RM0402
Figure 50. Synchronous multiplexed write mode waveforms - PSRAM (CRAM)
HCLK
CLK
A[25:16]
NEx
Hi-Z
NOE
NWE
NADV
NWAIT
(WAITCFG = 0)
A/D[15:0]
1 clock 1 clock
1. The memory must issue NWAIT signal one cycle in advance, accordingly WAITCFG must be programmed to 0.
2. Byte Lane (NBL) outputs are not shown, they are held low while NEx is active.
Table 68. FSMC_BCRx bitfields (Synchronous multiplexed write mode)
Bit number
31:22
21
20
19
18:16
15
14
13
Memory transaction = burst of 2 half words
addr[25:16]
(DATLAT + 2)
CLK cycles
Addr[15:0]
Bit name
Reserved
0x000
WFDIS
As needed
CCLKEN
As needed
CBURSTRW 0x1
CPSIZE
As needed (0x1 for CRAM 1.5)
ASYNCWAIT 0x0
EXTMOD
0x0
To be set to 1 if the memory supports this feature, to be kept at 0
WAITEN
otherwise.
RM0402 Rev 6
Flexible static memory controller (FSMC)
inserted wait state
data
Value to set
data
ai14731f
277/1163
287
