www.ti.com

9.1.1 CCFG Registers

Table 9-1
lists the memory-mapped registers for the CCFG. All register offset addresses not listed in
Table 9-1
must be considered as reserved locations and the register contents must not be modified.
Offset
Acronym
FA8h
EXT_LF_CLK
FACh
MODE_CONF_1
FB0h
SIZE_AND_DIS_FLAGS
FB4h
MODE_CONF
FB8h
VOLT_LOAD_0
FBCh
VOLT_LOAD_1
FC0h
RTC_OFFSET
FC4h
FREQ_OFFSET
FC8h
IEEE_MAC_0
FCCh
IEEE_MAC_1
FD0h
IEEE_BLE_0
FD4h
IEEE_BLE_1
FD8h
BL_CONFIG
FDCh
ERASE_CONF
FE0h
CCFG_TI_OPTIONS
FE4h
CCFG_TAP_DAP_0
FE8h
CCFG_TAP_DAP_1
FECh
IMAGE_VALID_CONF
FF0h
CCFG_PROT_31_0
FF4h
CCFG_PROT_63_32
FF8h
CCFG_PROT_95_64
FFCh
CCFG_PROT_127_96
SWCU117C – February 2015 – Revised September 2015
Submit Documentation Feedback
Table 9-1. CCFG Registers
Register Name
Extern LF clock configuration
Mode Configuration 1
CCFG Size and Disable Flags
Mode Configuration 0
Voltage Load 0
Voltage Load 1
Real Time Clock Offset
Frequency Offset
IEEE MAC Address 0
IEEE MAC Address 1
IEEE BLE Address 0
IEEE BLE Address 1
Bootloader Configuration
Erase Configuration
TI Options
Test Access Points Enable 0
Test Access Points Enable 1
Image Valid
Protect Sectors 0-31
Protect Sectors 32-63
Protect Sectors 64-95
Protect Sectors 96-127
Copyright © 2015, Texas Instruments Incorporated
Customer Configuration (CCFG)
Section
Section 9.1.1.1
Section 9.1.1.2
Section 9.1.1.3
Section 9.1.1.4
Section 9.1.1.5
Section 9.1.1.6
Section 9.1.1.7
Section 9.1.1.8
Section 9.1.1.9
Section 9.1.1.10
Section 9.1.1.11
Section 9.1.1.12
Section 9.1.1.13
Section 9.1.1.14
Section 9.1.1.15
Section 9.1.1.16
Section 9.1.1.17
Section 9.1.1.18
Section 9.1.1.19
Section 9.1.1.20
Section 9.1.1.21
Section 9.1.1.22
Device Configuration
689
