urmet domus IPerCom 3.1.0 System Technical Manual For The Installer page 294

7.1.5.8.3 Events Open Door and Open Gate
The "Open Door" and "Open Gate" events can refer to any door or gate in the system. If you choose one of
these two events, the "any" (default) events will appear, as shown in the image below:
In this case, about calling station access points, the activation of one or more relay outputs also takes place
outside the call step itself, by simply pressing the door and gate opening keys of apartment stations
Alternatively, you can choose a precise entrance (door or gate) using a special drop-down menu.
In this second case the relay outputs are piloted only after the actual opening of the selected access point.
If the door of a Key Reader is chosen for the Door Opening event, the selected outputs are controlled
only if the Key Reader is on the topological path of the concerned apartment and not when an
enabled key is passed.
294
Figure 343: Open door/gate activation
MT124-032N
