urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 673

6. Terminal board
7. Jumper for power from Ipercom system
The device must be positioned as the last module on the panel. Respect the installation constraint of
maximum 12 modules of which only one is a 1168/45 module. The pedestrian lock activation time must be
programmed on the door unit.
The keys configuratione must be configured through the configurator, refer to the following paragraphs:
Residents and Not residents.
Installation
MT124-032M
1. indicating LED state: ON enable (default)
2. Do not change the arrangement of this dip switch
3. RS485 BUS: Ipercom mode
OFF disable
673
