SDIOCLK are frozen, the APB2 interface is still alive. The FIFO can thus be filled or emptied
even if flow control is activated.
To enable HW flow control, the SDIO_CLKCR[14] register bit must be set to 1. After reset
Flow Control is disabled.
27.8

SDIO registers

The device communicates to the system via 32-bit-wide control registers accessible via
APB2.
27.8.1

SDIO power control register (SDIO_POWER)

Address offset: 0x00
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:2 Reserved, must be kept at reset value.
[1:0] PWRCTRL: Power supply control bits.
These bits are used to define the current functional state of the card clock:
00: Power-off: the clock to card is stopped.
01: Reserved
10: Reserved power-up
11: Power-on: the card is clocked.
Note: At least seven PCLK2 clock periods are needed between two write accesses to this register.
Note: After a data write, data cannot be written to this register for three SDIOCLK clock periods
plus two PCLK2 clock periods.
27.8.2

SDIO clock control register (SDIO_CLKCR)

Address offset: 0x04
Reset value: 0x0000 0000
The SDIO_CLKCR register controls the SDIO_CK output clock.
31 30 29
Res. Res. Res. Res.
15 14 13
HWFC NEGE
Res.
_EN DGE
rw rw
28 27 26 25
Res. Res. Res.
12 11 10 9
Res. Res. Res.
28 27 26 25
Res. Res. Res.
12 11 10 9
WID BYPAS PWRS
BUS S AV
rw rw rw rw
Secure digital input/output interface (SDIO)
24 23 22
Res. Res. Res.
8 7 6
Res. Res. Res.
24 23 22
Res. Res. Res.
8 7 6
CLKEN
rw rw rw
RM0402 Rev 6
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
Res. Res. Res. Res.
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
CLKDIV
rw rw rw rw
17 16
Res. Res.
1 0
PWRCTRL
rw rw
17 16
Res. Res.
1 0
rw rw
