Analog-to-digital converter (ADC)
13.12.2

ADC control register 1 (ADC_CR1)

Address offset: 0x04
Reset value: 0x0000 0000
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
DISCNUM[2:0] JDISCEN DISCEN JAUTO AWDSGL
rw rw rw rw
Bits 31:27 Reserved, must be kept at reset value.
Bit 26 OVRIE: Overrun interrupt enable
This bit is set and cleared by software to enable/disable the Overrun interrupt.
0: Overrun interrupt disabled
1: Overrun interrupt enabled. An interrupt is generated when the OVR bit is set.
Bits 25:24 RES[1:0]: Resolution
These bits are written by software to select the resolution of the conversion.
00: 12-bit (minimum 15 ADCCLK cycles)
01: 10-bit (minimum 13 ADCCLK cycles)
10: 8-bit (minimum 11 ADCCLK cycles)
11: 6-bit (minimum 9 ADCCLK cycles)
Bit 23 AWDEN: Analog watchdog enable on regular channels
This bit is set and cleared by software.
0: Analog watchdog disabled on regular channels
1: Analog watchdog enabled on regular channels
Bit 22 JAWDEN: Analog watchdog enable on injected channels
This bit is set and cleared by software.
0: Analog watchdog disabled on injected channels
1: Analog watchdog enabled on injected channels
Bits 21:16 Reserved, must be kept at reset value.
Bits 15:13 DISCNUM[2:0]: Discontinuous mode channel count
These bits are written by software to define the number of regular channels to be converted
in discontinuous mode, after receiving an external trigger.
000: 1 channel
001: 2 channels
...
111: 8 channels
Bit 12 JDISCEN: Discontinuous mode on injected channels
This bit is set and cleared by software to enable/disable discontinuous mode on the injected
channels of a group.
0: Discontinuous mode on injected channels disabled
1: Discontinuous mode on injected channels enabled
334/1163
27 26 25
Res. OVRIE RES
rw rw
11 10 9
SCAN
rw rw rw
RM0402 Rev 6
24 23 22
AWDEN JAWDEN Res.
rw rw rw
8 7 6
JEOCIE AWDIE EOCIE
rw rw rw
21 20 19 18
Res. Res. Res.
5 4 3 2
AWDCH[4:0]
rw rw rw rw
RM0402
17 16
Res. Res.
1 0
rw rw
