JTAG Test Access Port
Scan Latch
Position Type
290 output
291 input
292 output
293 input
294 output
295 input
296 output
297 input
298 output
299 input
300 output
301 input
302 output
303 input
304 output
305 input
306 output
307 input
308 output enable
309 output
310 input
311 output
312 input
313 output
314 input
315 output
316 input
317 output
318 input
319 output
320 input
321 output
322 input
323 output
324 input
325 output
326 input
327 output
328 input
329 output
330 input
331 output
332 input
333 output
334 input
335 output
336 input
337 output
338 input
339 output
www.BDTIC.com/ADI
Signal
Name
ADDR27
ADDR27
ADDR26
ADDR26
ADDR25
ADDR25
ADDR24
ADDR24
ADDR23
ADDR23
ADDR22
ADDR22
ADDR21
ADDR21
ADDR20
ADDR20
ADDR19
ADDR19
MS SW
ADDRx, x, output enable
ADDR18
ADDR18
ADDR17
ADDR17
ADDR16
ADDR16
ADDR15
ADDR15
ADDR14
ADDR14
ADDR13
ADDR13
ADDR12
ADDR12
ADDR11
ADDR11
ADDR10
ADDR10
ADDR9
ADDR9
ADDR8
ADDR8
ADDR7
ADDR7
ADDR6
ADDR6
ADDR5
ADDR5
ADDR4
ADDR4
ADDR3
D
D – 11
