7.4.26 RCC APB1 peripheral clock enable in Sleep mode register 2
(RCC_APB1SMENR2)
Address offset: 0x07C
Reset value: 0x0000 0061
Access: no wait state, word, half-word and byte access
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:7 Reserved, must be kept at reset value.
Bit 6 LPTIM3SMEN: Low-power timer 3 clock enable during CPU1 CSleep and CStop modes
Bit 5 LPTIM2SMEN: Low power timer 2 clock enable during CPU1 CSleep and CStop modes
Bits 4:1 Reserved, must be kept at reset value.
Bit 0 LPUART1SMEN: Low-power UART 1 clock enable during CPU1 CSleep and CStop modes
28 27 26 25
Res. Res. Res.
12 11 10 9
Res. Res. Res.
This bit is set and cleared by software.
0: LPTIM3 bus clock disabled by the clock gating during CPU1 CSleep and CStop modes
1: LPTIM3 bus clock enabled by the clock gating during CPU1 CSleep mode, disabled
during CPU1 CStop mode
This bit is set and cleared by software.
0: LPTIM2 bus clock disabled by the clock gating during CPU1 CSleep and CStop modes
1: LPTIM2 bus clock enabled by the clock gating during CPU1 CSleep mode, disabled
during CPU1 CStop mode
This bit is set and cleared by software.
0: LPUART1 bus clock disabled by the clock gating during CPU1 CSleep and CStop modes
1: LPUART1 bus clock enabled by the clock gating during CPU1 CSleep mode, disabled
during CPU1 CStop mode
24 23 22
Res. Res. Res. Res.
8 7 6
Res. Res.
rw
RM0453 Rev 2
Reset and clock control (RCC)
21 20 19 18
Res. Res. Res.
5 4 3 2
Res. Res. Res.
rw
17 16
Res. Res.
1 0
Res.
rw
