Instruction Set Reference
Syntax:
IF condition

compute ;

Function:
Conditional compute instruction. The instruction is executed if the
specified condition tests true.
Examples:
IF MS MRF=0;
F6=(F2+F3)/2;
Opcode:
47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23
0 0 0 0 0 0 0 1
22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
COMPUTE
The operation specified in the COMPUTE field is executed if the condition
specified by COND is true. If no condition is specified in the instruction,
COND is the TRUE condition, and the compute operation is always
executed.
www.BDTIC.com/ADI
Compute and Move
COND
A
compute
A – 17
