RM0041
12.4.15

TIM1 capture/compare register 2 (TIMx_CCR2)

Address offset: 0x38
Reset value: 0x0000
15 14 13
rw/ro rw/ro rw/ro rw/ro
Bits 15:0 CCR2[15:0]: Capture/Compare 2 value
12.4.16

TIM1 capture/compare register 3 (TIMx_CCR3)

Address offset: 0x3C
Reset value: 0x0000
15 14 13
rw/ro rw/ro rw/ro rw/ro
Bits 15:0 CCR3[15:0]: Capture/Compare value
12 11 10 9
rw/ro rw/ro rw/ro
If channel CC2 is configured as output:
CCR2 is the value to be loaded in the actual capture/compare 2 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR2 register
(bit OC2PE). Else the preload value is copied in the active capture/compare 2 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on OC2 output.
If channel CC2 is configured as input:
CCR2 is the counter value transferred by the last input capture 2 event (IC2). The
TIMx_CCR2 register is read-only and cannot be programmed.
12 11 10 9
rw/ro rw/ro rw/ro
If channel CC3 is configured as output:
CCR3 is the value to be loaded in the actual capture/compare 3 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR3 register
(bit OC3PE). Else the preload value is copied in the active capture/compare 3 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on OC3 output.
If channel CC3 is configured as input:
CCR3 is the counter value transferred by the last input capture 3 event (IC3). The
TIMx_CCR3 register is read-only and cannot be programmed.
8 7 6
CCR2[15:0]
rw/ro rw/ro rw/ro rw/ro
8 7 6
CCR3[15:0]
rw/ro rw/ro rw/ro rw/ro
RM0041 Rev 6
Advanced-control timer (TIM1)
5 4 3 2
rw/ro rw/ro rw/ro
5 4 3 2
rw/ro rw/ro rw/ro
1 0
rw/ro rw/ro
1 0
rw/ro rw/ro
277/709
