HIGH PRESSURE PUMP (HPP)

COMPONENTS LOCATOR

1. Inlet Metering Valve (IMV)
2. Hydraulic pressure head
3. Plunger
4. Drive shaft and cam ring
5. Housing
6. Roller and shoe
ENGINE HOUSING
DI ENG SM - 2004.4
Low pressure line
Fuel temperature sensor
IMV connector
High pressure
supply line
7. Low pressure pump
8. Fuel temperature sensor
9. Venting
10. High fuel pressure supply line
11. Pressure regulator
DI02-51
High pressure
line
Venturi return line
Inlet Metering
Valve (IMV)
Y220_02133
