it through Google Play Store). When you open the app you have to position the camera in front of the QR Code of the device and wait for the scan and the automatic filling in of MAC address: Figure 639: Automatic entering of the MAC address from the scanned QR Code...
Page 507 Configuration file extension: when saving the configuration you must assign a name to the file created; the default name of the file is "ipercom.ccf", but it can be changed by the user only by paying attention to always add the extension ".ccf" at the end of the name (otherwise the configuration cannot be imported from the MAX monitor.
Page 508 8.3.2.5 Mode 3.1: The installer creates the configuration in the laboratory on the MAX video door phone/PC/Android tablet and adds at the same time the previously installed devices Application case: The devices have already been installed, taking note of the topological position (block/stair/floor/apartment) and of the relevant MAC.
Page 509 8.3.2.6 Mode 4: One MAX video door phone with configurator in "Acquisition" mode Application case: The devices are already installed on the system. The configuration has already been created/imported on a MAX video door phone and the same MAX video door phone and all other devices have been added.
Page 510 The following window will open: Figure 641: Acquisition mode The selected MAX video door phone then sets to the "Acquisition" mode where it waits for all non- configured MAX video door phones to communicate their position in the system. In fact, as soon as this mode is started, all the other MAX video door phones of the system not yet configured will display the following window: Figure 642: Entering the topology node in non-configured MAX video door phones during acquisition mode No selections can be made in the Villa Kit type projects in the window shown in figure.
Page 511 3. Sending the position from all other MAX video door phones to the selected MAX video door phone For all MAX video door phones of the system, except the selected one, it will be necessary to fill in the fields shown in the previous figure and press "SEND LOCATION"...
Page 512 8.4 Configuration distribution The configuration is always distributed via MAX, VOG or Basic video door phone, and can be done in two ways: • directly from the configurator (if you are changing the configuration from a MAX, VOG or Basic video door phone connected to the system);...
Page 513 To import a configuration from SD card, access the configuration menu, then select the option "Import configuration from SD card": the window shown in the figure will open. Figure 645: Configuration distribution by importing from SD card The window shows all the configuration files saved on the SD card: once the desired file has been selected and the configuration distribution request has been confirmed, it will be applied to all the system devices.
Page 514 This window shows in sequence: • the “Devices with the same configuration”, i.e. devices that at that moment have the same configuration present on the current device; • the “Devices not in configuration”, i.e. devices that have not been included in the configuration present on the current device;...
Page 515 8.5 Exporting the configuration to an SD card It is recommended to make always a copy of the configuration on a file by means of export to SD card. To this purpose, in the configuration menu, in the sub-menu "System configuration” there is the function "Export configuration to SD card", which allows saving the current configuration to the SD card.
Page 516 8.6 Securing the system Once the system configuration has been completed and distributed to all the devices, i.e. while the system is running, it is possible to secure the system by setting an administrator password in addition to the installer password. In practice this means that the installer can only make changes to the configuration and the system by requesting the administrator password.
Page 517 As soon as the value of the last two fields is zero, the password distribution will be completed. Once you have changed the password in the system, to access the configurator you will need to enter the administrator password and no longer the Urmet password. 8.7 Changing the system configuration Once the first configuration of a system has been created, all the devices that make it up work as set in the configuration and any changes are made after entering the administrator password.
Page 518 8.7.1 Unlocking a system To unlock a previously blocked system, open the configuration menu from a MAX, VOG or Basic video door phone belonging to the system, then select "System configuration" and then "Password management": the following screen will open. Figure 652: “Password management"...
Page 519 8.7.2 How to change the configuration The configuration of a system can be changed in different ways: 1. by updating the users from the Switchboard application installed on the system; 2. by opening the configurator from the configuration menu of a MAX, VOG or Basic video door phone installed in the system;...
Page 520 Exporting to SD card creates a file with CCF extension, which can be opened by clicking on "Open” in the "Project” tab of the configurator. Figure 655: Opening a project from the configurator for MS Windows Once the configuration changes have been made, in the "Project” tab, press the "Save” button to overwrite the project file on the SD card.
Page 521 Modification of the configuration off-site): After having exported the current system configuration to change it off-site, the system may change its present configuration (via Switchboard or MAX, or Basic video door phone). In this case, loss of data may occur if you import the configuration modified off-site to the system.
Page 522 8.7.4 Changing the installer password Changing the installer password is necessary if the administrator decides to change the installer or if the installer has forgotten the password. In both cases the password change does not require that you know the previous one. To change the installer password, open the configuration menu from a MAX, VOG Basic video door phone belonging to the system, then select "System configuration"...
Page 523 Now simply enter and confirm the new password. Press the "CONFIRM" button and wait for the distribution of the new installer password to all the devices in the system. It is possible to monitor the status of this distribution in the dialogue box shown below: Figure 660: new installer password distribution As soon as the value of the last 2 fields is zero, the password distribution will be completed.
Page 524 8.7.5 Devices not aligned to the same IPerCom version or UPTK software development platform The possible presence of a misalignment between the UPTK versions of the devices and/or software applications is also signalled by the video door phones, which compare them with their own local UPTK version.
Page 525 The misalignment is not reported by the configured video door phones already present on the system: this is to avoid compromising the functioning of the system itself. If the device connected and not updated to the same IPerCom version of the system is a video intercom, this signals the misalignment with the rest of the system, as shown below: Figure 661: misalignment signalling on video door phone not present in the system configuration Press the “Status”...
Page 526 The misalignment is signalled by the configured video door phones already present on the system in the same way as seen in the previous point. For example, if only one device is added that is not aligned and present in the system configuration, the video intercoms already present in the system report the following signal: Figure 663: misalignment reporting on video door phone already present on the system By pressing the "STATUS"...
Page 527 The IPerCom version of the device just connected (8.22) is not aligned with that of the system (8.26). Also in this case, if the connected device that is not updated to the same IPerCom version of the system is a video door phone, this signals its misalignment with respect to the rest of the system, as shown in Figure 662.
Page 528 The misalignment is reported both by the software application and by the video door phones configured in the same ways described in the previous points. For example, if the Switchboard application has not been updated to the latest IPerCom version present on the system, after connecting to the system itself, the configured video door phones already present on the system report the following signal: Figure 665: misalignment reporting on video intercom for Switchboard application not aligned with the UPTK version of the system By pressing the "STATUS"...
Page 529 Similarly, the Switchboard application displays a similar window with the list of system devices that are not aligned with your version of UPTK (for further details see the Switchboard installation and use manual which can be downloaded from the website www.urmet.com). In all three cases reported above, the VOG 1761/6 and VOG 1761/15-16-18-19 video door phones...
Page 530 • Sending activation commands from iPerTAlk extensions to IPerCom Relay Actuators (only during conversation). Integration with the IPerCom 3.1.0 system is only supported by iPerTAlk version 2.2.10 or higher. Two integration modes are possible: • with iPerTAlk switch Ref. 1375/701 in presence of an internal network in the iPerTAlk system and you want to separate the network where iPerTAlk is installed from the IPerCom network;...
Page 531 9.1 Configuration and installation sequence for integration of the iPerTAlk system into the IPerCom system with the switch Ref. 1375/701 The following configuration steps must be followed for proper operation. 9.1.1 iPerTAlk system configuration Configure the iPerTAlk system consisting of PBX, router, switches, and phones. 1.
Page 532 9.1.2 IPerCom system configuration 1. Switch off the IPerCom system and the IPerTalk system. 2. Connect the iPerTAlk switch Ref. 1375/701, the PBX, router, switches, and phones to the IPerCom. network. Warning! For a correct integration of the iPerTAlk system with the IPerCom system, exclusively follow the instructions in the following connection diagram.
Page 533 Figure 669: example of IPerCom network setup 6. In the “Topology” tab create the topological structure of the system and identify a topological node for Server iPerTalk V1 (for example “Block 01” -- > “Stair 01” -- > “Floor 01”). 7.
Page 534 Figure 671: iPerTAlk ID configuration 9. Proceed with the configuration of the IPerCom calling stations and other IPerCom devices. MT124-032N...
Page 535 9.2 Configuration and installation sequence for integration of the iPerTAlk system into the IPerCom system without the switch Ref. 1375/701 The following configuration steps must be followed for proper operation. 9.2.1 IPerCom system configuration Configure the IPerCom system without connecting the iPerTAlk Server V1. 1.
Page 536 Figure 673: iPerTAlk ID configuration 6. Proceed with the configuration of the IPerCom calling stations and other IPerCom devices. MT124-032N...
Page 537 9.2.2 iPerTAlk system configuration 1. Switch off the IPerCom system. 2. Connect the PBX and phones to the switch in the IPercom system. Figure 674: IPerCom connection diagram - iPerTAlk without iPerTAlk switch Ref. 1375/701 3. Power the system up. 4.
Page 538 9.3 Auto-on function on iPerTAlk RTSP cameras from IPerCom video door phones The integration of the IPerCom system with the iPerTAlk system allows you to do the auto-on function on iPerTAlk RTSP cameras from IPerCom video door phones. After having correctly configured the IPerCom and iPerTAlk systems (as described in the previous paragraphs), the steps below must be followed via the IPerCom configurator so that IPerCom video door phones can also perform the auto-on function on RTSP cameras of iPerTAlk system.
Page 539 Figure 676: creation of a contact calling the iPerTAlk apartment with RTSP camera in the apartment with video door phone 1761/16 2.B Press the “Contact” tab on the configurator and, in the VOG video door phone directory, add a contact that has the iPerTAlk apartment created in the previous step as recipient, and in the “Visibility Filter”...
Page 540 Distribute the configuration on the Ipercom system. In this way the MAX, VOG , VOG , Basic e IPerCom Client video door phone directories will show the contact (with the same name given during the creation phase) that will enable the auto-on function on the RTSP camera.
