D.4 BOUNDARY REGISTER
The Boundary register is 363 bits long. This section defines the latch
type and function of each position in the scan path. The positions are
numbered with 0 being the first bit output (closest to TDO) and 362
being the last (closest to TDI).
Scan Latch
Position Type
0 input
1 input
2 input
3 input
4 input
5 input
6 input
7 input
8 input
9 input
10 output
11 input
12 output
13 input
14 output
15 input
16 output
17 input
18 output
19 input
20 output
21 input
22 output enable
23 output enable
24 output
25 input
26 output
27 input
28 output
29 input
30 output
31 input
32 output
33 input
34 output
35 input
36 output enable
37 output enable
38 output
39 input
Output Enables:
1 = Drive the associated signals during the EXTEST and INTEST instructions
0 = Tristate the associated signals during the EXTEST and INTEST instructions
