DIGIVOICE - Technical Manual
CALL MODULE
Download from: www.urmetdomus.com Technical Manuals area.
SECTION CONTENTS
SECTION 2B
(REV.F)
ADDITIONAL ALPHABETIC KEYPAD Ref. 1038/73 ....................12
SPECIFICATIONS..........................................................................12
INSTALLATION ..............................................................................12
Flush mounting version ..............................................................12
Wall-mounted version with case and hood .................................15
Examples of modular installation ................................................16