Page 541 10 Restoring the factory settings If devices are removed from the system or you want to restore the factory settings, it is necessary to make a restore to the factory settings, or easier factory reset. MT124-032N...
Page 542 10.1 Factory reset of MAX, VOG , Basic video door phone and IPerCom Client app To perform the factory reset it is first necessary to access the settings menu. Figure 678: Settings menu Select the "Maintenance" option, then "Factory Reset". After entering the administrator password (or Urmet password if the system is not locked), the MAX video door phone will start the factory reset process and restart.
Page 543 10.2 Factory reset of video door phone VOG To perform a factory reset of the VOG video door phone, access the Homepage by pressing the key twice. The display shows the following screen: Figure 680: Homepage Use keys to select the button and press the key (OK).
Page 544 Use the keys to select “Reset factory settings”, then press the key (OK). The following screen is displayed: Figure 682: Restoring the factory reset Press the keys to select which video door phone parameters you want to reset to factory values.
Page 545 10.3 Factory reset of video door phone VOG To perform a factory reset of the VOG video door phone, access the configuration menu: Figure 684: configuration menu - part 1 Press the key to move to the screen page 2 of the configuration menu: Figure 685: configuration menu - part 2 Press the key again to move to screen page 3 of the configuration menu:...
Page 546 Press the key 2 in the screen page 3 of the configuration menu. The display shows the following screen: Figure 687: Confirm factory reset Press the key to confirm the reset to factory settings of the device. The reset to factory settings can be carried out also via the Ipercom Installer Tools application (button of the Diagnostic tab).
Page 547 10.4 Factory reset of Door Phones Miro To restore default parameters of a Miro door phone after entering programming mode, hold button T1 pressed for longer than 5 seconds, hold buttons pressed for longer than 5 seconds. The device will generate 2 long beeps and reboot. Figure 688: Miro door phone The reset to factory settings can be carried out also via the Ipercom Installer Tools application (button...
Page 548 10.5 Factory reset of Call Modules 1060/12-13-17-18-23 The factory reset of the Call Modules can be carried out in two different steps: 1. during device startup 2. when the device is started and configured Figure 689: Call Module In the first case, during the start-up phase, the following screen is shown for five seconds: Figure 690: Call Module start screen If during this time the buttons "X”...
Page 549 In the second case it is assumed to have a configured Call Module already started, as shown in the figure: Figure 691: Main screen of a configured Call Module In this case, press the "0" button twice in rapid succession. A screen will be shown where you can enter the administrator password (if the system is blocked, otherwise you need to enter the Urmet password).
Page 550 Once the password has been entered and the "OK" button pressed, a screen opens where to select "CALL MODULE”: press "OK” again to access the following Call Module maintenance menu. Figure 693: Call Module maintenance menu By selecting "RESET ALL SETTINGS" and pressing the "OK” button, you will be asked to confirm the action. Figure 694: Factory reset confirmation screen Press the "OK”...
Page 551 10.6 Factory reset of the Modular Entry Panel with 1060/48 The factory reset of the Modular Entry Panel with 1060/48 can be done via the Outdoor Audio and Video IP Station 1060/48 or via the Display Module 1168/1 (below): Figure 695: Audio Video IP outdoor station (on the left) and Display Module (on the right) 10.6.1 Factory reset via the Outdoor Audio and Video IP Station 1060/48 There are 3 ways to perform a factory reset and they are listed below.
Page 552 Mode 2: factory reset with call button (Modular Entry Panel with 1060/48 OFF) Press the call button on the right (indicated in the figure with the red circle) of the Outdoor Audio and Video IP Station 1060/48, turn on the device by continuing to hold down the relevant button until the orange LEDs begin to flash 6 times.
Page 553 10.6.2 Factory reset via the Display Module 1168/1 There are 2 ways to perform a factory reset and they are listed below. Mode 1: press the X-9 buttons (Modular Entry Panel with 1060/48 ON) Quickly press the X-9 buttons in sequence using the Numeric Keypad Module 1168/46. The Display Module 1168/1 shows a screen page where it is necessary to enter the Urmet or system administrator password (depending on whether the system is unlocked or locked).
Page 554 10.7 Factory reset of the Entry panels 1060/71-/74-75-78 To perform a factory reset of a Door Speaker Unit, press the entrance hall button and at the same time the second button of the keypad (the lowest button) for 20 seconds. Figure 699: Entry panels After 20 seconds, the device emits a beep before restarting;...
Page 555 10.8 Factory reset of IPerCom 2Voice Gateway Figure 700: IperCom 2Voice Gateway 1083/59 To perform a factory reset on a gateway, press the Reset button five times in a row (less than 1s in between). The device will be reset to default parameters; all configurations will be lost. Hold same button pressed for more than 10 seconds to make an hardware reboot the device.
Page 556 10.9 Factory reset of the lift interface 1060/37 Figure 701: Lift interface 1060/37 To perform the factory reset of the lift interface, press the Reset button for 5 times in a row (with intervals of less than 1s). The device resets to factory parameters and loses all the configurations made. The same button briefly pressed 1 time reboots the device hardware.
Page 557 10.10 Factory reset of the Entry panel 1060/33-34 Figure 702: Entry panel 1060/33 (on the left) and 1060/34 (on the right) To perform the factory reset of the Entry panel Ref. 1060/33-34 carry out the following operations in sequence: • switch the device off;...
Page 558 10.11 Factory reset of Entry Panel 1060/21 Figure 703: Entry Panel 1060/21 To perform a factory reset on an Entry Panel Ref. 1060/21, the following operations must be carried out in sequence: • Switch the device off. • Press and hold the call key and the hall key. •...
Page 559 10.12 Factory reset of Floor Entry Panel 1060/22 Figure 704: Floor Entry Panel 1060/22 To perform a factory reset on a Floor Entry Panel Ref. 1060/22, the following operations must be carried out in sequence: • Switch the device off. •...
Page 560 APPENDIX A: Configuration parameters of IPerCom devices Server 1060/1 Figure 705: Server 1060/1 settings The following table shows the meaning of the fields for Server 1060/1. Name Name to assign to the Server. MAC Address MAC address associated with the Server. IP Address IP address associated with the Server.
Page 561 Call Module 1060/12-13-17-18 Figure 706: Call Module 1060/12-13-17-18 settings (part 1) Figure 707: Call Module 1060/12-13-17-18 settings (part 2) MT124-032N...
Page 562 Figure 708: Call Module 1060/12-13-17-18 settings (part 3) Figure 709: Call Module 1060/12-13-17-18 settings (part 4) MT124-032N...
Page 563 The following table shows the meaning of the fields for Call Module 1060/12-13-17-18. General Settings Name Name to assign to Call Module. MAC Address MAC address associated to the Call Module. IP Address IP address associated to the Call Module. Field visible only if manual network configuration is set in system parameters.
Page 564 Main Door settings Enabled The item Yes enables the main door: in this case the following options are shown, marked with a hash mark (#). The item No disables the main door. Default value: Yes. Door Profile (#) This allows you to associate a previously created door profile with the concerned main door.
Page 565 Hall Button Settings Use Hall Button for calling If selected, it allows you to use the hall button to call the competence switchboard or switchboards of the system. concierge Remote Button (#) It allows you to remotely control the entrance hall button that opens the main door of the Call Module.
Page 566 End-user settings Show Address Book The item appears only if the call addressing mode is “Block Mode” and if the device is placed on a node other than the “Site” node. In this case, if the item is selected, the address book is shown on the call module;...
Page 567 There are two types of electric locks on the market: with automatic rearm or without automatic rearm. Installing a type of lock with automatic rearm and sending a door opening command, the door remains open only for the time established in the configurator (“Door Time (s)” parameter). After that time the lock rearms and the door is closed.
Page 568 Call Module 1060/23 Figure 710: Call Module 1060/23 settings (part 1) Figure 711: Call Module 1060/23 settings (part 2) MT124-032N...
Page 569 Figure 712: Call Module 1060/23 settings (part 3) Figure 713: Call Module 1060/23 settings (part 4) MT124-032N...
Page 570 The following table shows the meaning of the fields for Call Module 1060/23. General settings Name Name to assign to Call Module. MAC Address MAC address associated with the Call Module. IP Address IP address associated with the Call Module. Field visible only if a manual network configuration has been set in the system parameters.
Page 571 Main door settings Used In this case, the item Yes enables the main door: the following options are shown, marked with a hash mark (#). The item No disables the main door. Default value: Yes. Door Profile (#) It allows you to associate a previously created access profile to the main door in question.
Page 572 Hall Button Settings Use Hall Button for calling If selected, it allows you to use the hall button to call the concierge competence switchboard or switchboards of the system. Remote Button (#) It allows you to remotely control the entrance hall button that opens the main door of the Call Module.
Page 573 End user settings Show Address Book The item appears only if the call addressing mode is “Block Mode” and if the device is placed on a node other than the “Site” node. In this case, if the item is selected, the address book is shown on the call module;...
Page 574 RTSP In-Call stream settings RTSP In-Call stream If selected, the Switchboard application can display the RTSP video stream of the calling station during the call to an apartment station or during the auto-on from an apartment station. Fields marked with the hash mark (#) must be filled correctly.
Page 575 Modular Calling Station with 1060/48 Figure 714: Modular Calling Station with 1060/48 settings (part 1) Figure 715: Modular Calling Station with 1060/48 settings (part 2) MT124-032N...
Page 576 Figure 716: Modular Calling Station with 1060/48 settings (part 3) Figure 717: Modular Calling Station with 1060/48 settings (part 4) Figure 718: Modular Calling Station with 1060/48 settings (part 5) MT124-032N...
Page 577 Figure 719: Modular Calling Station with 1060/48 settings (part 6) Figure 720: Modular Calling Station with 1060/48 settings (part 7) MT124-032N...
