RM0365
Bit 2 CC2IF: Capture/Compare 2 interrupt flag
Refer to CC1IF description
Bit 1 CC1IF: Capture/compare 1 interrupt flag
If channel CC1 is configured as output: This flag is set by hardware when the counter
matches the compare value, with some exception in center-aligned mode (refer to the CMS
bits in the TIMx_CR1 register description) and in retriggerable one pulse mode. It is cleared
by software.
0: No match.
1: The content of the counter TIMx_CNT has matched the content of the TIMx_CCR1
register.
If channel CC1 is configured as input: This bit is set by hardware on a capture. It is cleared
by software or by reading the TIMx_CCR1 register.
0: No input capture occurred.
1: The counter value has been captured in TIMx_CCR1 register (An edge has been detected
on IC1 which matches the selected polarity).
Bit 0 UIF: Update interrupt flag
This bit is set by hardware on an update event. It is cleared by software.
0: No update occurred
1: Update interrupt pending. This bit is set by hardware when the registers are updated:
At overflow or underflow (for TIM2 to TIM4) and if UDIS=0 in the TIMx_CR1 register.
When CNT is reinitialized by software using the UG bit in TIMx_EGR register, if URS=0 and
UDIS=0 in the TIMx_CR1 register.
When CNT is reinitialized by a trigger event (refer to the synchro control register description),
if URS=0 and UDIS=0 in the TIMx_CR1 register.
21.4.6

TIMx event generation register (TIMx_EGR)

Address offset: 0x14
Reset value: 0x0000
15
14
13
Res.
Res.
Res.
Res.
Bits 15:7 Reserved, must be kept at reset value.
Bit 6 TG: Trigger generation
Bit 5 Reserved, must be kept at reset value.
Bit 4 CC4G: Capture/compare 4 generation
Bit 3 CC3G: Capture/compare 3 generation
12
11
10
9
Res.
Res.
Res.
This bit is set by software in order to generate an event, it is automatically cleared by
hardware.
0: No action
1: The TIF flag is set in TIMx_SR register. Related interrupt or DMA transfer can occur if
enabled.
Refer to CC1G description
Refer to CC1G description
General-purpose timers (TIM2/TIM3/TIM4)
8
7
6
Res.
Res.
TG
w
DocID025202 Rev 7
5
4
3
2
Res.
CC4G
CC3G
CC2G
w
w
w
1
0
CC1G
UG
w
w
604/1080
618
