RM0402
18.5.10
TIM10/11/13/14 capture/compare register 1 (TIMx_CCR1)
Address offset: 0x34
Reset value: 0x0000
15
14
13
rw
rw
rw
Bits 15:0 CCR1[15:0]: Capture/Compare 1 value
If channel CC1 is configured as output:
CCR1 is the value to be loaded in the actual capture/compare 1 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR1 register (bit
OC1PE). Else the preload value is copied in the active capture/compare 1 register when an
update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on OC1 output.
If channel CC1is configured as input:
CCR1 is the counter value transferred by the last input capture 1 event (IC1).
18.5.11
TIM11 option register 1 (TIM11_OR)
Address offset: 0x50
Reset value: 0x0000
15
14
13
Res.
Res.
Res.
Res.
Bits 15:2
Reserved, must be kept at reset value.
Bits 1:0
TI1_RMP[1:0]: TIM11 Input 1 remapping capability
Set and cleared by software.
00,01,11: TIM11 Channel1 is connected to the GPIO (refer to the Alternate function mapping
table in the datasheets).
10: HSE_RTC clock (HSE divided by programmable prescaler) is connected to the
TIM11_CH1 input for measurement purposes.
12
11
10
9
rw
rw
rw
rw
12
11
10
9
Res.
Res.
Res.
General-purpose timers (TIM9 to TIM14)
8
7
6
CCR1[15:0]
rw
rw
rw
8
7
6
Res.
Res.
Res.
RM0402 Rev 6
5
4
3
2
rw
rw
rw
rw
5
4
3
2
Res.
Res.
Res.
Res.
1
0
rw
rw
1
0
TI1_RMP[1:0]
rw
589/1163
591
