urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 651

3. Adding an RTSP Camera
If you add an RTSP Camera to the system, the following screen appears:
The "IP Address" field automatically reports the first available IP address among those present in the range
of IP addresses defined in
The proposed IP address must be the same as the one manually set in the RTSP Camera that you are adding
into the configuration: if this is not the case, simply change it the configurator.
The proposed IP address can be changed to another IP address even outside the range set in
774 (provided it has not already been used).
Similarly, if RTSP streaming of a calling station is enabled, the IP address assigned will be included in the
range of Figure 774. This can be modified with another value which in this case, however, must be included
in the range set and must not have already been used.
MT124-032M
Figure 775: adding an RTSP camera to the IPerCom system
Figure 774.
Figure
651