Page 578 The following table shows the meaning of the fields for Modular entry panel with 1060/48. General settings Name Name to assign to the calling station. MAC Address MAC address associated with the calling station. IP Address IP address associated with the calling station. Field visible only if a manual network configuration has been set in the system parameters.
Page 579 Main door settings Used The item Yes enables the main door: in this case the following options are shown, marked with a hash mark (#). The item No disables the main door. Default value: Yes. Door Profile (#) It allows you to associate a previously created access profile to the main door in question.
Page 580 Hall Button Settings Use Hall Button for calling If selected, it allows you to use the hall button to call the concierge competence switchboard or switchboards of the system. Remote Button (#) It allows you to remotely control the entrance hall button that opens the main door of the Call Module.
Page 581 Gate settings Used The item Yes enables the gate: the following options are shown, marked with a hash mark (#). The item No disables the gate. The item “By door opening” allows you to use the relay contact of the driveway to open the main door. The Relay Actuator item allows you to use the gate relay output as the output (only in monostable mode) of a Relay Actuator: in this case the item marked with the symbol (§)
Page 582 End user settings Integrated call buttons The 2 calling station buttons can be enabled or disabled as shown below: -) both disabled, -) only right call button enabled, -) both enabled. Camera LEDs Enabling of the camera LEDs. Default value: selected. Welcome Message It allows you to enter a text message that will be displayed on the display module 1168/1 in case of configuration as...
Page 583 RTSP In-Call stream settings RTSP In-Call stream If selected, the Switchboard application can display the RTSP video stream of the calling station during the call to an apartment station or during the auto-on from an apartment station. Fields marked with the hash mark (#) must be filled correctly.
Page 584 The "Call Buttons" section allows associating the apartment stations (or the Switchboards) to be called to the keys of the Outdoor Station by pressing on the icon “Edit”. The relevant window will open allowing you • set recipient’s name and surname (field “Name”), which will appear on the outdoor station name tag at the corresponding call key;...
Page 585 Entry Panel 1060/71-74-75-/78 Figure 721: Entry Panel 1060/71-74-75-78 settings (part 1) Figure 722: Entry Panel 1060/71-74-75-78 settings (part 2) MT124-032N...
Page 586 Figure 723: Entry Panel 1060/71-74-75-78 settings (part 3) Figure 724: Entry Panel 1060/71-74-75-78 settings (part 4) Figure 725: Entry Panel 1060/71-74-75-78 settings (part 5) MT124-032N...
Page 587 The following table shows the meaning of the fields for Entry Panel 1060/71-74-75-/78. General settings Name Name to assign to the Entry Panel. MAC Address MAC address associated with the Entry Panel. IP Address IP address associated with the Entry Panel. Field visible only if manual network configuration is set in system parameters.
Page 588 Main door settings Used In this case, the item Yes enables the main door: the following options are shown, marked with a hash mark (#). The item No disables the main door. Default value: Yes. Door Profile (#) This allows you to associate a previously created door profile with the concerned main door.
Page 589 Hall Button Settings Remote Button (#) It allows you to remotely control the entrance hall button that opens the main door of the Call Module. For further details, see paragraph Remote relay functions, remote entrance hall button and remote sensor. Table 45: hall button settings Gate settings Used...
Page 590 End user settings Loudspeakers Volume Loudspeaker volume setting. Button feedback tone Audio feedback volume at button pressure. Call feedback tone Feedback volume of forwarded call. Camera LEDs Enabling of the camera LEDs. Model 1060/71 This box must be ticked if you use a calling station with one button.
Page 591 The "Call Buttons" section allows associating the indoor stations (or the Switchboards) to be called to the keys of the Outdoor Station by pressing on the icon “Edit”. The relevant window will open allowing you to: • set recipient’s name and surname (fields “Line 1” and “Line 2”), which will appear on the outdoor station name tag at the corresponding call key;...
Page 592 Entry panel 1060/33 Figure 726: Entry Panel 1060/33 settings (part 1) Figure 727: Entry Panel 1060/33 settings (part 2) MT124-032N...
Page 593 Figure 728: Entry Panel 1060/33 settings (part 3) Figure 729: Entry Panel 1060/33 settings (part 4) MT124-032N...
Page 594 The following table shows the meaning of the fields for Entry panel 1060/33. General settings Name Name to assign to the Entry Panel. MAC Address MAC address associated with the Entry Panel. IP Address IP address associated with the Entry Panel. Field visible only if a manual network configuration has been set in the system parameters.
Page 595 Main door settings Used In this case, the item Yes enables the main door: the following options are shown, marked with a hash mark (#). The item No disables the main door. Default value: Yes. Door Profile (#) It allows you to associate a previously created access profile to the main door in question.
Page 596 Hall Button Settings Remote Button (#) It allows you to remotely control the entrance hall button that opens the main door of the Call Module. For further details, see paragraph Remote relay functions, remote entrance hall button and remote sensor. Table 51: Hall button settings Gate settings Used...
Page 597 End user settings Call Feedback This allows you to set call feedback via vocal message/sound feedback or to set no call feedback mode (default). Loudspeaker Volume Loudspeaker volume setting Camera LEDs Enabling of the camera LEDs. Default value: selected. Table 53: End user settings RTSP In-Call stream settings RTSP In-Call stream If selected, the Switchboard application can display the RTSP...
Page 598 The “Add” button in the “Activations” section has already been described in paragraph Activations. The "Call Keys" section allows associating the indoor stations (or the Switchboards) to be called to the 4 keys of the Outdoor Station by pressing on the icon “Modification”. The relevant window will open allowing you to: •...
Page 599 Entry panel 1060/34 Figure 730: Entry Panel 1060/34 settings (part 1) Figure 731: entry panel 1060/34 settings (part 2) MT124-032N...
Page 600 Figure 732: Entry Panel 1060/34 settings (part 3) The following table shows the meaning of the fields for Entry Panel 1060/34. General settings Name Name to assign to the Entry Panel. MAC Address MAC address associated with the Entry Panel. IP Address IP address associated with the Entry Panel.
Page 601 Main door settings Used In this case, the item Yes enables the main door: the following options are shown, marked with a hash mark (#). The item No disables the main door. Default value: Yes. Door Profile (#) It allows you to associate a previously created access profile to the main door in question.
Page 602 Hall Button Settings Remote Button (#) It allows you to remotely control the entrance hall button that opens the main door of the Call Module. For further details, see paragraph Remote relay functions, remote entrance hall button and remote sensor. Table 57: Hall button settings Gate settings Used...
Page 603 End user settings Call Feedback This allows you to set call feedback via vocal message/sound feedback or to set no call feedback mode (default). Loudspeaker Volume Loudspeaker volume setting. Camera LEDs Enabling of the camera LEDs. Default value: selected. Table 59: End user settings RTSP In-Call stream settings RTSP In-Call stream If selected, the Switchboard application can display the RTSP...
Page 604 The "Add" button in the "Activations" section has already been described in the paragraph “Activations”. The address book of the Entry Panel is automatically created by importing the residents (set as visible) of all the apartments of the topological group of the Entry Panel itself. MT124-032N...
Page 605 Entry Panel 1060/21 Figure 733: Entry Panel 1060/21 settings (part 1) Figure 734: Entry Panel 1060/21 settings (part 2) MT124-032N...
Page 606 Figure 735: entry panel 1060/21 settings (part 3) Figure 736: Entry Panel 1060/21 settings (part 3) The following table shows the meaning of the fields for the Entry Panel 1060/21. General settings Name Name to assign to the Entry Panel. MAC address MAC address associated with the Entry Panel.
Page 607 Main door settings Used The item “Yes” enables the main door: in this case the following options are shown, marked with a hash mark (#). The item “No” disables the main door. Default value: “Yes”. Door Profile (#) This allows you to associate a previously created door profile with the concerned main door.
Page 608 Hall Button Settings Remote Button (#) It allows you to remotely control the entrance hall button that opens the main door of the Entry Panel. For further details, see paragraph Remote relay functions, remote entrance hall button and remote sensor. Table 63: Hall button settings Gate settings Used...
Page 609 RTSP In-Call stream settings RTSP In-Call stream If selected, the Switchboard application can display the RTSP video stream of the calling station during the call to an apartment station or during the auto-on from an apartment station. Fields marked with the hash mark (#) must be filled correctly.
Page 610 Private Call Module 1060/22 Figure 737: Private Call Module 1060/22 settings (part 1) Figure 738: Private Call Module 1060/22 settings (part 2) MT124-032N...
Page 611 The following table shows the meaning of the fields for the Private Call Module 1060/22. General Settings Name Name to assign to the Entry Panel. MAC address MAC address associated with the Entry Panel. IP address IP address associated with the Entry Panel. Field visible only if manual network configuration is set in system parameters.
Page 612 In the RTSP streaming settings to set the IP address it is recommended to follow what is reported in APPENDIX F1: How to use customized network settings in IperCom system. It is possible to configure any Urmet NVR device to record calls made via Entry Panel 1060/22 and related auto-on activated by video door phone.
Page 613 Switchboard 1060/41 Figure 739: Switchboard settings The following table shows the meaning of the fields for Switchboard 1060/41. General Settings Name Name to assign to the Switchboard. MAC Address MAC address associated with the PC on which the Switchboard programme is installed. IP Address IP address associated to the PC on which the Switchboard programme is installed.
Page 614 If there are two or more Switchboard applications on the same node, the following screen page will appear: Figure 740: Switchboard settings for CallMe priority feature The buttons in the "CallMe Priority" section allow you to move the Switchboard applications located on the relevant node up or down (in this case block 01).
