2.7
Addressing Modes and Effective Address Calculation
The H8S/2000 CPU supports the eight addressing modes listed in table 2.11. Each instruction uses
a subset of these addressing modes. Arithmetic and logic instructions can use the register direct
and immediate modes. Data transfer instructions can use all addressing modes except program-
counter relative and memory indirect. Bit manipulation instructions use register direct, register
indirect, or absolute addressing mode to specify an operand, and register direct (BSET, BCLR,
BNOT, and BTST instructions) or immediate (3-bit) addressing mode to specify a bit number in
the operand.
Table 2.11 Addressing Modes
No. Addressing Mode
1
Register direct
2
Register indirect
3
Register indirect with displacement
4
Register indirect with post-increment
Register indirect with pre-decrement
5
Absolute address
6
Immediate
7
Program-counter relative
8
Memory indirect
Rev. 3.0, 10/02, page 46 of 686
op
op
op
EA(disp)
op
cc
Figure 2.11 Instruction Formats (Examples)
NOP, RTS, etc.
r m
r n
ADD.B Rn, Rm, etc.
r n
r m
MOV.B @(d:16, Rn), Rm, etc.
EA(disp)
BRA d:16, etc.
Symbol
Rn
@ERn
@(d:16,ERn)/@(d:32,ERn)
@ERn+
@–ERn
@aa:8/@aa:16/@aa:24/@aa:32
#xx:8/#xx:16/#xx:32
@(d:8,PC)/@(d:16,PC)
@@aa:8
