RM0402

29.15.22 OTG host frame interval register (OTG_HFIR)

Address offset: 0x404
Reset value: 0x0000 EA60
This register stores the frame interval information for the current speed to which the
OTG_FS controller has enumerated.
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:17 Reserved, must be kept at reset value.
Bit 16 RLDCTRL: Reload control
This bit allows dynamic reloading of the HFIR register during run time.
0: The HFIR cannot be reloaded dynamically
1: The HFIR can be dynamically reloaded during run time.
This bit needs to be programmed during initial configuration and its value must not be
changed during run time.
Caution: RLDCTRL = 0 is not recommended.
Bits 15:0 FRIVL[15:0]: Frame interval
The value that the application programs to this field, specifies the interval between two
consecutive SOFs (FS) or Keep-Alive tokens (LS). This field contains the number of PHY
clocks that constitute the required frame interval. The application can write a value to this
register only after the port enable bit of the host port control and status register (PENA bit in
OTG_HPRT) has been set. If no value is programmed, the core calculates the value based
on the PHY clock specified in the FS/LS PHY clock select field of the host configuration
register (FSLSPCS in OTG_HCFG). Do not change the value of this field after the initial
configuration, unless the RLDCTRL bit is set. In such case, the FRIVL is reloaded with each
SOF event.
– Frame interval = 1 ms × (FRIVL - 1)
28 27 26 25
Res. Res. Res.
12 11 10 9
rw rw rw rw
USB on-the-go full-speed (OTG_FS)
24 23 22
Res. Res. Res.
8 7 6
FRIVL[15:0]
rw rw rw
RM0402 Rev 6
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
rw rw rw rw
17 16
RLD
Res.
CTRL
rw
1 0
rw rw
1027/1163