Page 615 Video door phone 7” VOG 1761/31-32-33 Figure 741: Video door phone 7” VOG 1761/31-32-33 settings The following table shows the meaning of the various fields. General Settings Name Name to assign to the video door phone. MAC Address MAC address associated with the video door phone. IP Address IP address associated with the video door phone.
Page 616 Video door phone 5'' VOG 1761/15-16-17-18 Figure 742: Video door phone 5'' VOG 1761/15-16-17-18 settings The following table shows the meaning of the various fields. General settings Name Name to assign to the video door phone. MAC Address MAC address associated with the video door phone. IP Address IP address associated with the video door phone.
Page 617 Video door phone 5'' VOG 1761/6 Figure 743: Video door phone 5'' VOG 1761/6 settings (part 1) Figure 744: Video door phone 5'' VOG 1761/6 settings (part 2) MT124-032N...
Page 618 The following table shows the meaning of the various fields. General Settings Name Name to assign to the video door phone. MAC Address MAC address associated with the video door phone IP Address IP address associated with the video door phone. Field visible only if a manual network configuration has been set in the system parameters.
Page 619 Video door phone 7’’ MAX 1717/31-32-33-34-41 Figure 745: Video door phone 7’’ MAX 1717/31-32-33-34-41 settings The following table shows the meaning of the various fields. General Settings Name Name to assign to the video door phone. MAC Address MAC address associated with the video door phone. IP Address IP address associated with the video door phone.
Page 620 Video door phone 10'' MAX 1717/21-22-23 Figure 746: Video door phone 10'' MAX 1717/21-22-23 settings The following table shows the meaning of the various fields. General Settings Name Name to assign to the video door phone. MAC Address MAC address associated with the video door phone. IP Address IP address associated with the video door phone.
Page 621 Video door phone 7'' Basic 1741/1-2-3 Figure 747: Video door phone 7'' Basic 1741/1-2-3 settings The following table shows the meaning of the various fields. General Settings Name Name to assign to the video door phone. MAC Address MAC address associated with the video door phone. IP Address IP address associated with the video door phone.
Page 622 IPerCom Client 1060/43 Figure 748: IPerCom Client 1060/43 settings The following table shows the meaning of the various fields. General Settings Name Name to assign to the video door phone. MAC Address MAC address associated with the video door phone. IP Address IP address associated with the video door phone.
Page 623 Miro door phone 1160/3 Figure 749: Miro door phone 1160/3 settings (part 1) Figure 750: Miro door phone 1160/3 settings (part 2) MT124-032N...
Page 624 The following table shows the meaning of the various fields. General Settings Name Name to assign to the door phone. MAC address MAC address associated with the Door Phone. IP address IP address associated with the Door Phone. Field visible only if manual network configuration is set in system parameters.
Page 625 Key Reader 1060/45 or 1060/86 Figure 752: Key Reader settings (part 1) Figure 753: Key Reader settings (part 2) MT124-032M...
Page 626 The following table shows the meaning of the fields for Key Reader 1060/45 e 1060/86. General Settings Name Name to assign to the Key Reader. MAC Address MAC address associated with the Key Reader. IP Address IP address associated with the Key Reader. Field visible only if manual network configuration is set in system parameters.
Page 627 The “Add” button in the "Activations” section has already been described in paragraph Activations. For the Key Reader 1060/86 with firmware version 1.40 it is recommended to remotely control the door open sensor through the input of a Relay Actuator with firmware version 4.05 (remote sensor function).
Page 628 Relay actuator 1060/84 v. 2.07 / 3.04 / v. 4.05 Figure 754: Relay actuator 1060/84 (part 1) Figure 755: Relay actuator 1060/84 (part 2) MT124-032N...
Page 629 Figure 756: Relay actuator 1060/84 (part 3) The following table shows the meaning of the fields for the Relay Actuator 1060/84 and the version for which the field is present. GENERAL SETTINGS v. 3.04/v. 2.07/v. 4.05 Name Name to assign to the Relay Actuator. If no name is assigned, the field is forced with the MAC address.
Page 630 Output 1 and 2 v. 3.04/v. 2.07/v. 4.05 Name Name to assign to the output. If no name is assigned, the field is forced by the last 3 pairs of alphanumeric characters of the MAC address followed by " - Output 1 (2)". Mode Output relay operating mode: monostable or bistable.
Page 631 The IPerTAlk Server V1 item appears only if the network addressing chosen for the IPerCom system is static and refers to the integration of the IPerCom 3.1.0 system with the IPerTAlk 2.2.10 system or higher (which mandatorily requires static addressing for the IPerCom system). On the contrary, the IPerTAlk Server item appears with both dynamic and static network addressing and refers to the first integration of the IPerCom 2.2.0 system with the IPerTAlk 2.1.4 system or higher (up to and...
Page 632 IPassan controller Figure 758: IPassan controller settings The following table shows the meaning of the fields for the IPassan Controller. General Settings Name Name to assign to the IPassan Controller. MAC Address MAC address associated with the IPassan Controller. Value not editable.
Page 633 IPerCom-2Voice Gateway 1083/59 Figure 759: IPerCom-2Voice Gateway 1083/59 settings The following table shows the meaning of the fields for the IPerCom-2Voice Gateway 1083/59. General Settings Name Name to assign to the IPerCom-2Voice Gateway. MAC address MAC address associated with the IPerCom-2Voice Gateway. IP address IP address of the IPerCom-2Voice Gateway.
Page 634 IperCom Clock Module 1060/85 Figure 760: IperCom Clock Module 1060/85 settings The following table shows the meaning of the fields for "IperCom Clock Module 1060/85”. General Settings Name Name to assign to the IperCom Clock Module. MAC Address MAC address associated with the IperCom Clock Module. IP Address IP address associated to the PC on which the IperCom Clock Module programme is installed.
Page 635 Lift interface 1060/37 Figure 761: Lift interface 1060/37 settings (part 1) Figure 762: Lift interface 1060/37 settings (part 2) MT124-032M...
Page 636 The following table shows the meaning of the fields for Lift Interface 1060/37. General settings Name Name to assign to the Lift Interface. MAC Address MAC address associated with the Lift Interface. IP Address IP address of the Lift Interface. Field visible only if a manual network configuration has been set in the system parameters.
Page 637 RTSP Camera Figure 763: RTSP Camera settings (part 1) Figure 764: RTSP Camera settings (part 2) MT124-032M...
Page 638 The following table shows the meaning of the fields for RTSP Camera. General Settings Name Name to assign to the RTSP Camera. MAC Address MAC address associated with the RTSP Camera. Device Code Value cannot be changed. Location Position in the system topology: it is possible to move the device to another topological node by pressing the "Move”...
Page 639 RTSP Camera (NVR) Figure 765: RTSP Camera (NVR) settings (part 1) Figure 766: RTSP Camera (NVR) settings (part 2) MT124-032M...
Page 640 The following table shows the meaning of the fields for RTSP Camera (NVR). General Settings Name Meaningful name to be assigned to the RTSP Camera connected to the Urmet NVR device Identifier Unique identifier of the NVR device (serial number or other) Device Code Non-editable value Location...
Page 641 APPENDIX B: Differences of functions between 2Voice and IPerCom apartment station Below is a table with the performances supported and not supported by the IPerCom and 2Voice apartment station. Please note that adding a riser of 2Voice apartment station to an IPerCom system is only possible through the IPerCom-2Voice 1083/59 Gateway.
Page 642 APPENDIX C: Differences of functions between 2Voice and IPerCom devices with IPerCom Switchboard The following table shows the differences in functions between the 2Voice and IPerCom devices with an IPerCom Switchboard. Function 2Voice device IPerCom device 2Voice secondary stations IPerCom stations Auto-on from Switchboard (connected to the Gateway): NO (any): YES...
Page 643 APPENDIX D: IPerCom priority calls Calls within an IPerCom system are shown in ascending order of priority: • auto-on; • intercom (call between two apartments); • call from Call Module/Entry Panel/Switchboard to apartment or from apartment to Switchboard; • emergency call. Each call has two basic parameters (which can be set from the "System"...
Page 644 APPENDIX E: Type of proximity keys that can be read by IPerCom devices with access control function The following table shows, for each IPerCom device which integrates a proximity key reader, the types of keys compatible with the reader: 125KHz MIFARE 125KHz/MIFARE MIFARE PLUS Call Module...
Page 645 APPENDIX F1: How to use customized network settings in IperCom system The “Custom Network Settings” section is present in the “System” tab, as shown below: Figure 767: “System” tab - “Custom Network Settings” In this section it is possible to define a range of IP addresses (between the “IP Range Minimum” and “IP Range Maximum”...
Page 646 CASE 1: IP , RTSP C OM SYSTEM WITH DYNAMIC ADDRESSING AMERAS AND OM DEVICES IN THE SAME SUBNET To implement this case, we recommend following the diagram displayed below, where the IP addresses shown are purely by way of example: Figure 768: connection diagram for RTSP cameras and IPerCom devices To create the diagram in Figure...
Page 647 1. Dynamic addressing of IPerCom devices In the “System” tab in the “Network Settings” section, choose the “Dynamic” item regarding the way in which IPerCom devices receive IP addresses: Figure 769: dynamic network settings for IPerCom devices 2. Static addressing of RTSP Cameras For RTSP Cameras, choose a 192.168.35.x/24 subnet in the “Custom Network Settings”...
Page 648 3. Adding an RTSP Camera If you add an RTSP Camera to the system, the following screen appears: Figure 771: adding an RTSP camera to the IPerCom system The “IP Address” field automatically reports the first available IP address among those present in the range of IP addresses defined in Figure 770.
Page 649 CASE 2: IP , RTSP OM SYSTEM WITH STATIC ADDRESSING CAMERAS AND OM DEVICES IN THE SAME SUBNET This case is like the previous one with the only difference that the IP addresses of the IPerCom devices are not assigned by the DHCP server of a router but by the configurator. To implement this case, we recommend following the diagram displayed below, where the IP addresses shown are purely by way of example: Figure 772: connection diagram for RTSP cameras and IPerCom devices...
