DOCUMENTATION ERRATA
Chapter: 7 Page: 31
Revision Needed:
The instruction should be replaced with
IF NE JUMP (PC,-2);
IF TF JUMP (PC,-2);
Chapter: 8 Page: 8
Revision Needed:
The last paragraph on this page is confusing. It should be changed to:
Table 8.2 covers all cases including various multiprocessing systems.
There is a special case for a single ADSP-2106x system where id=0. In this
scenario, the host needs to drive only the ADDR pins.
18–0
Chapter: 10 Page: 18
Revision Needed:
Add the following statement to the third paragraph of the Companding
section:
Program the SPORT registers prior to loading data values into the
SPORT buffers for companding to execute properly.
Chapter: A Page: 5
Revision Needed:
The condition labeled NBM is incorrect syntax. The correct syntax for the
condition is NOT BM.
H-7
