Page 4
The information in this manual is subject to change without notice and should not be construed as a commitment by ABB. ABB assumes no responsibility for any errors that may appear in this manual. Except as may be expressly stated anywhere in this manual, nothing herein shall be construed as any kind of guarantee or warranty by ABB for losses, damages to persons or property, fitness for a specific purpose or the like.
Prerequisites A maintenance/repair/installation personnel working with an ABB Robot must: • be trained by ABB and have the required knowledge of mechanical and electrical installation/repair/maintenance work. Organization of chapters The manual is organized in the following chapters: Chapter...
This listing is based on the type of information in the documents, regardless of whether the products are standard or optional. All documents listed can be ordered from ABB on a DVD. The documents listed are valid for IRC5 robot systems.
ABB Ltd and its entities are not liable for damages and/or losses related to such security breaches, any unauthorized access, interference, intrusion, leakage and/or theft of data or information.
Limitation of liability Any information given in this manual regarding safety must not be construed as a warranty by ABB that the industrial robot will not cause injury or damage even if all safety instructions are complied with. Related information...
1.2.3 Safety in collaborative operation General IRB 14000 is intended for collaborative applications where contact between robot and the operator is harmless. The robot is designed to comply with ISO 10218-1, §5.10.5. Power and force limiting by inherent design or control. This is achieved by inherent design measures in the robot arm and control system.
ABB is not liable for damages caused by the use of non-original spare parts and special equipment. ABB is not liable for damages or injuries caused by unauthorized modifications to the robot system.
The IRB 14000 gripper is not designed to retain work pieces in case of power loss. Objects held by the servo and vacuum modules may be released, in the event of pneumatic or electric power loss to the gripper.
VAC). • The IRB 14000 gripper is powered by 24 V DC from the robot tool flange. A risk for short-circuit and sparks exists. All installation and service works should be done with power disconnected from the gripper and the tool flange.
Page 38
Note The FlexPendant is always equipped with a three-position enabling device, but for the IRB 14000 system the enabling device is not used. Therefore the enabling device is disabled and inactive when the FlexPendant is connected to an IRB 14000 system, but it is enabled and active when connected to another robot.
Safety on page 17 before performing any installation work. Note If the IRB 14000 is connected to power, always make sure that the robot is connected to protective earth before starting any installation work! For more information see: • Product manual - IRC5...
It also contains information useful during later re-installation of the robot. Checking the pre-requisites for installation Installation personnel working with an ABB product must: • be trained by ABB and have the required knowledge of mechanical and electrical installation/maintenance/repair work • conform to all national and local codes.
2.3.1 Lifting the robot with lifting accessories Introduction The IRB 14000 is a collaborative robot, the whole robot can be lifted by lifting accessories or lifted by two persons. This section contains a general overview of how to lift the complete robot using lifting accessories.
Lifting and transporting the robot Use this procedure to lift the robot. Action Note CAUTION The IRB 14000 robot weighs 38 kg and can be lifted by two persons. Grasp the hand-holding grooves, one person on each side of the robot. xx1400002122...
Communicates with FlexPendant to which the robot con- nects. Main power cable Main power cable can be provided by customer or purchased from ABB as option. The following table lists the ABB-supplied main power cables in different interface standards. Choose as required.
The IRB 14000 integrated controller is based on the standard IRC5 controller, and contains all functions needed to move and control the robot. xx1400002127 Note When replacing a unit in the controller, report the following data to ABB, for both the replaced unit and the replacement unit: • the serial number •...
Main AC power connector, IEC 60320-1 C14, 100-240 VAC, 50-60 Hz Connecting power supply Line fusing Line fusing of the IRB 14000 is 5A at 100-240 V. Rated power Rated power of the IRB 14000 is 360 W. Required equipment...
Page 95
For example field buses, cameras, and welding equipment. Note When using IRB 14000 grippers, the following restrictions apply to the usage of LAN2: • Any external units connected to LAN2 need to have IP addresses on the same subnet as the grippers, network 192.168.125.0/24.