Page 650 As regards the IPerCom configurator, follow the points below. 1. Static addressing of IPerCom devices In the “System” tab in the “Network Settings” section, choose the “Static” item regarding the way in which IPerCom devices receive IP addresses: Figure 773: static network settings for IPerCom devices 2.
Page 651 3. Adding an RTSP Camera If you add an RTSP Camera to the system, the following screen appears: Figure 775: adding an RTSP camera to the IPerCom system The “IP Address” field automatically reports the first available IP address among those present in the range of IP addresses defined in Figure 774.
Page 652 CASE 3: RTSP C AMERAS AND OM DEVICES ON TWO DIFFERENT SUBNETS To implement this case, we recommend following the diagram displayed below, where the IP addresses shown are purely by way of example: Figure 776: connection diagram for RTSP cameras and IPerCom devices To create the diagram in Figure 776, follow the instructions below.
Page 653 In this way the IperCom devices connected to ROUTER 1 via LAN have IP addresses of the 192.168.35.x/24 type while the WAN port of ROUTER 1 has an IP address of 10.10.10.2. ROUTER 2 has an IP address 10.10.10.1 with a 24-bit network mask: the RTSP Cameras connected to the LAN ports of ROUTER 2 will have IP addresses from 10.10.10.3 to 10.10.10.20 (set statically).
Page 654 3. Adding an RTSP Camera If you add an RTSP Camera to the system, the following screen appears: Figure 779: adding an RTSP camera to the IPerCom system The “IP Address” field automatically reports the first available IP address among those present in the range of IP addresses defined in Figure 778.
Page 655 If you enable RTSP streaming of a calling station, the following screen appears: Figure 780: enabled RTSP streaming of a calling station As written above, the “IP address” field automatically reports the first available IP address: this can be modified with another value which in this case, however, must be included in the range set in Figure 778 (and must not already be been used).
Page 656 APPENDIX F2: Custom network settings and editable static IP addresses for IPerCom devices If you choose the “Static” item in the “Network Settings” section of “System” tab of configurator, it is necessary, as already mentioned, to define a range of IP addresses, a network mask, DNS, and gateway as shown below: Figure 781: static network settings for IPerCom devices MT124-032N...
Page 657 If you add an IPerCom device, a screen like this appears: Figure 782: adding an IPerCom device The “IP Address” field automatically reports the first available IP address proposed in the range of IP addresses defined in Figure 781. This IP address can be modified if you select the “Custom” item: Figure 783: editable IP address MT124-032M...
Page 658 The “IP Address” field shows the first available value among those present in the IP address range set in the “Custom Network Settings” section: Figure 784: custom IP address range To be able to modify the “IP address” field of Figure 783 it is necessary to choose a value included in the IP address range of...
Page 659 APPENDIX G: Changing the network settings of IPerCom Installer Tools. If it is necessary to change the network settings of the system after its commissioning, this is possible in the configurator through the System tab in the Network Settings section, which allows you to switch from an automatic setting (for example if there is a router in the system) to a manual setting or vice versa.
Page 660 Then it is necessary to press the OK button: the modifications to the site are automatically saved and IPerCom Installer Tools restarts, showing the following screen: Figure 787: iPerCom Installer Tools screen after restart Now it is necessary to open the project associated with the system and connect to it. When you press the "Connect"...
Page 661 If you press the Continue key during this step (without changing the network parameters), the IPerCom Installer Tools application is closed. To change the IP address and MAC address of the network interface through which you are connected to the IPerCom system, it is necessary to press the Open Network Connections and Sharing Centre button on your PC (icon at the bottom right of the screen), then identify the name of the network connected to IPerCom system.
Page 662 APPENDIX H: Date and time incorrectly set in the future. As described in the previous paragraphs, during the commissioning of an IPerCom system it is necessary to correctly set the date and time. This can be done through MAX video door phone or IPerCom Clock Module or by simply connecting the system to the Internet via a router.
Page 663 APPENDIX I: Modular entry panel with 1060/48 Alpha Modular entry panel with a robust, essential, and advanced design that offers easy access to a full range of functions. The system, with modular elements, consists of modules (with or without white or black or gray plastic front units) that can be inserted on special wall frames.
Page 664 Performance • Audio/video IP outdoor station module Ref. 1060/4. • Possibility to supply a maximum of 12 modules in total: - Only one IP audio video external unit with its front unit (black or white or gray) with 0.1 or 2 keys; - ILA module with optional black, white, or grey speech synthesis.
Page 665 Audio video external unit IP Ref. 1060/48 Structure FRONT VIEW REAR VIEW 1. DDA LED 2. “USER 0” calling button 3. Speaker 4. Name tag and button light LED 5. Camera 6. Camera lighting LED 7. “USER 1” calling button 8.
Page 666 11. Connector for hearing aid coil (ILA) Ref. 1168/48 12. USB connector for connecting to display module 1168/1 13. Module connection wire connector (OUT) 14. Label with MAC ADDRESS of the device 15. Trimmer for adjusting speaker volume (RV1) 16. Jumper provided to connect the door state sensor 17.
Page 667 DDA (Disability Discrimination Act) led actuation - system status indication • The system state is shown by the following indications which appear on the door unit front: • call in progress: LED on green and voice message “CALL IN PROGRESS”. •...
Page 668 ILA and voice synthesis module ref. 1168/48 The ILA and voice synthesis module is a modular device designed to allow hearing aid users to hear the door unit audio and be notified of system state by means of auditory indications. To interface with the calling unit, the user must approach the hearing aid (with T function) to the front part of the device, no further than 20 cm, near the name tag IP Audio video...
Page 669 Structure REAR VIEW 1. Module connection wire connector (IN) 2. Module connection wire connector (OUT) 3. Audio wire connector (ILA) 4. Potentiometer for adjusting the speech synthesis volume 5. Rotary selector for selecting speech synthesis MT124-032M...
Page 670 Installation The ILA module must be positioned immediately near the door unit. The modules must be connected by means of the three-wire audio cord provided. 8 cm long cord provided with button module and expansion unit Ref. 1168/4 of the ILA and voice synthesis module Ref.
Page 671 Speech synthesis language selection The language is selected by means of the rotary selector (5) in the rear part of the module as shown in the following table. Rotary selector position Associated language Italian (default) English Franch German Spanish Dutch 0 –...
Page 672 Proximity key reader module Ref. 1168/45 The device Ref. 1168/45 is the proximity key reader. It has following operating modes: Audio-video door IP unit Ref. 1060/48 Only one module 1168/45 can be installed for each call station. Structure 1. Proximity key sensor 2.
Page 673 indicating LED state: ON enable (default) OFF disable 2. Do not change the arrangement of this dip switch 3. RS485 BUS: Ipercom mode 6. Terminal board 7. Jumper for power from Ipercom system The device must be positioned as the last module on the panel. Respect the installation constraint of maximum 12 modules of which only one is a 1168/45 module.
Page 674 8 cm long cord provided with modules Ref. 1168/xx. Performance Permits timed opening (from 0 to 99 seconds) when a user proximity key is placed close to the frontn panel. The two-color LED, if enabled, displays the recognition of a proximity key approached to the front by changing color (from red to green).
Page 675 Ref.1168/50W: Opaline white name tag supplied with the module; the name tag can be written by means of decals. Ref. 1168/50G: grey name tag supplied with the module; name tags are engraved. Installation MT124-032M...
Page 676 8 cm long cord provided with button module and expansion unit Ref. 1168/4 or 1168/8 of the building number module Ref. 1168/50 B 38 cm long cord provided with building number module Ref. 1168/50. The name tag can only be fitted or replaced after the front unit of the module has been removed. Blind module Ref.
Page 677 4-Button module Ref. 1168/4 and 8-Button module Ref. 1168/8 4-BUTTON MODULE 8-BUTTON MODULE The 4-button or 8-button modules can be used to expand the number of users on the panel. Up to 88 buttons can be connected (in addition to the two already present on the door unit), using up to 11 button modules Ref.
Page 678 Joining flush-mounting boxes Flush mounting boxes can be assembled with suitable spacers, also used as wire hole. Up to 3 4-module flush-mounting boxes can be assembled (12 modules in total). If wall cover frames are used, instead, up to 3 3-module boxes (9 modules in total) can be assembly, joining them on the longer side. All spacers are empty, to allow the passage of wires from a box to another one.
Page 679 Module holder frames The module holder frames allow quick and easy ALPHA module assembly (either single or double). A hinge is provided in the lower part of the frame to tip the modules and facilitate wiring and adjustment. Available versions are: •...
Page 680 Wall cover frame These frames are used to conceal irregularities of the wall in the flush mounting area surrounding the panel; insert the cover frames between modules and wall. The following anodised aluminium frames are provided: • 1-row frame for 1 module Sch.
Page 681 • 3-row frame for 9 modules Sch. 1168/639 H is 328 mm for 3 module versions. Wall frame cover installation Embed the flush mounting box in the wall, position the wall cover frame and fasten the module holder lower screw. Frame fastening is completed by tightening the upper frame screw last. MT124-032M...
Page 682 Wall-mounted panel accessories Casings with frame The casings can be used for wall-mounted installations without embedding. The following versions are provided with module holder frame: • For 1 module Sch. 1168/311 • For 2 modules Sch. 1168/312 • For 3 modules Sch.
Page 683 Casing and frame joiner The casings with frames may be joined by means of shims which double as spacers. Up to 3 4-module flush- mounting boxes can be assembled (12 modules in total). All shims are hollow to allow the passage of wires from one box to the other. Panel accessory in common to both versions Rain hood cover They are useful to make the panel installation weatherproof.
