APPENDIX U: Types of system/performance for which the presence of the
1060/1 Server is required
Depending on the type of system required and/or on the performance that the system must support, the
presence of at least one 1060/1 Server may be mandatory.
As regards the type of system, we can distinguish the cases in which the system is not in IPerCloud mode
and the case in which it is. Regarding the first case, the line highlighted in yellow requires the presence of at
least one 1060/1 Server in the system:
Regarding the second line, it is sufficient for only one of the 3 conditions above to occur for Server
1060/1 to be mandatory.
In addition to the above, in the case of IPerCom systems in IPerCloud mode, the 1060/1 Server is necessary
if at least one of the conditions reported below is verified on the system:
•
at least one calling station other than Modular Calling Station with 1060/48 or Entry Panel 1060/33-
34 or Entry Panel 1060/21,
or
•
several IPerCloud apartments greater than 200,
or
•
only Entry Panels 1060/33-34 with several IPerCloud apartments greater than 32,
or
•
only Entry Panels 1060/21 with several IPerCloud apartments greater than 20.
The performances that require the presence of a 1060/1 Server are the following:
•
display of system logs on IPerCom Installer Tools;
•
modification of the system configuration remotely (Server 1060/1 is required on the remote system
whose configuration is to be modified);
•
saving the system configuration (backup) manually or automatically in periodic mode;
•
centralized update of devices (via Server 1060/1).
784
Device number
Apartment number
≤ 1000
> 1000 (max 4000) > 1000 (max 4000)
Table 97: presence of a Server 1060/1
Resident and non-
resident number
≤ 1000 ≤ 1000
> 1000 (max 10000)
