TIM6 and TIM7 control register 2 (TIMx_CR2)

Address offset: 0x04
Reset value: 0x0000
15 14 13
Bits 15:7 Reserved, must be kept at reset value.
Bits 6:4 MMS[2:0]: Master mode selection
Note: The clock of the slave timer and ADC must be enabled prior to receiving events from
Bits 3:0 Reserved, must be kept at reset value.
16.4.3

TIM6 and TIM7 DMA/Interrupt enable register (TIMx_DIER)

Address offset: 0x0C
Reset value: 0x0000
15 14 13
Reserved
Bits 15:9 Reserved, must be kept at reset value.
Bit 8 UDE: Update DMA request enable
Bits 7:1 Reserved, must be kept at reset value.
Bit 0 UIE: Update interrupt enable
12 11 10 9
Reserved
These bits are used to select the information to be sent in master mode to slave timers for
synchronization (TRGO). The combination is as follows:
000: Reset - the UG bit from the TIMx_EGR register is used as a trigger output (TRGO). If
reset is generated by the trigger input (slave mode controller configured in reset mode) then
the signal on TRGO is delayed compared to the actual reset.
001: Enable - the Counter enable signal, CNT_EN, is used as a trigger output (TRGO). It is
useful to start several timers at the same time or to control a window in which a slave timer
is enabled. The Counter Enable signal is generated by a logic OR between CEN control bit
and the trigger input when configured in gated mode.
When the Counter Enable signal is controlled by the trigger input, there is a delay on TRGO,
except if the master/slave mode is selected (see the MSM bit description in the TIMx_SMCR
register).
010: Update - The update event is selected as a trigger output (TRGO). For instance a
master timer can then be used as a prescaler for a slave timer.
the master timer, and must not be changed on-the-fly while triggers are received from
the master timer.
12 11 10 9
0: Update DMA request disabled.
1: Update DMA request enabled.
0: Update interrupt disabled.
1: Update interrupt enabled.
8 7 6
MMS[2:0]
rw
8 7 6
UDE
rw
RM0041 Rev 6
Basic timers (TIM6 and TIM7)
5 4 3 2
Reserved
rw rw
5 4 3 2
Reserved
1 0
1 0
UIE
rw
