RM0402
Slave TIM
TIM9
TIM12
18.4.3

TIM9/12 Interrupt enable register (TIMx_DIER)

Address offset: 0x0C
Reset value: 0x0000
15 14 13
Res. Res. Res. Res.
Bits 15:7
Bit 6 TIE: Trigger interrupt enable
Bits 5:3
Bit 2 CC2IE: Capture/Compare 2 interrupt enable
Bit 1 CC1IE: Capture/Compare 1 interrupt enable
Bit 0 UIE: Update interrupt enable

Table 103. TIMx internal trigger connections

ITR0 (TS = '000')
TIM2
TIM4
12 11 10 9
Res. Res. Res.
Reserved, must be kept at reset value.
0: Trigger interrupt disabled.
1: Trigger interrupt enabled.
Reserved, must be kept at reset value.
0: CC2 interrupt disabled.
1: CC2 interrupt enabled.
0: CC1 interrupt disabled.
1: CC1 interrupt enabled.
0: Update interrupt disabled.
1: Update interrupt enabled.
General-purpose timers (TIM9 to TIM14)
ITR1 (TS = '001')
TIM3
TIM5
8 7 6
Res. Res. TIE
rw
RM0402 Rev 6
ITR2 (TS = '010') ITR3 (TS = '011')
TIM10_OC
TIM13_OC
5 4 3 2
Res. Res. Res. CC2IE
rw
TIM11_OC
TIM14_OC
1 0
CC1IE UIE
rw rw
569/1163
591