Page 684 Alpha entry panel with 1060/48 installation It is suggested to install the modules at the height shown below, according to the system to be realized. However, for complex systems with several modules, for a correct installation consider the height shown in the figure to fix the camera.
Page 685 Flush-mounted version • Prepare the flush-mounting hole for the passages of the connecting wires. • Install the flush mounting box: it must not jut out of the wall. MT124-032M...
Page 686 • Remove the upper header and the lower header from the frame using a flat screwdriver at the tip 0. MT124-032N...
Page 687 • Fit the module holder frame • Tip the holder frame and connect the wires. MT124-032M...
Page 688 • Adjust correct perpendicularity of the panel. • Establish the connections between the various modules with the wires provided before powering the system. • Use the cord provided with the frame to connect modules belonging to frames arranged side by side. •...
Page 689 • On the rear of the external unit there is the RESET key which must be pressed to restart or reset the device to factory settings. • Close the frame by tightening the screws. • Insert the name tags in the front panels Clip the front panels onto the frame. When hooking the front unit to the wall frame, make sure to keep the buttons on the right side of the entry panel.
Page 690 • Attach upper header and lower the frame. MT124-032N...
Page 691 Wall-mounted version • Remove the upper header and the lower header from the frame using a flat screwdriver at the tip 0. • Remove the module holder frame from the casing. MT124-032M...
Page 692 • Secure the casing with screws to the wall. • Fit the module holder frame. MT124-032N...
Page 693 • Fit the modules in the frame. • Tip the frame and connect the wires. MT124-032M...
Page 694 • Adjust correct perpendicularity of the panel. • Establish the connections between the various modules with the wires provided before powering the system. • Use the cord provided with the frame to connect modules belonging to frames arranged side by side •...
Page 695 RESET • On the rear of the external unit there is the RESET key which must be pressed to restart or reset the device to factory settings. • Attach upper header and lower the frame. MT124-032M...
Page 696 • Insert the name tags in the front panels Clip the front panels onto the frame. When hooking the front unit to the wall frame, make sure to keep the buttons on the right side of the entry panel. • Attach upper header and lower the frame.
Page 697 MT124-032M...
Page 698 Complementary products list DOOR UNIT Audio video IP door unit Ref. 1060/48 MODULES 4-Button module Ref. 1168/4 8-Button module Ref. 1168/8 ILA and voice synthesis module (*) Ref. 1168/48-48W-48G Building number module (*) Ref. 1168/50-50W-50G Name directory module (*) Ref. 1168/51-51W-51G Blind module Ref.
Page 699 MODULE HOLDER FRAMES Frame for 1 module Ref. 1168/61 Frame for 2 modules Ref. 1168/62 Frame for 3 modules Ref. 1168/63 Frame for 4 modules Ref. 1168/64 WALL COVER FRAME 1-row frame for 1 module Ref. 1168/611 1-row frame for 2 modules Ref.
Page 700 Overall dimensions Flush-mounted version Dimensions H1= 114, 204, 294, 384 refers to the flush-mounting height and H2= 126, 217, 306, 396 refers to the total height, for the 1, 2, 3, 4 module versions, respectively. MT124-032N...
Page 701 all-mounted version The H3 dimensions related to the total height can have different values depending on the number of modules that the housing can accommodate. MT124-032M...
Page 702 Modularity examples for different system dimensions (single push button black color) BUTTONS NUMBER Video door phones A/V door IP unit 1060/48 module 1168/140 Front frame for 1168/141 A/V IP door unit 1168/142 4-Button module 1168/4 1168/11 Common products 1168/12 Front frame for push button panel 1168/13 1168/14...
Page 703 BUTTONS NUMBER Video door phones A/V door IP unit 1060/48 module 1168/140 Front frame for 1168/141 A/V IP door unit 1168/142 4-Button module 1168/4 1168/11 Common products 1168/12 Front frame for push button panel 1168/13 1168/14 Building number 1168/50 module Blind module 1168/59 Rain hood cover...
Page 704 BUTTONS NUMBER Video door phones A/V door IP unit 1060/48 module 1168/140 Front frame for 1168/141 A/V IP door unit 1168/142 4-Button module 1168/4 1168/11 Common products 1168/12 Front frame for push button panel 1168/13 1168/14 Building number 1168/50 module Blind module 1168/59 Rain hood cover...
Page 705 MT124-032M...
Page 706 MT124-032N...
Page 707 Modularity examples for different system dimensions (double push button black color) BUTTONS NUMBER Video door phones A/V door IP unit 1060/48 module 1168/140 Front frame for 1168/141 A/V IP door unit 1168/142 4-Button module 1168/8 Common products 1168/24 Front frame for push button panel 1168/28 Building number...
Page 708 BUTTONS NUMBER Video door phones A/V door IP unit 1060/48 module 1168/140 Front frame for 1168/141 A/V IP door unit 1168/142 4-Button module 1168/8 Common products 1168/24 Front frame for push button panel 1168/28 Building number 1168/50 module Blind module 1168/59 Rain hood cover 1168/401...
Page 709 BUTTONS NUMBER Video door phones A/V door IP unit 1060/48 module 1168/140 Front frame for 1168/141 A/V IP door unit 1168/142 4-Button module 1168/8 Common products 1168/24 Front frame for push button panel 1168/28 Building number 1168/50 module Blind module 1168/59 Rain hood cover 1168/401...
Page 710 BUTTONS NUMBER Video door phones A/V door IP unit 1060/48 module 1168/140 Front frame for 1168/141 A/V IP door unit 1168/142 4-Button module 1168/8 Common products 1168/24 Front frame for push button panel 1168/28 Building number 1168/50 module Blind module 1168/59 Rain hood cover 1168/401...
Page 711 BUTTONS NUMBER Video door phones A/V door IP unit 1060/48 module 1168/140 Front frame for 1168/141 A/V IP door unit 1168/142 4-Button module 1168/8 Common products 1168/24 Front frame for push button panel 1168/28 Building number 1168/50 module Blind module 1168/59 Rain hood cover 1168/401...
Page 712 BUTTONS NUMBER Video door phones A/V door IP unit 1060/48 module 1168/140 Front frame for 1168/141 A/V IP door unit 1168/142 4-Button module 1168/8 Common products 1168/24 Front frame for push button panel 1168/28 Building number 1168/50 module Blind module 1168/59 Rain hood cover 1168/401...
Page 713 MT124-032M...
Page 714 MT124-032N...
Page 715 APPENDIX L: Alpha call module 1168 The ALPHA call module with sturdy, streamline and modern design is for use in 2Voice systems. It offers simple access to a full range of functions. The system consists of black or grey modules which can be inserted on specific frames.
Page 716 EXTENDED CONFIGURATION Apart from the IP 1060/48 audio video outdoor station, all the other modules listed above can be black or grey. The IP 1060/48 audio video outdoor station must be fitted with a black or grey faceplate (with 0, 1 or 2 keys) depending on the colour chosen.
Page 717 Features Possibility of powering up to 12 modules in total: CONFIGURATIONS Maximum number of modules Modules Description 1060/48 IP Door unit modules 1168/1 Display module 1168/46 Numeric keypad module 1168/45 Proximity key reader module 1168/48 ILA and voice synthesis module 1168/49 Alphaphetic keypad module Door number module or 4-buttons...
Page 718 PROXIMITY KEY READER MODULE 1168/45 • The door can be opened using a transponder key if the proximity key reader module is present. Below is the description of the modules that make up the ALPHA call module. For the description of the following modules see APPENDIX M1: - Audio/video external unit module IP Ref.
Page 719 Structure FRONT VIEW REAR VIEW 1. 4 context soft touch keys on backlighting 2. 3.5-inch LCD display 3. Connector for module connection cable (IN) 4. Connector for module connection cable (OUT) 5. Label with MAC ADDRESS of the device 6. Cables preset for connection to the external presence sensor (optional) 7.
Page 720 Structure 8. Proximity key sensor 9. Two colour LED (red/green) 10. Module connection cable connector (IN) 11. Module connection cable connector (OUT) 12. Configuration dip switches used for: 1. indicating LED state: ON enable (default) 2. Do not change the arrangement of this dip switch 3.
Page 721 Installation 8-cm long cord provided with the following modules: display Ref. 1168/1, keypads Ref. 1168/46 and /49, proximity key reader Ref. 1168/45 and door number Ref. 1168/50. 82-cm cord provided with ILA and voice synthesis module Ref. 1168/48. 58-cm long cord provided with three or four-module frame Ref. 1168/63 or and of one-row casings with three or four-module frame (Ref.
Page 722 Numeric keypad module Ref. 1168/46 The numeric keypad module Ref. 1168/46 allows you to make a call using a numerical, logical, topological code or enter a door opener code to open an access point. FRONT VIEW REAR VIEW 1. 12 soft-touch shortcut keys with backlighting 2.
Page 723 Alphabetic keypad module Ref. 1168/49 The alphabetic keypad module Ref. 1168/46 is a keypad dedicated to IperCom call modules. FRONT VIEW REAR VIEW 1. 12 soft-touch shortcut keys with backlighting 2. Module connection wire connector (IN) 3. Module connection wire connector (OUT) MT124-032M...
Page 724 Connecting the call module The connection of a call module with standard and extended configuration is shown below. STANDARD CONFIGURATION EXTENDED CONFIGURATION 8-cm long cord provided with the following modules: display Ref. 1168/1, keypads Ref. 1168/46 and /49, proximity key reader Ref. 1168/45 and door number Ref. 1168/50. 82-cm cord provided with ILA and voice synthesis module Ref.
