RM0041
13.4

TIMx2 to TIM5 registers

Refer to
The 32-bit peripheral registers have to be written by words (32 bits). All other peripheral
registers have to be written by half-words (16 bits) or words (32 bits). Read accesses can be
done by bytes (8 bits), half-words (16 bits) or words (32 bits).
13.4.1

TIMx control register 1 (TIMx_CR1)

Address offset: 0x00
Reset value: 0x0000
15 14 13
Reserved
Bits 15:10 Reserved, must be kept at reset value.
Bits 9:8 CKD: Clock division
Bit 7 ARPE: Auto-reload preload enable
Bits 6:5 CMS: Center-aligned mode selection
Note: It is not allowed to switch from edge-aligned mode to center-aligned mode as long as
Bit 4 DIR: Direction
Note: This bit is read only when the timer is configured in Center-aligned mode or Encoder
Bit 3 OPM: One-pulse mode
Section 2.2 for a list of abbreviations used in register descriptions.
12 11 10 9
CKD[1:0]
rw
This bit-field indicates the division ratio between the timer clock (CK_INT) frequency and
sampling clock used by the digital filters (ETR, TIx),
00: t = t
DTS CK_INT
01: t = 2 × t
DTS CK_INT
10: t = 4 × t
DTS CK_INT
11: Reserved
0: TIMx_ARR register is not buffered
1: TIMx_ARR register is buffered
00: Edge-aligned mode. The counter counts up or down depending on the direction bit
(DIR).
01: Center-aligned mode 1. The counter counts up and down alternatively. Output compare
interrupt flags of channels configured in output (CCxS=00 in TIMx_CCMRx register) are set
only when the counter is counting down.
10: Center-aligned mode 2. The counter counts up and down alternatively. Output compare
interrupt flags of channels configured in output (CCxS=00 in TIMx_CCMRx register) are set
only when the counter is counting up.
11: Center-aligned mode 3. The counter counts up and down alternatively. Output compare
interrupt flags of channels configured in output (CCxS=00 in TIMx_CCMRx register) are set
both when the counter is counting up or down.
the counter is enabled (CEN=1)
0: Counter used as upcounter
1: Counter used as downcounter
mode.
0: Counter is not stopped at update event
1: Counter stops counting at the next update event (clearing the bit CEN)
General-purpose timers (TIM2 to TIM5)
8 7 6
ARPE CMS
rw rw rw
RM0041 Rev 6
5 4 3 2
DIR OPM URS
rw rw rw rw
1 0
UDIS CEN
rw rw
