True random number generator (RNG)
22.3 RNG functional description
22.3.1 RNG block diagram
Figure 98
rng_it
rng_hclk
rng_clk
22.3.2 RNG internal signals
Table 129
at the STM32 product level (on pads).
Signal name
634/1454
shows the RNG block diagram.
Figure 98. RNG block diagram
Banked Registers
control
data
AHB
status
interface
AHB clock domain
RNG clock domain
describes a list of useful-to-know internal signals available at the RNG level, not
Table 129. RNG internal input/output signals
Signal type
rng_it Digital output
rng_hclk Digital input
rng_clk Digital input
CONDRST
RNG_CR
RNG_DR
RNG_SR
Fault detection
Clock checker
Health tests
en_osc
RNG global interrupt request
AHB clock
RNG dedicated clock, asynchronous to rng_hclk
RM0453 Rev 2
True RNG
Conditioning logic
1-bit
Post-processing (optional)
Sampling (x N) + XOR
Analog Analog Analog
...
noise noise noise
source 1 source 2 source N
Analog noise source
Description
