25.16.2

TRACE pin assignment

Asynchronous mode
The asynchronous mode requires 1 extra pin and is available on all packages. It is only
available if using Serial Wire mode (not in JTAG mode).
TPUI pin name
TRACESWO
Synchronous mode
The synchronous mode requires from 2 to 6 extra pins depending on the data trace
size and is only available in the larger packages. In addition it is available in JTAG
mode and in Serial Wire mode and provides better bandwidth output capabilities than
asynchronous trace.
TPUI pin name
TRACECK
TRACED[3:0]
TPUI TRACE pin assignment
By default, these pins are NOT assigned. They can be assigned by setting the
TRACE_IOEN and TRACE_MODE bits in the MCU Debug component configuration
register. This configuration has to be done by the debugger host.
In addition, the number of pins to assign depends on the trace configuration (asynchronous
or synchronous).
Asynchronous mode: 1 extra pin is needed
Synchronous mode: from 2 to 5 extra pins are needed depending on the size of the
data trace port register (1, 2 or 4):
To assign the TRACE pin, the debugger host must program the bits TRACE_IOEN and
TRACE_MODE[1:0] of the Debug MCU configuration register (DBGMCU_CR). By default
the TRACE pins are not assigned.
This register is mapped on the external PPB and is reset by the PORESET (and not by the
SYSTEM reset). It can be written by the debugger under SYSTEM reset.

Table 156. Asynchronous TRACE pin assignment

Type

Table 157. Synchronous TRACE pin assignment

Type
O
O
TRACECK
TRACED(0) if port size is configured to 1, 2 or 4
TRACED(1) if port size is configured to 2 or 4
TRACED(2) if port size is configured to 4
TRACED(3) if port size is configured to 4
Trace synchronous mode
Description
O
TRACE Async Data Output
Trace synchronous mode
Description
TRACE Clock
TRACE Sync Data Outputs
Can be 1, 2 or 4.
RM0041 Rev 6
Debug support (DBG)
STM32F100xx pin
assignment
PB3
STM32F100xxpin
assignment
PE2
PE[6:3]
