Real-time clock (RTC)
32.6.21 RTC alarm A binary mode register (RTC_ALRABINR)
This register can be written only when ALRAE is reset in RTC_CR register, or in initialization
mode.
Address offset: 0x70
Backup domain reset value: 0x0000 0000
System reset: not affected
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:0 SS[31:0]: Synchronous counter alarm value in Binary mode
32.6.22 RTC alarm B binary mode register (RTC_ALRBBINR)
This register can be written only when ALRBE is reset in RTC_CR register, or in initialization
mode.
Address offset: 0x74
Backup domain reset value: 0x0000 0000
System reset: not affected
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:0 SS[31:0]: Synchronous counter alarm value in Binary mode
1030/1454
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
This value is compared with the contents of the synchronous counter to determine if Alarm A
is to be activated. Only bits 0 up MASKSS-1 are compared.
SS[14:0] is the mirror of SS[14:0] in the RTC_ALRMASSRR, and so can also be read or
written through RTC_ALRMASSR.
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
This value is compared with the contents of the synchronous counter to determine if Alarm
Bis to be activated. Only bits 0 up MASKSS-1 are compared.
SS[14:0] is the mirror of SS[14:0] in the RTC_ALRMBSSRR, and so can also be read or
written through RTC_ALRMBSSR.
