AES Cryptoprocessor Overview
10.1.4.5.4 Data Input and Output Registers
The AESDATAINn and AESDATAOUTn data registers are typically accessed through DMA and not with
host writes and reads. However, for debugging purposes, the Data Input and Output Registers can be
accessed through host write and read operations. The registers buffer the input and output data blocks to
and from the crypto core.
NOTE: The data input buffer AESDATAINn and data output buffer AESDATAOUTn are mapped to
the same address locations.
Writes (both DMA and host) to these addresses load the input buffer, while reads pull from the output
buffer. Therefore, for write access, the data input buffer is written; for read access, the data output buffer
is read. The data input buffer must be written before starting an operation. The data output buffer contains
valid data when an operation completes. Therefore, any 128-bit data block can be split over multiple 32-bit
word transfers; these transfers can be mixed with other host transfers over the external interface.
For normal operations, this register is not used, because data input and output is transferred from and to
the AES core through DMA. For a host write operation, these registers must be written with the 128-bit
input block for the next AES operation. Writing at a word-aligned offset within this address range stores
the word (4 bytes) of data into the corresponding position of 4-word deep (16 bytes = 128-bit AES block)
data-input buffer. This buffer is used for the next AES operation. If the last data block is not completely
filled with valid data, it can write only the words with valid data. Finally, the AES operation is triggered by
writing the AESCTL.INPUT_RDY register bit.
For a host read operation, this register contains the 128-bit output block from the latest AES operation.
Reading from a word-aligned offset within this address range reads one word (4 bytes) of data out of the
4-word deep (16 bytes = 128-bits AES block) data output buffer. The words (four words, one full block)
must be read before the core moves the next block to the data output buffer. To empty the data output
buffer, the AESCTL.OUTPUT_RDY bit must be written.
For the modes with authentication (CBC-MAC and CCM), the invalid (message) bytes/words can be
written with any data.
NOTE: AES typically operates on a 128-bit block with multiple input data. The CTR and CCM modes
form an exception. The last block of a CTR-mode message may contain less than 128 bits
(refer to [NIST 800-38A]): 0 < n < = 128 bits. For CCM, the last block of both AAD and
message data may contain less than 128 bits (refer to [NIST 800-38D]). The AES module
automatically pads or masks misaligned ending data blocks with zeroes for CCM and
CBC-MAC. For CTR mode, the remaining data in an unaligned data block is ignored. The
AAD or authentication-only data is not copied to the output buffer but is only used for
authentication.
Operation
ECB/CBC encrypt
ECB/CBC decrypt
CTR encrypt
CTR decrypt
CCM AAD data
CCM encrypt data
CCM decrypt data
CBC-MAC data
812
Table 10-7. Input/Output Block Format Per Operating Mode
Data Input Buffer
128-bit plaintext block
128-bit ciphertext block
n-bit plaintext block
n-bit ciphertext block
n-bit plaintext block
n-bit plaintext block
n-bit ciphertext block
n-bit plaintext block
Copyright © 2015, Texas Instruments Incorporated
Data Output Buffer
128-bit ciphertext block
128-bit plaintext block
n-bit ciphertext block
n-bit plaintext block
no output data
n-bit ciphertext block
n-bit plaintext block
no output data
SWCU117C – February 2015 – Revised September 2015
Submit Documentation Feedback