Page 725 Complementary products list DOOR UNIT Audio video IP door unit Ref. 1060/48 MODULES Display module Ref. 1168/1-1G 4-Button module Ref. 1168/4 8-Button module Ref. 1168/8 Numeric keypad module Ref. 1168/46-46G Alphabetic keypad module Ref. 1168/49-49G Proximity key reader module Ref. 1168/45-45G ILA and voice synthesis module Ref.
Page 726 MODULE HOLDER FRAMES Frame for 1 module Ref. 1168/61 Frame for 2 modules Ref. 1168/62 Frame for 3 modules Ref. 1168/63 Frame for 4 modules Ref. 1168/64 WALL COVER FRAME 1-row frame for 1 module Ref. 1168/611 1-row frame for 2 modules Ref.
Page 727 Modularity examples Ref. Description N° Note 1060/48 Audio video IP door unit 1168/141 (§) 1 PB front frame for audio video IP door unit 1168/1 Display module 1168/46 Numeric keypad module 1145/53 Flush-mounting boxes 1168/63 Module holder frames Flush-mounted 1168/613 Wall cover frame (*) Wall-mounted 1168/313...
Page 728 Ref. Description N° Note 1060/48 Audio video IP door unit 1168/141 (§) 1 PB front frame for audio video IP door unit in alternative: 1168/50 1168/49 1168/48 ILA and voice synthesis module 1168/45 1168/8 1168/4 1168/1 Display module 1168/46 ILA and voice synthesis module 1145/52 Flush-mounting boxes 1168/62...
Page 729 Ref. Description N° Note 1060/48 Audio video IP door unit 1168/141 (§) 1 PB front frame for audio video IP door unit 1168/1 Modulo display 1168/46 Display module in alternative: 1168/50 1168/49 1168/45 Proximity key reader module 1168/48 1168/8 1168/4 1145/54 Flush-mounting boxes 1168/64...
Page 730 (§) in alternative: 1168/140 or 1168/142 Ref. Description N° Note 1060/48 Audio video IP door unit 1168/141 (§) 1 PB front frame for audio video IP door unit 1168/48 ILA and voice synthesis module 1168/45 Proximity key reader module 1168/1 Display module 1168/46 Numeric keypad module...
Page 731 Ref. Description N° Note 1060/48 Audio video IP door unit 1168/141 (§) 1 PB front frame for audio video IP door unit 1168/1 Display module in alternative: 1168/59 Blind module 1168/4 / 1168/8 1168/45 Proximity key reader module 1168/50 Building number module 1168/48 ILA and voice synthesis module 1168/46...
Page 732 (§) in alternative: 1168/140 or 1168/142 Ref. Description N° Note 1060/48 Audio video IP door unit 1168/141 (§) 1 PB front frame for audio video IP door unit 1168/1 Display module 1168/45 Proximity key reader module 1168/48 ILA and voice synthesis module 1168/46 Numeric keypad module 1168/49...
Page 733 Call module installation It is suggested to install the modules at the height shown below, according to the system to be realized. However, for complex systems with several modules, for a correct installation consider the height shown in the figure to fix the camera. If the system is a door phone, height refers to the door unit. Flush-mounted version •...
Page 734 • Remove the upper header and the lower header from the frame using a flat screwdriver at the tip 0. • Fit the module holder frame. MT124-032N...
Page 735 • Tip the holder frame and connect the wires. • Adjust correct perpendicularity of the call module. MT124-032M...
Page 736 • Establish the connections between the various modules with the wires provided before powering the system. • Use the cord provided with the frame to connect modules belonging to frames arranged side by side. • On the last module be sure to protect the OUT connector using the cap provided. RESET •...
Page 737 • Close the frame by tightening the screws. • Attach upper header and lower the frame. MT124-032M...
Page 738 Wall-mounted version • Remove the upper header and the lower header from the frame using a flat screwdriver at the tip 0. • Remove the module holder frame from the casing. MT124-032N...
Page 739 • Secure the casing with screws to the wall. • Fit the module holder frame. MT124-032M...
Page 740 • Fit the modules in the frame. • Tip the frame and connect the wires. MT124-032N...
Page 741 • Adjust correct perpendicularity of the panel. • Establish the connections between the various modules with the wires provided before powering the system. • On the last module be sure to protect the OUT connector using the cap provided. RESET MT124-032M...
Page 742 • On the rear of the external unit there is the RESET key which must be pressed to restart or reset the device to factory settings. • Attach upper header and lower the frame. • Attach upper header and lower the frame. MT124-032N...
Page 743 APPENDIX M1: Streaming video from IPerCom calling stations to NVR Urmet The following procedure describes how to display and record the following on Urmet 1098/324P-326P- 328P NVR devices: • streaming video during calls from IPerCom calling stations to apartments or to a generic apartment station;...
Page 744 Display of the software version Follow the procedure below to view the software version of the Urmet NVR device. 1. Connect to a switch a PC and the Urmet NVR device (via one of the LAN ports or via the WAN port); 2.
Page 745 Figure 792: default username and password to access the Urmet NVR device The username “admin” cannot be changed At this point a password recovery screen appears with related security questions. The user can fill in this form and press the “OK” button or press the “Cancel” button. In both cases the following dialog box appears: Figure 793: password accepted MT124-032M...
Page 746 After pressing the “OK” button, the login window appears: Figure 794: login window After entering your username (“admin”) and password and pressing the “Login” button, the following screen appears: Figure 795: access to the NVR device MT124-032N...
Page 747 By pressing on the “Remote settings” item (red arrow), the following screen appears: Figure 796: tab “Remote Setting” On the left side of the screen, move the scroll bar to the bottom until the “System” section and the “Information” item are displayed (red arrow): Figure 797: tab “Remote Setting”...
Page 748 By pressing on the “Information” item, the software version of the Urmet NVR device is displayed (red arrow): Figure 798: tab “Remote Setting” - section “System” --- > “Information” Before continuing with the other operations, we recommend extending the time out of the connection via the web page to the Urmet NVR device.
Page 749 Software update of the Urmet NVR device Follow the following procedure to update the software version of the Urmet NVR device. 1. Download the software version V8.2.4.1-20240515 or higher from the website www.urmet.com the 1098/324P-326P-328P related web page; 2. Press on the “Remote Setting” item, then in the “System” section press on the “Maintenance” item, then on the “Upgrade”...
Page 750 Connection of the Urmet NVR device to the IPerCom system The procedure below refers to an IPerCom system with dynamic addressing via a DHCP Server. In the “Network” section, press on the “General” item, then in the “WAN” section, check that the DHCP option is enabled.
Page 751 At this point, from a PC with an IP address in the same subnet as the IPerCom system, enter the IP address reported in the Device Config Tool application in the address bar of the browser. After entering the username and password, you can connect to the Urmet NVR device again. In the “Network”...
Page 752 Enabling the RTSP streaming during calls from Modular Calling Station with 1060/48 1. Access the configuration page of an IPerCom calling station (for example the Modular Calling Station with 1060/48) via the configurator; 2. Enable the “RTSP In-Call Stream” item by selecting the relevant box: Figure 803: enabling of the RTSP streaming from the configurator for the Modular Entry Panel with 1060/48 3.
Page 753 The above values can be modified and saved by pressing the “Apply” button. Every time you enable the RTSP streaming of a calling station, the first available IP address within the range of IP addresses set in the previous figure is proposed in the relevant “IP address” field. The IP address range and the related netmask must have compatible values.
Page 754 Press the button (“Operation” column in the red box) relating to channel 1 (CH1). The following screen appears: Figure 806: parameters for setting the channel In the “Protocol” field, select the “RTSP” item. The following screen appears: Figure 807: RTSP protocol setting on CH1 channel MT124-032N...
Page 755 Then fill in the other fields as shown below, assuming that the default values of the RTSP streaming have not been changed: Figure 808: URL, username, and password settings on CH1 channel The string for RTSP streaming to be entered is the following: rtsp://10.10.128.0:8554/h264urmet; username and password must be entered separately.
Page 756 Viewing the streaming video To view the streaming video, you need to press on the “Live” item. The following screen appears: Figure 810: “Live” tab to view the streaming video If on the IPerCom system no call from the Modular Calling Station with 1060/48 is in progress or if no auto- on towards the Modular Calling Station with 1060/48 is being performed from any video door phone, no streaming video is displayed.
Page 757 On the contrary, if an apartment/resident is called from the Modular Calling Station with 1060/48 or an auto-on is made from a video door phone towards the Modular Calling Station with 1060/48, the corresponding video streaming is displayed on the Urmet NVR device: Figure 811: streaming video during calls from the calling station or auto-on from the video door phone What is written above applies to any other calling station present on the IPerCom system.
Page 758 Recording of the streaming video To view the recording settings, press on the “Remote Setting” item, then in the “Record” section select the “Record” item, as shown below: Figure 812: tab “Remote Setting” - section “Record” --- > “Record” The “Record” item is already enabled (as indicated by the red arrow in the figure) for all channels. MT124-032N...
Page 759 To view the recording, press on the “Playback” item, as shown below: Figure 813: “Playback” tab to view the recording In the “Channel List” section, select the channel for which you want to play the recording of the streaming video (you can select one channel at a time). If you select channel 1 and press the “Search” button, the following screen appears: Figure 814: channel selection in the “Playback”...
Page 760 The vertical green bars in the red box indicate the time intervals of when the recording occurred. By pressing the button (highlighted by the red arrow), you can play the recording, which starts at the first green bar. Simply press the mouse on a subsequent green bar to play the recording corresponding to another time interval.
Page 761 APPENDIX M2: RTSP Cameras with NVR Urmet device Below is a short procedure for integrating the RTSP Cameras into the IPerCom system through the Urmet 1098/324P-326P-328P NVR devices connected in turn to the IPerCom system. In this way the streaming video of the RTSP Cameras will be visible from the system's video door phones (in auto-on, in call both during the unhook time and during the conversation time), from the Switchboard application and can also be recorded (and displayed) by the Urmet NVR device.
