Flexible static memory controller (FSMC)
Bit number
31-20
19
18:16
15
14
13
12
11
10
9
8
7
6
5-4
3-2
1
0
Bit number
31:30
29-28
27-24
23-20
19-16
15-8
7-4
3-0
504/709

Table 98. FSMC_BCRx bit fields

Bit name
Reserved 0x000
CBURSTRW 0x0 (no effect on asynchronous mode)
CPSIZE 0x0 (no effect on asynchronous mode)
ASYNCWAIT Set to 1 if the memory supports this feature. Otherwise keep at 0.
EXTMOD 0x0
WAITEN 0x0 (no effect on asynchronous mode)
WREN As needed
WAITCFG Don't care
WRAPMOD 0x0
WAITPOL Meaningful only if bit 15 is 1
BURSTEN 0x0
Reserved 0x1
FACCEN Don't care
MWID As needed
MTYP[0:1] As needed, exclude 0x2 (NOR flash)
MUXE 0x0
MBKEN 0x1

Table 99. FSMC_BTRx bit fields

Bit name
Reserved 0x0
ACCMOD Don't care
DATLAT Don't care
CLKDIV Don't care
BUSTURN Time between NEx high to NEx low (BUSTURN HCLK)
Duration of the second access phase (DATAST+1 HCLK cycles for
DATAST
write accesses, DATAST HCLK cycles for read accesses).
ADDHLD Don't care
Duration of the first access phase (ADDSET HCLK cycles).
ADDSET[3:0]
Minimum value for ADDSET is 0.
RM0041 Rev 6
Value to set
Value to set
RM0041
