Direct memory access controller (DMA)
12.5.2 DMA interrupt flag clear register (DMA_IFCR)
Address offset: 0x04
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
CTEIF4 CHTIF4 CTCIF4 CGIF4 CTEIF3 CHTIF3 CTCIF3 CGIF3 CTEIF2 CHTIF2 CTCIF2 CGIF2 CTEIF1 CHTIF1 CTCIF1 CGIF1
w w w
Bits 31:28 Reserved, must be kept at reset value.
Bits 27, 23, 19, 15, CTEIFx: Channel x transfer error clear (x = 1..7)
11, 7, 3
This bit is set by software.
0: No effect
1: Clears the corresponding TEIF flag in the DMA_ISR register
Bits 26, 22, 18, 14, CHTIFx: Channel x half transfer clear (x = 1..7)
10, 6, 2
This bit is set by software.
0: No effect
1: Clears the corresponding HTIF flag in the DMA_ISR register
Bits 25, 21, 17, 13, CTCIFx: Channel x transfer complete clear (x = 1..7)
9, 5, 1
This bit is set by software.
0: No effect
1: Clears the corresponding TCIF flag in the DMA_ISR register
Bits 24, 20, 16, 12, CGIFx: Channel x global interrupt clear (x = 1..7)
8, 4, 0
This bit is set by software.
0: No effect
1: Clears the GIF, TEIF, HTIF and TCIF flags in the DMA_ISR register