Page 762 1. ROUTER 1 • Enable the DHCP Server and ensure that it assigns addresses of the 10.2.1.x/24 type; • Set the WAN port in DHCP. 2. ROUTER 2 • Enable the DHCP Server and ensure that it assigns addresses of the 192.168.88.x/24 type; •...
Page 763 The following screen appears: Figure 818: “RTSP Camera (NVR)” device configuration page The following table shows the meaning of the fields for the “RTSP Camera (NVR)” device: General Settings Name Meaningful name to be assigned to the RTSP Camera connected to the Urmet NVR device Identifier Unique identifier of the NVR device (serial number or other)
Page 764 An example URI for streaming is as follows: rtsp://admin:Password1!@192.168.88.158:80/rtsp/streaming?channel=01&subtype=0 where: - <admin>: username for accessing the Urmet NVR device, - <Password1!>: password for accessing the Urmet NVR device, - <192.168.88.158>: Urmet NVR device IP address, - <80>: RTSP streaming port, - <rtsp/streaming?channel=01&subtype=0>: stream for channel 1.
Page 765 APPENDIX N: “Site name” and “Global site ID” field definition The site represents the system you want to configure, meaning for system the entire network, devices and IPerCom software applications. It is possible to assign a name to the site and this is a fundamental data because it allows the site to be uniquely recognized in all the possible applications in which it is involved.
Page 766 In this phase it is necessary to create a new configuration via the "Create" button in the "Configuration" tab: Figure 820: creation of a new configuration The screen that appears is the following: Figure 821: “Site name” field when creating a configuration The first data to enter is the site name (red box).
Page 767 After entering the name of the site (for example “via Bologna 188/C Turin”), IPerCom Installer Tools shows this data on the right and left side of the screen (after having applied the configuration to the site): Figure 822: “Site name” field filled in in IPerCom Installer Tools The site name can subsequently be changed from the configurator and IPerCom Installer Tools will always show the aligned data (after having applied the configuration).
Page 768 If CallMe Manager support is enabled from the configurator, the "Global site ID" field is also filled in in the screen above (after having applied the configuration): Figure 823: “Global site ID” filled in In the CallMe Manager application, once the site has been imported, the “Site name” field reports what is reported in IPerCom Installer Tools while the “ID”...
Page 769 APPENDIX O: IPassan integration with IPerCom The integration of the IPassan system with the IPerCom system is carried out as follows. Use the configurator to: • create the topological structure of the system (blocks, stairs, floors and apartments); • add the calling stations and enable the respective passages (pedestrian door and/or driveway gate); •...
Page 770 APPENDIX P1: How to properly turn 1060/1 Server on and off. The 1060/1 Server should never be turned off by directly disconnecting the power cord, as this can cause irreversible damage to the internal memory. The correct way to turn it on and off is shown below. Switching on the 1060/1 Server After connecting the 1060/1 Server to the power supply, the on/off key LED is yellow, as shown below: BUTTON ON OFF...
Page 771 APPENDIX P2: Connection between 1060/1 Server and UPS device. This appendix applies to UPS devices model BK350EI/BK500EI/BK650EI. The correct connection of a UPS device and the 1060/1 Server is required: • a power cable between the UPS device and the 1060/1 Server (not supplied with the product); •...
Page 772 In this way, on the Diagnostics tab of IPerCom Installer Tools by selecting 1060/1 Server from the devices in the system and pressing button , a screen with a series of detailed information about the UPS operating status appears, as shown below: MT124-032N...
Page 773 APPENDIX P3: Replacing a 1060/1 Server that is no longer working. The procedure for correctly replacing a 1060/1 Server that is no longer working is as follows: 1) in a network separated from the IPerCom system, upgrade the new server 1060/1 to the IPerCom version in the system using IPerUpgrade;...
Page 774 APPENDIX Q: First upgrade of a system via Server 1060/1 To upgrade a system (just installed and not configured) to version 2.1.2 via Server 1060/1, follow the steps below: • using IPerUpgrade, upgrade the Server 1060/1 (or Servers 1060/1) to the required IPerCom firmware version (IPerUpgrade application and user manual available at www.urmet.com);...
Page 775 Figure 826: automatic update via IperCom server • press the "Apply" button, save the configuration, and then distribute it. At this point, after connecting the Servers 1060/1 to the IPerCom network, one of them will upgrade the rest of the system to the same version to which it was upgraded. For subsequent upgrades, it will only be necessary to upgrade the system Servers 1060/1.
Page 776 APPENDIX R: Call to several Switchboard applications each connected to a CallMe app Call to competence Switchboard If an apartment (or a calling station) calls more than one competence switchboard (each with the call forwarding function enabled) the only CallMe app that receives the call is the one linked to the switchboard placed on the lowest node of the topological path of the calling device.
Page 777 Figure 828: Configuration page with several Switchboard applications on the plant The list can be modified using the buttons. "This Device" represents Switchboard 1, i.e. the Switchboard application whose configuration page has been opened via the configurator. The CallMe app associated with the first Switchboard application in the list (box in red) is the one that will receive the call if the APT1 apartment calls the competence switchboards.
Page 778 ALL TO ALL WITCHBOARDS If an apartment (or a calling station) calls from address book all switchboards of the plant (each one with the call forwarding function enabled) the only CallMe app that receives the call is the one linked to the switchboard placed on the highest node of the topological structure.
Page 779 Figure 830: Configuration page with several Switchboard applications on the plant The list can be modified using the buttons. "This Device" represents Switchboard 1, i.e. the Switchboard application whose configuration page has been opened via the configurator. The CallMe app associated with the first Switchboard application in the list (box in red) is the one that will ring after a call to all switchboards.
Page 780 APPENDIX S: CallMe contacts To ensure that the contacts in the address book of your video door phone also appear in your CallMe app, they must have the relevant box selected in the configurator. To do this, the following example is shown with 3 apartments on the same floor: Figure 831: Topological structure with tab “Addressbooks”...
Page 781 Instead, the contact relating to the apartment "01010103" has the "Video door phone with address book" box selected but not the "CallMe" box selected: Figure 833: Checkbox “CallMe” not selected The result of this configuration is that both contacts are present on the 7 '' MAX video door phone (for example): Figure 834: Contacts on video door phone MT124-032M...
Page 782 Instead, on the relevant CallMe app, only the contact relating to the apartment "01010102" appears in the Address Book section: Figure 835: App CallMe contacts The contacts generated by the video door phones with address book (MAX, VOG7, Basic and IPerCom Client 1060/43) by means of an “invitation”...
Page 783 APPENDIX T: Consumption in watts of IPerCom devices A table is shown where next to each IPerCom device the relative consumption in Watts referred to the PoE power supply is reported: Reference Description Consumption [W] 1060/12-13 Call Module Soft Touch 1060/17-18-23 Call Module Vandal Proof 1060/48...
Page 784 APPENDIX U: Types of system/performance for which the presence of the 1060/1 Server is required Depending on the type of system required and/or on the performance that the system must support, the presence of at least one 1060/1 Server may be mandatory. As regards the type of system, we can distinguish the cases in which the system is not in IPerCloud mode and the case in which it is.
Page 785 The same 1060/1 Server is sufficient to cover one or more conditions among those listed above and one or more performances among the 4 listed above. The presence of multiple 1060/1 Server on a system is dictated by requests on the same system. MT124-032M...
Page 786 APPENDIX V: Device compatibility table A table is shown where for each officially released version of IPerCom the set of supported devices is indicated. This table is of fundamental importance for installers as: • in case of replacement or addition of a new device, this may not be compatible with the version currently installed on the system, and this would require an update of the entire system;...
Page 787 IPERCOM versions Supported devices Code Ver. 1.0.0 1.1.0 1.2.0 1.3.0 1.4.0 2.0.0 2.1.0 2.1.1 2.1.2 2.2.0 3.0.0 3.1.0 dec-18 dec-18 apr-19 sep-19 nov-19 dec-20 oct-21 apr-22 may-22 dec-22 oct-23 jul-24 VDP IP 7'' 1717/3x A31S VDP IP 7'' 1717/4x A31S KEY READER 1060/82 CM ELEKTA...
Page 788 Table 98: Device compatibility with IPerCom versions MT124-032N...
Page 789 APPENDIX W1: RTSP Cameras supported by IPerCom video door phones 1761/15-16-17-18 e VOG 1761/6 Below is the list of supported RTSP Cameras: • Camera IP 5M 2.8-13mm Bullet ECO 2 Ref. 1099/501A; • Camera IP 5M 2.8mm Dome PLUS AI Ref. 1099/550B; •...
Page 790 APPENDIX W2: Auto-on on RTSP Cameras In general, the auto-on function on compatible RTSP Cameras is available on video door phones and Switchboard / IPerCom Client applications in the conditions shown below: • by means of the auto-on button of the video door phones and IPerCom Client application (for the Switchboard application there is a dedicated item in the Tools menu);...
Page 791 APPENDIX X: CallMe operating mode for VOG , MAX 1717/3x and 1717/2x video door phones 1761/3x and MAX 1717/2x, 3x video door phones can work in CallMe mode. The CallMe mode allows you to have a new application like CallMe on the video door phone with the following features: •...
Page 792 After this, the following window appears: Top Page in CallMe Mode Press the icon in the red box, then go to the login window and enter the same credentials used in the CallMe app on your smartphone/tablet. The CallMe on video door phones VOG and MAX supports IPerCom and IPerCloud apartments.
Page 793 APPENDIX V: Template of the list of devices installed in the system If the installer adds the devices via Mode 3.1 during the configuration phase (paragraph 8.3.2.5), it is necessary that the basic information of each device (type and MAC address) as well as its topological location are written down during the installation of the system.
Page 794 MT124-032N...
