1 Introduction
The ten DMA channels of the ADSP-21060 and ADSP-21062 are
numbered as shown below:
DMA
Channel#
DMA Channel 0
DMA Channel 1
DMA Channel 2
DMA Channel 3
DMA Channel 4
DMA Channel 5
DMA Channel 6
DMA Channel 7 *
DMA Channel 8 *
DMA Channel 9
DMAR1 DMAG1
* and
DMAR2 DMAG2
and

1.3.6.4 Booting

The internal memory of the ADSP-2106x can be booted at system
powerup from an 8-bit EPROM or a host processor. Additionally, the
ADSP-21060 and the ADSP-21062 can also be booted through one of
the link ports. Selection of the boot source is controlled by the
EBOOT, and LBOOT pins. Both 32-bit and 16-bit host processors can
be used for booting.
1.4

DEVELOPMENT TOOLS

The ADSP-2106x is supported with a complete set of software and
hardware development tools, including an EZ-LAB
®
Board, EZ-ICE
development software provides tools for programming and debugging
applications in both assembly language and C. The EZ-ICE emulator
allows system integration and hardware/software debugging. Figure
1.4 shows the process of developing an application using the
development tools.
The development software includes an ANSI C Compiler. The
compiler includes Numerical C extensions based on the work of the
ANSI NCEG committee (Numerical C Extensions Group).
1 – 16
www.BDTIC.com/ADI
Data
Buffer Description
RX0 Serial Port 0 Receive
RX1 (or LBUF0) Serial Port 1 Receive (or Link Buffer 0)
TX0 Serial Port 0 Transmit
TX1 (or LBUF1) Serial Port 1 Transmit (or Link Buffer 1)
LBUF2 Link Buffer 2
LBUF3 Link Buffer 3
EPB0 (or LBUF4) Ext. Port FIFO Buffer 0 (or Link Buffer 4)
EPB1 (or LBUF5) Ext. Port FIFO Buffer 1 (or Link Buffer 5)
EPB2 Ext. Port FIFO Buffer 2
EPB3 Ext. Port FIFO Buffer 3
are handshake controls for DMA Channel 7.
are handshake controls for DMA Channel 8.
In-Circuit Emulator, and development software. The
BMS
,
®
Evaluation
