Embedded Flash memory (FLASH)
memory clock (HCLK3) and the internal voltage range of the device (V
Section 6.1.4: Dynamic voltage scaling
The table below shows the correspondence between wait states and frequency of the Flash
memory clock.
Table 12. Number of wait states according to Flash clock (HCLK3) frequency
Wait states (WS)
0 WS (1 HCLK cycle)
1 WS (2 HCLK cycles)
2 WS (3 HCLK cycles)
After power-on reset and wakeup from Standby, the HCLK3 clock frequency is 4 MHz in
range 1 and 0 wait state (WS) is configured in FLASH_ACR.
When changing the frequency of the Flash memory clock or the V
sequences detailed below must be applied in order to tune the number of wait states
needed to access the Flash memory:
Increase the CPU frequency
1. Program the new number of wait states to the LATENCY[2:0] bits in FLASH_ACR.
2. Check that the new number of wait states is taken into account to access the Flash
memory by reading back the LATENCY[2:0] bits in FLASH_ACR, and wait until the new
programmed number is read.
3. Modify the system cock source by writing the SW[1:0] bits in RCC_CFGR.
4. If needed, modify the CPU clock prescaler by writing the SHDHPRE[3:0] bits in
RCC_EXTCFGR.
5. Optionally, check that the new system clock source or/and the new Flash memory clock
prescaler value is/are taken into account by reading the clock source status (SWS(1:0]
bits) in RCC_CFGR, or/and the AHB prescaler value (SHDHPREF bit) in
RCC_EXTCFGR.
Decrease the CPU frequency
1. Modify the system clock source by writing the SW[1:0] bits in RCC_CFGR.
2. If needed, modify the Flash memory clock prescaler by writing the SHDHPRE[3:0] bits
in RCC_EXTCFGR.
3. Check that the new system clock source or/and the new Flash memory clock prescaler
value is/are taken into account by reading the clock source status (SWS[1:0] bits) in
RCC_CFGR, or/and the AHB prescaler value (SHDHPREF bit) in RCC_EXTCFGR.
Wait until the new programmed system clock source or/and new Flash memory clock
prescaler value is/are read.
4. Program the new number of wait states to the LATENCY[2:0] bits in FLASH_ACR.
5. Optionally, check that the new number of wait states is used to access the Flash
memory by reading back the LATENCY[2:0] bits in FLASH_ACR.
