FD controller area network (FDCAN)

FDCAN Tx event FIFO status register (FDCAN_TXEFS)

Address offset: 0x00E4

Reset value: 0x0000 0000

Bits 31:26 Reserved, must be kept at reset value.

Bit 25 TEFL: Tx Event FIFO element lost

This bit is a copy of interrupt flag IR[TEFL]. When IR[TEFL] is reset, this bit is also reset.

0 No Tx event FIFO element lost

1 Tx event FIFO element lost, also set after write attempt to Tx Event FIFO of size 0.

Bit 24 EFF: Event FIFO full

0: Tx event FIFO not full

1: Tx event FIFO full

Bits 23:18 Reserved, must be kept at reset value.

Bits 17:16 EFPI[1:0]: Event FIFO put index

Tx Event FIFO write index pointer, range 0 to 3.

Bits 15:10 Reserved, must be kept at reset value.

Bits 9:8 EFGI[1:0]: Event FIFO get index

Tx Event FIFO read index pointer, range 0 to 3.

Bits 7:3 Reserved, must be kept at reset value.

Bits 2:0 EFFL[2:0]: Event FIFO fill level

Number of elements stored in Tx event FIFO, range 0 to 3.

Address offset: 0x00E8

Reset value: 0x0000 0000
