ST STM32WL55JC Reference Manual page 887

RM0453
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:0 CCR2[31:0]: Capture/Compare 2 value
26.4.18 TIM2 capture/compare register 3 (TIM2_CCR3)
Address offset: 0x3C
Reset value: 0x0000 0000
31 30 29 28
rw rw rw rw
15 14 13 12
rw rw rw rw
Bits 31:0 CCR3[31:0]: Capture/Compare value
26.4.19 TIM2 capture/compare register 4 (TIM2_CCR4)
Address offset: 0x40
Reset value: 0x0000 0000
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
If channel CC2 is configured as output:
CCR2 is the value to be loaded in the actual capture/compare 2 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR1 register
(bit OC2PE). Else the preload value is copied in the active capture/compare 2 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on OC2 output.
If channel CC2 is configured as input:
CCR2 is the counter value transferred by the last input capture 2 event (IC2). The
TIMx_CCR2 register is read-only and cannot be programmed.
27 26 25
rw rw rw
11 10 9
rw rw rw
If channel CC3 is configured as output:
CCR3 is the value to be loaded in the actual capture/compare 3 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR2 register
(bit OC3PE). Else the preload value is copied in the active capture/compare 3 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on OC3 output.
If channel CC3is configured as input:
CCR3 is the counter value transferred by the last input capture 3 event (IC3). The
TIMx_CCR3 register is read-only and cannot be programmed.
24 23 22
CCR2[31:16]
rw rw rw
8 7 6
CCR2[15:0]
rw rw rw
24 23 22
CCR3[31:16]
rw rw rw
8 7 6
CCR3[15:0]
rw rw rw
RM0453 Rev 2
General-purpose timer (TIM2)
21 20 19 18
rw rw rw rw
5 4 3 2
rw rw rw rw
21 20 19 18
rw rw rw rw
5 4 3 2
rw rw rw rw
17 16
rw rw
1 0
rw rw
17 16
rw rw
1 0
rw rw
887/1454
