Advanced-control timer (TIM1)
Input capture mode
Bits 15:12 IC4F: Input capture 4 filter
Bits 11:10 IC4PSC: Input capture 4 prescaler
Bits 9:8 CC4S: Capture/Compare 4 selection
Note: CC4S bits are writable only when the channel is OFF (CC4E = '0' in TIMx_CCER).
Bits 7:4 IC3F: Input capture 3 filter
Bits 3:2 IC3PSC: Input capture 3 prescaler
Bits 1:0 CC3S: Capture/compare 3 selection
Note: CC3S bits are writable only when the channel is OFF (CC3E = '0' in TIMx_CCER).
12.4.9

TIM1 capture/compare enable register (TIMx_CCER)

Address offset: 0x20
Reset value: 0x0000
15 14 13
CC4NP CC4P CC4E
Res.
rw rw
Bit 15 CC4NP: Capture/Compare 4 complementary output polarity
Bit 14 Reserved, must be kept at reset value.
Bit 13 CC4P: Capture/Compare 4 output polarity
Bit 12 CC4E: Capture/Compare 4 output enable
Bit 11 CC3NP: Capture/Compare 3 complementary output polarity
Bit 10 CC3NE: Capture/Compare 3 complementary output enable
Bit 9 CC3P: Capture/Compare 3 output polarity
272/709
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC4 channel is configured as output
01: CC4 channel is configured as input, IC4 is mapped on TI4
10: CC4 channel is configured as input, IC4 is mapped on TI3
11: CC4 channel is configured as input, IC4 is mapped on TRC. This mode is working only if
an internal trigger input is selected through TS bit (TIMx_SMCR register)
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC3 channel is configured as output
01: CC3 channel is configured as input, IC3 is mapped on TI3
10: CC3 channel is configured as input, IC3 is mapped on TI4
11: CC3 channel is configured as input, IC3 is mapped on TRC. This mode is working only if
an internal trigger input is selected through TS bit (TIMx_SMCR register)
12 11 10 9
CC3NP CC3NE CC3P
rw rw rw rw
refer to CC1NP description
refer to CC1P description
refer to CC1E description
refer to CC1NP description
refer to CC1NE description
refer to CC1P description
8 7 6
CC3E CC2NP CC2NE CC2P
rw rw rw
RM0041 Rev 6
5 4 3 2
CC2E CC1NP CC1NE
rw rw rw rw
RM0041
1 0
CC1P CC1E
rw rw
