Errata and Corrections
Chapter: A Page: 20
Revision Needed:
There is a typographical error in the first compute/immediate modify
example. Change as follows:
From:
IF FLAG0_IN F1=F5*F12, F11=PM(I10,40);
To:
IF FLAG0_IN F1=F5*F12, F11=PM(I10,4);
Chapter: A Page: 24
Revision Needed:
There is a typographical error in the first line of the immediate shift exam-
ple. Change as follows:
From:
IF GT R2=R6 LSHIFT BY 30, DM(I4,M4)=R0;
To:
IF GT LSHIFT BY 30, DM(I4,M4)=R0;
Chapter: B Page: 81
Revision Needed:
The fifth instruction from the bottom of the page should read:
Fm=F3-0 * F7-4, Ra=FIX F11-8 by R15-12
