To avoid spurious clearing of some bits, it is recommended to clear them with a load
instruction where all bits which must not be altered are written with 1, and all bits to be
cleared are written with 0 (these bits can only be cleared by software). Read-modify-write
cycles should be avoided because between the read and the write operations another bit
could be set by the hardware and the next write clears it before the microprocessor has the
time to service the event.
31 30 29
LS_ DCON_
Res. Res.
DCON STAT
r r
15 14 13
PMA
CTR ERR WKUP
OVR
r rc_w0 rc_w0 rc_w0
Bit 31 Reserved, must be kept at reset value.
Bit 30 LS_DCON: Low speed device connected
– Host mode:
This bit is set by hardware when an LS device connection is detected. Device connection is
signaled after LS J-state is sampled for 22 consecutive cycles of the USB clock (48 MHz)
from the unconnected state.
Bit 29 DCON_STAT: Device connection status
– Host mode:
This bit contains information about device connection status. It is set by hardware when a
LS/FS device is attached to the host while it is reset when the device is disconnected.
0: No device connected
1: FS or LS device connected to the host
Bits 28:17 Reserved, must be kept at reset value.
Bit 16 THR512: 512 byte threshold interrupt
This bit is set to 1 by the hardware when 512 bytes have been transmitted or received during
isochronous transfers. This bit is read/write but only 0 can be written and writing 1 has no
effect. Note that no information is available to indicate the associated channel/endpoint,
however in practice only one ISO endpoint/channel with such large packets can be
supported, so that channel.
Bit 15 CTR: Completed transfer in host mode
This bit is set by the hardware to indicate that an endpoint/channel has successfully
completed a transaction; using DIR and IDN bits software can determine which
endpoint/channel requested the interrupt. This bit is read-only.
Bit 14 PMAOVR: Packet memory area over / underrun
This bit is set if the microcontroller has not been able to respond in time to an USB memory
request. The USB peripheral handles this event in the following way: During reception an
ACK handshake packet is not sent, during transmission a bit-stuff error is forced on the
transmitted stream; in both cases the host retries the transaction. The PMAOVR interrupt
should never occur during normal operations. Since the failed transaction is retried by the
host, the application software has the chance to speed-up device operations during this
interrupt handling, to be ready for the next transaction retry; however this does not happen
during isochronous transfers (no isochronous transaction is anyway retried) leading to a loss
of data in this case. This bit is read/write but only 0 can be written and writing 1 has no effect.
Universal serial bus full-speed host/device interface (USB)
28 27 26 25
Res. Res. Res.
12 11 10 9
RST_
SUSP SOF
DCON
rc_w0 rc_w0 rc_w0
24 23 22
Res. Res. Res.
8 7 6
ESOF L1REQ Res.
rc_w0 rc_w0
RM0444 Rev 5
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
Res. DIR
r r r
17 16
THR
Res.
512
rc_w0
1 0
IDN[3:0]
r r
