CC2650 SimpleLink™ Multistandard Wireless MCU

1 Device Overview

1.1

Features

1
• Microcontroller
®
– Powerful ARM
Cortex
®
– EEMBC CoreMark
– Up to 48-MHz Clock Speed
– 128KB of In-System Programmable Flash
– 8KB of SRAM for Cache
– 20KB of Ultralow-Leakage SRAM
– 2-Pin cJTAG and JTAG Debugging
– Supports Over-The-Air Upgrade (OTA)
• Ultralow-Power Sensor Controller
– Can Run Autonomous From the Rest of the
System
– 16-Bit Architecture
– 2KB of Ultralow-Leakage SRAM for Code and
Data
• Efficient Code Size Architecture, Placing Drivers,
®
Bluetooth
Low Energy Controller, IEEE 802.15.4
MAC, and Bootloader in ROM
• RoHS-Compliant Packages
– 4-mm × 4-mm RSM VQFN32 (10 GPIOs)
– 5-mm × 5-mm RHB VQFN32 (15 GPIOs)
– 7-mm × 7-mm RGZ VQFN48 (31 GPIOs)
• Peripherals
– All Digital Peripheral Pins Can Be Routed to
Any GPIO
– Four General-Purpose Timer Modules
(Eight 16-Bit or Four 32-Bit Timers, PWM Each)
– 12-Bit ADC, 200-ksamples/s, 8-Channel Analog
MUX
– Continuous Time Comparator
– Ultralow-Power Analog Comparator
– Programmable Current Source
– UART
– 2× SSI (SPI, MICROWIRE, TI)
– I2C
– I2S
– Real-Time Clock (RTC)
– AES-128 Security Module
– True Random Number Generator (TRNG)
– 10, 15, or 31 GPIOs, Depending on Package
Option
– Support for Eight Capacitive-Sensing Buttons
– Integrated Temperature Sensor
• External System
– On-Chip internal DC-DC Converter
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
Sample &
Product
Buy
Folder
®
-M3
Score: 142
Tools &
Technical
Software
Documents
SWRS158B – FEBRUARY 2015 – REVISED JULY 2016
– Very Few External Components
– Seamless Integration With the SimpleLink™
CC2590 and CC2592 Range Extenders
– Pin Compatible With the SimpleLink CC13xx in
4-mm × 4-mm and 5-mm × 5-mm VQFN
Packages
• Low Power
– Wide Supply Voltage Range
Normal Operation: 1.8 to 3.8 V
External Regulator Mode: 1.7 to 1.95 V
– Active-Mode RX: 5.9 mA
– Active-Mode TX at 0 dBm: 6.1 mA
– Active-Mode TX at +5 dBm: 9.1 mA
– Active-Mode MCU: 61 µA/MHz
– Active-Mode MCU: 48.5 CoreMark/mA
– Active-Mode Sensor Controller: 8.2 µA/MHz
– Standby: 1 µA (RTC Running and RAM/CPU
Retention)
– Shutdown: 100 nA (Wake Up on External
Events)
• RF Section
– 2.4-GHz RF Transceiver Compatible With
Bluetooth Low Energy (BLE) 4.2 Specification
and IEEE 802.15.4 PHY and MAC
– Excellent Receiver Sensitivity (–97 dBm for BLE
and –100 dBm for 802.15.4), Selectivity, and
Blocking Performance
– Link budget of 102 dB/105 dB (BLE/802.15.4)
– Programmable Output Power up to +5 dBm
– Single-Ended or Differential RF Interface
– Suitable for Systems Targeting Compliance With
Worldwide Radio Frequency Regulations
ETSI EN 300 328 (Europe)
EN 300 440 Class 2 (Europe)
FCC CFR47 Part 15 (US)
ARIB STD-T66 (Japan)
• Tools and Development Environment
– Full-Feature and Low-Cost Development Kits
– Multiple Reference Designs for Different RF
Configurations
– Packet Sniffer PC Software
– Sensor Controller Studio
– SmartRF™ Studio
– SmartRF Flash Programmer 2
– IAR Embedded Workbench
– Code Composer Studio™
Support &
Reference
Community
Design
CC2650
®
for ARM
