USB Type-C™ / USB Power Delivery interface (UCPD)
Bit 13 Reserved, must be kept at reset value.
Bit 12 RXMSGENDCF: Rx message received flag (RXMSGEND) clear
Setting the bit clears the RXMSGEND flag in the UCPD_SR register.
Bit 11 RXOVRCF: Rx overflow flag (RXOVR) clear
Setting the bit clears the RXOVR flag in the UCPD_SR register.
Bit 10 RXHRSTDETCF: Rx Hard Reset detect flag (RXHRSTDET) clear
Setting the bit clears the RXHRSTDET flag in the UCPD_SR register.
Bit 9 RXORDDETCF: Rx ordered set detect flag (RXORDDET) clear
Setting the bit clears the RXORDDET flag in the UCPD_SR register.
Bits 8:7 Reserved, must be kept at reset value.
Bit 6 TXUNDCF: Tx underflow flag (TXUND) clear
Setting the bit clears the TXUND flag in the UCPD_SR register.
Bit 5 HRSTSENTCF: Hard reset send flag (HRSTSENT) clear
Setting the bit clears the HRSTSENT flag in the UCPD_SR register.
Bit 4 HRSTDISCCF: Hard reset discard flag (HRSTDISC) clear
Setting the bit clears the HRSTDISC flag in the UCPD_SR register.
Bit 3 TXMSGABTCF: Tx message abort flag (TXMSGABT) clear
Setting the bit clears the TXMSGABT flag in the UCPD_SR register.
Bit 2 TXMSGSENTCF: Tx message send flag (TXMSGSENT) clear
Setting the bit clears the TXMSGSENT flag in the UCPD_SR register.
Bit 1 TXMSGDISCCF: Tx message discard flag (TXMSGDISC) clear
Setting the bit clears the TXMSGDISC flag in the UCPD_SR register.
Bit 0 Reserved, must be kept at reset value.
38.7.8

UCPD Tx ordered set type register (UCPD_TX_ORDSETR)

Address offset: 0x01C
Reset value: 0x0000 0000
Writing to this register is only effective when the peripheral is enabled (UCPDEN = 1) and
no packet transmission is in progress (TXSEND and TXHRST bits are both low).
31 30 29
Res. Res. Res. Res.
15 14 13
rw rw rw
Bits 31:20 Reserved, must be kept at reset value.
Bits 19:0 TXORDSET[19:0]: Ordered set to transmit
The bitfield determines a full 20-bit sequence to transmit, consisting of four K-codes, each of
five bits, defining the packet to transmit. The bit 0 (bit 0 of K-code1) is the first, the bit 19 (bit
4 of K-code4) the last.
