RM0033
15.5.10

TIM10/11/13/14 capture/compare register 1 (TIMx_CCR1)

Address offset: 0x34
Reset value: 0x0000
15 14 13
rw/ro rw/ro rw/ro rw/ro
Bits 15:0 CCR1[15:0]: Capture/Compare 1 value
If channel CC1 is configured as output:
CCR1 is the value to be loaded in the actual capture/compare 1 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR1 register (bit
OC1PE). Else the preload value is copied in the active capture/compare 1 register when an
update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on OC1 output.
If channel CC1is configured as input:
CCR1 is the counter value transferred by the last input capture 1 event (IC1). The TIMx_CCR1
register is read-only and cannot be programmed.
15.5.11

TIM11 option register 1 (TIM11_OR)

Address offset: 0x50
Reset value: 0x0000
15 14 13
Bits 15:2
Bits 1:0
12 11 10 9
rw/ro rw/ro rw/ro
12 11 10 9
Reserved
Reserved, must be kept at reset value.
TI1_RMP[1:0]: TIM11 Input 1 remapping capability
Set and cleared by software.
00,01,11: TIM11 Channel1 is connected to the GPIO (refer to the Alternate function mapping
table in the datasheets).
10: HSE_RTC clock (HSE divided by programmable prescaler) is connected to the
TIM11_CH1 input for measurement purposes
General-purpose timers (TIM9 to TIM14)
8 7 6
CCR1[15:0]
rw/ro rw/ro rw/ro rw/ro
8 7 6
RM0033 Rev 9
5 4 3 2
rw/ro rw/ro rw/ro
5 4 3 2
1 0
rw/ro rw/ro
1 0
TI1_RMP[1:0]
rw
481/1381
483