2 Installation and commissioning 2.4.4 Connecting I/O signals 2.4.4 Connecting I/O signals Introduction It is possible to connect digital I/O signals to the IRB 14000 through the connectors on the interface on the left side panel of the controller. xx1400002129 XS12...
PROFINET or EtherNet/IP (fieldbus adapter option) Note DeviceNet m/s (option 709-1) is provided at XS17 as default. The DeviceNet fieldbus adapter (option 840-4) is not supported by IRB 14000. Continues on next page Product manual - IRB 14000 3HAC052983-001 Revision: D...
2.4.6 Connecting safety signals Introduction The IRB 14000 safety stop signals (SS) are accessed through the safety connector on the interface on the left side panel of the controller. This is covered by a safety bridge connector by default in standalone mode. If the bridge connector is removed, it is external device mode.
Page 103
IRB 14000 FlexPendant. Safety PLC The safety PLC shall process the input from the IRB 14000 emergency stop, as well as inputs from other safety devices in the cell, and set the necessary outputs to stop machinery in the cell.
Page 104
RT6 safety relay (option 1526-X) through the safety connector XS9. The safety relay also receives main power inputs and then feeds the inputs to the robot power inlet. Contact ABB for further information. xx1600001076 For more information about connecting the safety signals, see Circuit diagram - IRB 14000.
2.4.7.1 SD-card memory 2.4.7 Memory functions 2.4.7.1 SD-card memory General The controller is fitted with an SD-card memory containing ABB Boot Application software. The SD-card memory is located inside the computer unit. Note Only use SD-card memory supplied by ABB.
Safety on page 17 before performing any service work! Note If the IRB 14000 is connected to power, always make sure that the IRB 14000 is connected to protective earth before starting any maintenance work! For more information see: •...
3.2.1 Specification of maintenance intervals Introduction The intervals are specified in different ways depending on the type of maintenance activity to be carried out and the working conditions of the IRB 14000: • Calendar time: specified in months regardless of whether the system is running or not.
Page 113
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Page 124
WARNING - The unit is sensitive to ESD! on page 55 Fit the battery and and secure it with a cable tie. Note Battery includes protection circuits. Only replace with a specified spare part or with an ABB-ap- proved equivalent. xx1500000506 Connect the battery connector (X3). xx1500000505 Refit the body cover.
Turn off all electrical power supplies to the robot before starting the cleaning. General To secure high uptime it is important that the IRB 14000 is cleaned regularly. The frequency of cleaning depends on the environment in which the manipulator works.
Make sure to read through the chapter Safety on page 17 before commencing any service work. Note If the IRB 14000 is connected to power, always make sure that the IRB 14000 is connected to earth before starting any repair work. For more information see: •...
Page 129
If the flange surfaces are defective, the parts may not be used because leakage could occur. Clean the surfaces properly in accordance with the recommendations of ABB. Distribute the sealing compound evenly over the surface, preferably with a brush. Tighten the screws evenly when fastening the flange joint.
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Page 302
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Required spare parts Note The spare part numbers that are listed in the table can be out of date. See the latest revision of Product manual, spare parts - IRB 14000 on ABB Library. Spare part Article number Note...
Under this condition, all the seven joints' positions are pre-determined, and all of the axes can be calibrated at the same time. The fine calibration method is used for all IRB 14000 robots and is the recommended method in order to achieve proper performance.
Only robots with protection Clean Room. Deviations from ISO 10218-1:2011 ISO 10218-1:2011 was developed with conventional industrial robots in mind. Deviations from the standard are motivated for IRB 14000 in the table below. More information about ISO 10218-1 compliance is given in technote_150918. Requirement...
UNBRAKO screws UNBRAKO is a special type of screw recommended by ABB for certain screw joints. It features special surface treatment (Gleitmo as described below) and is extremely resistant to fatigue.
All components exceeding 22 kg (50 lbs) are highlighted in this way. To avoid injury, ABB recommends the use of a lifting accessory when handling components with a weight exceeding 22 kg. A wide range of lifting accessories and devices are available for each manipulator model.
