urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 399

B
LOCK MODE ADDRESSING TYPE
In block mode addressing to call an apartment from the Call Module or Modular Calling Station with
1060/48 it is necessary to distinguish whether these are positioned on the "Site" node or not.
C M M
ALL ODULE OR ODULAR
To call an apartment by the keypad you need:
•
from Call Module (by means of arrow buttons) first select the block in which the apartment in
question is placed, then enter the numeric code associated with the apartment;
•
from Modular Calling Station with 1060/48, press the button corresponding to the icon
select block in which the apartment in question is placed, then enter the numeric code associated
with the apartment.
C M M
ALL ODULE OR ODULAR
To call an apartment by the keypad you need:
•
from Call Module enter the numeric code associated with the apartment;
•
from Modular Calling Station with 1060/48 enter the numeric code associated with the apartment.
Again, in this type of addressing, the numeric code (which appears in the "Settings" tab of the "Topology"
tab) can be set automatically or manually, as already seen previously.
When typing the code from the alphanumeric keyboard, the on the left zeros can be omitted.
MT124-032N
C S 1060/48
ALLING TATION WITH
C S 1060/48
ALLING TATION WITH
ON SITE NODE
/ /F
ON NODE BLOCK STAIR
, then
LOOR
