17.3 I/O Mapping

Up to 16 package-dependent I/Os can be routed to the AUX_PD I/O controller by configuring the MCU I/O
controller, which allows the sensor controller to directly control I/Os independently of the MCU and the
MCU power modes used.
See Chapter 11, I/O Control, for more details on the mapping between AUX I/Os and digital I/Os.
SWCU117C – February 2015 – Revised September 2015
Submit Documentation Feedback
Table 17-2. Register Mapping (continued)
Register Name
PWRDWNACK
CLKLFREQ
CLKLFACK
BGAPREQ
BGAPACK
MCUBUSCTL
MCUBUSSTAT
EVTOMCUFLAGSCLR
EVTOAONFLAGSCLR
VECFLAGSCLR
MODCLKEN1
T1CTL
SET03[1:0]
SET03[3:2]
SET47[1:0]
SET47[3:2]
SET811[1:0]
SET811[3:2]
SET1215[1:0]
SET1215[3:2]
CLR03[1:0]
CLR03[3:2]
CLR47[1:0]
CLR47[3:2]
CLR811[1:0]
CLR811[3:2]
CLR1215[1:0]
CLR1215[3:2]
AUX – Sensor Controller with Digital and Analog Peripherals
Copyright © 2015, Texas Instruments Incorporated
Original Address
0x400C 6000+0x0C
0x400C 6000+0x10
0x400C 6000+0x14
0x400C 6000+0x20
0x400C 6000+0x24
0x400C 6000+0x48
0x400C 6000+0x4C
0x400C 5000+0x38
0x400C 5000+0x3C
0x400C 5000+0x40
0x400C 6000+0x5C
0x400C 7000+0x14
0x400C B000+0x10
0x400C B000+0x12
0x400C B000+0x14
0x400C B000+0x16
0x400C B000+0x18
0x400C B000+0x1A
0x400C B000+0x1C
0x400C B000+0x1E
0x400C B000+0x20
0x400C B000+0x22
0x400C B000+0x24
0x400C B000+0x26
0x400C B000+0x28
0x400C B000+0x2A
0x400C B000+0x2C
0x400C B000+0x2E
I/O Mapping
Alias Address
55
56
57
60
61
62
63
64
65
66
67
68
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
1193
