RM0402
6.3.24
RCC Dedicated Clocks Configuration Register (RCC_DCKCFGR)
Address offset: 0x8C
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access.
31
30
29
CKDFSD
Res.
Res.
M1SEL
rw
15
14
13
CKDFSD
Res.
Res.
M1ASEL
rw
Bit 31 CKDFSDMSEL: DFSDM1 Kernel clock selection.
Bits 30:29 Reserved, must be kept at reset value.
Bits 28:27 I2S2SRC[1:0]: I2S APB2 clocks source selection (I2S1/4/5)
Bits 26:25 I2S1SRC[1:0]: I2S APB1 clocks source selection (I2S2/3)
Bit 24 TIMPRE: Timers clocks prescalers selection
28
27
26
I2S2RC[1:0]
I2S1RC[1:0]
rw
rw
12
11
10
Res.
Res.
Res.
Res.
0: APB2 clock used as Kernel clock
1: System clock used as Kernel clock
Set and reset by software.
These bits should be written when the PLL and PLLI2S are disabled.
00: I2S APB2 clock frequency = f(
01: I2S APB2 clock frequency = external I2S clock from pads - alternate function input
frequency
10: I2S APB2 clock frequency = f(
11: I2S APB2 clock frequency = HSI/HSE depending on PLLSRC (PLLCFGR(22))
Set and reset by software to control the frequency of the APB1 I2S clock.
These bits should be written when the PLL and PLLI2S are disabled.
00: I2S APB1 clock frequency = f(
01: I2S APB1 clock frequency = external I2S clock from pads - alternate function input
frequency
10: I2S APB1 clock frequency = f(
11: I2S APB1 clock frequency = HSI/HSE depending on PLLSRC (PLLCFGR(22))
Set and reset by software to control the clock frequency of all the timers connected to APB1
and APB2 domain.
0: If the APB prescaler (PPRE1, PPRE2 in the RCC_CFGR register) is configured to a
division factor of 1, TIMxCLK = PCLKx. Otherwise, the timer clock frequencies are set to
twice to the frequency of the APB domain to which the timers are connected:
TIMxCLK = 2xPCLKx.
1:If the APB prescaler (PPRE1, PPRE2 in the RCC_CFGR register) is configured to a
division factor of 1, 2, or 4, TIMxCLK = HCKL. Otherwise, the timer clock frequencies are set
to four times to the frequency of the APB domain to which the timers are connected:
TIMxCLK = 4xPCLKx.
Reset and clock control (RCC) for STM32F412xx
25
24
23
22
TIMPRE
Res.
Res.
rw
9
8
7
6
Res.
Res.
Res.
)
PLLI2S_R
)
PLL_R
)
PLLI2S_R
)
PLL_R
RM0402 Rev 6
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
Res.
Res.
Res.
Res.
17
16
Res.
Res.
1
0
Res.
Res.
161/1163
