RM0402
17.4.10

TIMx counter (TIMx_CNT)

Address offset: 0x24
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 CNT[15:0]: Counter value
17.4.11

TIMx prescaler (TIMx_PSC)

Address offset: 0x28
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 PSC[15:0]: Prescaler value
17.4.12

TIMx auto-reload register (TIMx_ARR)

Address offset: 0x2C
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0
12 11 10 9
rw rw rw rw
12 11 10 9
rw rw rw rw
The counter clock frequency CK_CNT is equal to f
PSC contains the value to be loaded in the active prescaler register at each update event.
12 11 10 9
rw rw rw rw
ARR[15:0]: Auto-reload value
ARR is the value to be loaded in the actual auto-reload register.
Refer to the Section 17.3.1: Time-base unit on page 485
and behavior.
The counter is blocked while the auto-reload value is null.
General-purpose timers (TIM2 to TIM5)
8 7 6
CNT[15:0]
rw rw rw
8 7 6
PSC[15:0]
rw rw rw
CK_PSC
8 7 6
ARR[15:0]
rw rw rw
RM0402 Rev 6
5 4 3 2
rw rw rw rw
5 4 3 2
rw rw rw rw
/ (PSC[15:0] + 1).
5 4 3 2
rw rw rw rw
for more details about ARR update
1 0
rw rw
1 0
rw rw
1 0
rw rw
537/1163
