urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 634

IperCom Clock Module 1060/85
The following table shows the meaning of the fields for "IperCom Clock Module 1060/85".
General Settings
Name
MAC Address
IP Address
Device Code
Location
It is necessary to upgrade the IPerCom system to version 1.2.0 or higher for proper operation of the
module in question.
634
Figure 760: IperCom Clock Module 1060/85
Name to assign to the IperCom Clock Module.
MAC address associated with the IperCom Clock Module.
IP address associated to the PC on which the IperCom Clock Module
programme is installed. Field visible only if manual network
configuration is set in system parameters. Value that cannot be
changed.
Value that cannot be changed.
Position in the system topology: it is possible to move the IperCom
Clock Module to another topological node by pressing the "Move"
button.
Table 87: General settings
settings
