Universal serial bus full-speed host/device interface (USB)
37.6.2

Buffer descriptor table

Note: The buffer descriptor table is located inside the packet buffer memory in the separate "USB
SRAM" address space.
Although the buffer descriptor table is located inside the packet buffer memory ("USB
SRAM" area), its entries can be considered as additional registers used to configure the
location and size of the packet buffers used to exchange data between the USB macro cell
and the device.
The first packet memory location is located at USB SRAM base address. The buffer
descriptor table entry associated with the USB_CHEPnR registers is described below. The
memory should be addressed using Word (32-bit) accesses.
A thorough explanation of packet buffers and the buffer descriptor table usage can be found
in Structure and usage of packet buffers on page
Channel/endpoint transmit buffer descriptor n (USB_CHEP_TXRXBD_n)
Address offset: n*8
This register description applies when corresponding CHEPnR register does not program
the use of double buffering (otherwise refer to following register description)
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:26 Reserved, must be kept at reset value.
Bits 25:16 COUNTn_TX[9:0]: Transmission byte count
Bits 15:0 ADDRn_TX[15:0]: Transmission buffer address
Channel/endpoint receive buffer descriptor n [alternate]
(USB_CHEP_TXRXBD_n)
Address offset: n*8
This register description applies when corresponding CHEPnR register programs the use of
double buffering and activates receive buffers (otherwise refer to previous register
description).
This table location is used to store two different values, both required during packet
reception. The most significant bits contains the definition of allocated buffer size, to allow
buffer overflow detection, while the least significant part of this location is written back by the
USB peripheral at the end of reception to give the actual number of received bytes. Due to
1302/1390
28 27 26 25
Res. Res.
rw
12 11 10 9
rw rw rw rw
These bits contain the number of bytes to be transmitted by the endpoint/channel associated
with the USB_CHEPnR register at the next IN token addressed to it.
These bits point to the starting address of the packet buffer containing data to be transmitted
by the endpoint/channel associated with the USB_CHEPnR register at the next IN token
addressed to it. Bits 1 and 0 must always be written as "00" since packet memory is word
wide and all packet buffers must be word aligned.
1268.
24 23 22
COUNTn_TX[9:0]
rw rw rw
8 7 6
ADDRn_TX[15:0]
rw rw rw
RM0444 Rev 5
21 20 19 18
rw rw rw rw
5 4 3 2
rw rw rw rw
RM0444
17 16
rw rw
1 0
rw rw
